IP65 LED Vapor Tight Light Fixture LED Tri-proof Light for Customized Lighting Solutions
Contact Person : Claire Li
Phone Number : 86-15999718117
WhatsApp : +8615999718117
| Minimum Order Quantity : | 100PCS | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | 66*23*24CM/25pcs/CTN, G.W: 12.3Kg | Delivery Time : | Depends on orders |
| Payment Terms : | T/T, Western Union, Paypal | Supply Ability : | 20,000pcs/Month |
| Place of Origin: | China | Brand Name: | MF |
|---|---|---|---|
| Certification: | CE, RoHS | Model Number: | MF-T218/MF-T236/MF-T258/MF-T270 |
|
Detail Information |
|||
| Product Code: | MF-T218/MF-T236/MF-T258/MF-T270 | Power: | 20W/40W/60W/80W |
|---|---|---|---|
| LED Type: | SMD2835 | LED Chip: | SAMSUNG |
| Luminous: | 140lm/w | Viewing Angle: | 120 Degree |
| IP Rate: | IP65 | IK Rate: | IK08 |
| High Light: | LED Tri Proof Light,Triproof LED Light |
||
Product Description
*Slotted iron Board, excellent heat dissipation.
*Driver: Osram; Meanwell or other Chinese brand options.
*IP65/IP66, IK08, and 850 degrees glow wire test requirement.
*Microwave sensor and PIR sensors, emergency kits, etc. It can be easily available and installed.
*Modular installation,save labor cost.
*Suitable for supermarket, warehouse, underground parking place, garage, productionplant, suitable for outdoor and wet location lighting application.
| Model No | MF-T218/MF-T236/MF-T258/MF-T270 |
| Input voltage | AC100-277Vac 50hz/60hz |
| Power(watt) | 20W/40W/60W/80W |
| Product size(mm) | 2ft(600mm)/4ft(1200mm)/5ft(1500mm)/6ft(1800mm) |
| Color temperature | Warm White(3000K-4500K), Pure White(5000K-5500K), Cold White(6000K-6500K) |
| LED Chip | SAMSUNG |
| Luminous Flux (lm) | 140LM/W±10% |
| CRI(Ra) | >85 |
| Lifespan | ≥50000hrs |
| Beam Angle | 120° |
| Material | Aluminum + PC |
| Operating Temperature | -20°C ~40°C |
| IP | IP65 |
| IK | IK08 |
| Certificate | CE/RoHS |
| Warranty Period | 5 years |
| Product Code | Dimentions(LxWxH)(mm) | Q'ty/ctn | Clips | LF(mm) | Inner Box(mm) | Outer Box(mm) | G.W./CTN | N.W./CTN |
|---|---|---|---|---|---|---|---|---|
| MF-T218 | 600x125x88 | 6 | 6 | 260-300 | 660*130*95 | 680*280*310 | 8.5kg | 1.3kg |
| MF-T236 | 1200x125x88 | 6 | 10 | 800-860 | 1260*130*95 | 1280*280*310 | 14.6kg | 2.16kg |
| MF-T258 | 1500x125x88 | 6 | 12 | 1080-1150 | 1560*130*95 | 1580*280*310 | 17kg | 2.5kg |
| MF-T270 | 1800x125x88 | 4 | 16 | 860-1050 | 1860*130*95 | 1860*280*210 | 14kg | 3.2kg |
Suitable for supermarket, warehouse, underground parking place, garage, productionplant, suitable for outdoor and wet location lighting application.
