Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 66*23*24CM/25pcs/CTN, G.W: 12.3Kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, Paypal,L/C Supply Ability : 20,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS Model Number: MF-T218/MF-T236/MF-T258/MF-T270

Detail Information

Product Code: MF-T218/MF-T236/MF-T258/MF-T270 Item Type: Tri Proof Light/Vapor Tight Light
Power: 20W/40W/60W/80W Luminous Efficiency: 140lm/w
LED Type: SMD2835 LED Chip Brand:: SAMSUNG
Viewing Angle: 120° Standard Warranty: 5 Years
High Light:

LED Tri Proof Light

,

Triproof LED Light

Product Description

Led Vapor Tight Fixture Ip65 Tri Proof Led Light 20w 40w 60w 80w Led Vapor Tight Light Waterproof Led Light
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 0


  1. IP65 Tri-proof LED Light Fixture
  2. Input: AC 100-277V, 50/60Hz
  3. Luminous Flux: 140lm/w±10%
  4. CRI: >85
  5. PF: >0.95
  6. Lifespan: ≧50000Hrs
  7. IP rate: IP65
  8. IK rate: IK08
  9. Viewing Angle:120°


Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 1

  • The LED lighting solution boasts a slotted iron board design that enhances heat dissipation, maximizing energy efficiency and lifespan.
  • Offers a choice of high-quality drivers, including Meanwell and other Chinese brands, for customized performance and reliable operation, meeting the specific needs of customers.
  • Meets strict requirements for IP65/IP66, IK08, and the 850-degree glow wire test, ensuring safety and durability in harsh environments, reducing maintenance and replacement costs.
  • Comes equipped with microwave and PIR sensors, emergency kits, and other convenient features that improve functionality and ease of use, enhancing overall user experience.
  • Boasts a modular installation design that simplifies setup and maintenance, saving on labor costs and reducing downtime.
  • Suitable for a broad range of lighting applications, such as supermarkets, warehouses, garages, production plants, and outdoor and wet locations, providing versatile lighting solutions for various settings.
  • Overall, it is a dependable and efficient lighting option that can meet the diverse needs of various settings, delivering a high-quality and cost-effective lighting solution.

Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 2

Model No MF-T218/MF-T236/MF-T258/MF-T270
Input voltage AC100-277Vac 50hz/60hz
Power(watt) 20W/40W/60W/80W
Product size(mm) 2ft(600mm)/4ft(1200mm)/5ft(1500mm)/6ft(1800mm)
Color temperature Warm White(3000K-4500K), Pure White(5000K-5500K), Cold White(6000K-6500K)
LED Chip SAMSUNG
Luminous Flux (lm) 140LM/W±10%
CRI(Ra) >85
Lifespan ≥50000hrs
Beam Angle 120°
Material Aluminum + PC
Operating Temperature -20°C ~40°C
IP IP65
IK IK08
Certificate CE/RoHS
Warranty Period 5 years


Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 3
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 4
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 5Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 6Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 7Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 8
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 9


Product Code Dimentions(LxWxH)(mm) Q'ty/ctn Clips LF(mm) Inner Box(mm) Outer Box(mm) G.W./CTN N.W./CTN
MF-T218 600x125x88 6 6 260-300 660*130*95 680*280*310 8.5kg 1.3kg
MF-T236 1200x125x88 6 10 800-860 1260*130*95 1280*280*310 14.6kg 2.16kg
MF-T258 1500x125x88 6 12 1080-1150 1560*130*95 1580*280*310 17kg 2.5kg
MF-T2570 1800x125x88 4 16 860-1050 1860*130*95 1860*280*210 14kg 3.2kg


Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 10
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 11
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 12
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 13 Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 14 Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 15 Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 16 Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 17
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 18
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 19
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 20
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 21
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 22
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 23
Suitable for supermarket, warehouse, underground parking place, garage, productionplant, suitable for outdoor and wet location lighting application.
Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 24Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 25Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 26Led Batten Light Led Vapor Tight Fixture Ip65 Tri Proof Led Light Led Vapor Tight Light Waterproof Led Light 27
