20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium

Contact Now

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium

Minimum Order Quantity :	1PCS	Delivery Time :	depends on order
Supply Ability :	5000pcs/months

Place of Origin:	China	Brand Name:	MF
Certification:	CE,RoHs,SAA	Model Number:	MF-FLRA-xxW

Detail Information
POWER:	20-400W	CCT Range:	4000K
Voltage Range:	100-277V	Warranty:	5Years
IP:	IP66	Operation Temperature:	Ta=40
Life Hours:	50000H	LED Driver:	Meanwell/Sosen
Efficiency:	130lm/W	LED Brand:	Lumileds
Brackrt Material:	Galvanized Iron	CRI:	>70/80
THD:	<15%	Starting Time:	<0.5S
Switching Cycle Before Failure:	>100,000times
High Light:	20-400W LED Flood Light , IK08 LED Flood Light , LED Flood Light with angle bracket

Product Description

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 0
FEATURES

1.IP66 Waterproof/dust proof/explosion proof/IK08
2.Pure Aluminum shape good at heat dissipation
3.Angle Bracket,easy to install by drill
4.Easy replacement and installation
5.Phi-lips SMD 3030 Ra>80/ R9>0/ SDCM<6
6.100,000 times switching cycle before failure
7.Total harmonic distortion(THD)<15%

Matters needing attention
1.Before installing the lighting fixtures,please read this instruction manual carefully.
2.The lighting fixtures should be intalled,connected and tested by certified electrician based on the local regulations
3.Lamps should always be installed or replaced carefully
4.Please check the local voltage in accordance with the product requirements before installation
5.Revamping only can be done when the power is off and the lamp is completely cooled down
6.When clean the lamp,make the power off and let it cool down completely,clean the fixture with a soft colth and a standard PH neutral detergent,stainless steel should be maintained regularly.
7.Don't cover the fixtures with flameable materials
8.Replace shouldbe made by the manufaturer or his service agent or certified electrician in order to avoid a hazard

Temperature Characteristics t-ambient 25ºC.

Temperature

Operating -20~+45ºC

Storage -40~+60ºC

Electrical Characteristics

Input Voltage:AC100-277V 50/60Hz

PF:>0.93

Power Efficiency:>=0.90

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 2

Model NO.	Power(W)	Light Source	LED QTY(pcs)	CCT(K)	Lumen(lm/w)	CRI	Beam Angle
20W	20	3030	16	4000K	130	>70/80	120°
30W	30		32
50W	50		48
100W	100		96
150W	150		160
200W	200		240
250W	250		240
300W	300		320
400W	400		510

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 3

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 4

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 5

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 6

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 7

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 8

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 9

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 10

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 11

Outdoor Area Lighting:

LED flood lights are widely used to illuminate large outdoor areas such as parking lots, stadiums, sports fields, and industrial yards. They provide bright and uniform lighting, enhancing safety and visibility.

Building Facades and Monuments:

LED flood lights are used to highlight architectural features, facades, and monuments of commercial buildings. They can be strategically positioned to create dramatic lighting effects and draw attention to the structure.

Signage and Billboards:

LED flood lights are ideal for illuminating signage and billboards. They offer high brightness and uniform light distribution, ensuring clear visibility of advertisements and promotional messages, even from a distance.
Warehouses and Industrial Facilities:

LED flood lights are commonly used in warehouses, factories, and industrial facilities to provide bright, well-distributed lighting for improved safety and productivity. They can be mounted on high ceilings to cover large areas effectively.
Retail Spaces:

LED flood lights are employed in retail stores, shopping malls, and showrooms to create an inviting ambiance and highlight product displays. They can be used to accentuate specific areas or products, enhancing the overall shopping experience.
Outdoor Events and Festivals:

LED flood lights are extensively used for temporary lighting setups during outdoor events, festivals, concerts, and exhibitions. They offer high-intensity lighting that can be customized to suit different requirements.
Security Lighting:

LED flood lights play a crucial role in commercial security applications. They are used to illuminate parking lots, building perimeters, and sensitive areas to deter intruders and enhance surveillance camera visibility.

Sports Lighting:

LED flood lights are widely used for sports field lighting, including football fields, tennis courts, basketball courts, and outdoor recreational spaces. They provide high-quality lighting, ensuring optimal visibility for players and audiences.
Hospitality and Hotels:

LED flood lights are employed in hotels, resorts, and hospitality establishments to illuminate outdoor areas, including gardens, pathways, and entrances. They create a welcoming environment and enhance safety for guests.
Exhibition and Trade Shows:

LED flood lights are popular for illuminating exhibition booths and trade show displays. They can be easily installed and adjusted to highlight specific products or create a desired atmosphere.

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 12

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 13

20-400W IP66 IK08 5years Warranty LED Flood Light With Angle Bracket For Tunnel Airports Stadium 14
