IP20 IK05 High Luminous Flux Suspended LED Linear Luminaire 50W / 55W / 60W

Minimum Order Quantity :	100PCS	Price :	Negotiable
Packaging Details :	Depends on each model	Delivery Time :	Depends on orders
Payment Terms :	T/T, Western Union, Paypal,L/C	Supply Ability :	10,000pcs/Month

Place of Origin:	China	Brand Name:	MF
Certification:	UL,DLC,Premium,SAA,TUV,VEET,CB	Model Number:	MF-LL1T5-50E

Detail Information
Name:	MF LED Linear Light	Power:	50W/55W/60W
Luminous Efficacy:	125lm/w	CRI:	80Ra, 90Ra
System Efficiency:	≥90%	UGR:	<16
Protection:	IP20/IK05	Lifespan:	100,000+hours
Size:	1200mm,1500mm
Highlight:	Suspended LED Linear Luminaire , IK05 LED Linear Luminaire , IP20 Suspended Linear LED Lighting

Product Description

IP20 IK05 High Luminous Flux Suspended LED Linear Luminaire 50W / 55W / 60W

Features& Benefits

* High efficacy of more than 125LM/W.
* Seamless connection without light leakage.
* Fast installation and easy maintenance.
* Optimum glare control.
* Shining free and uniform light.
* Individual and continuous row optional.

Model No	MF-LL1T5-50E
Input voltage	200-240V, 120-270V
Power(watt)	50W/55W/60W
Dimension	1200mm,1500mm
Color temperature	3000K,3500K,4000K,3000-6500K
LED Chip	Optional
Protection	IP20/IK05
Housing Color	Black(RAL9005),White(RAL9016)
Luminous Flux (lm)	125lm/w
CRI(Ra)	80Ra, 90Ra
Lifespan	50000H(L90/B10)
Beam Angle	70°down , 140°up
Operating Temperature	-25°C to +40°C
THD	<15%
Certificate	UL, DLC, Premium, SAA, TUV, VEET, CB
Warranty Period	5 years

Multiple Light Distribution:
IP20 IK05 High Luminous Flux Suspended LED Linear Luminaire 50W / 55W / 60W 0
                      Direct light                            Indirect / Direct light

           Asymmetric Direct light      Asymmetric Indirect/Direct
IP20 IK05 High Luminous Flux Suspended LED Linear Luminaire 50W / 55W / 60W 3

Suitable for a variety of intelligent home control systems, more modern


Installation and Technical Data:

What is MF linear lighting?
M Linear lighting is defined as a linear shape luminaire (opposed to square or round).
These luminaires long optics to distribute the light over a more narrow area than with traditional lighting. Usually, these lights are long in length and are installed as either suspended from a ceiling, surface mounted to a wall or ceiling or recessed into a wall or ceiling.

Application: Office,Education,Communication area
IP20 IK05 High Luminous Flux Suspended LED Linear Luminaire 50W / 55W / 60W 9
