2ft 4ft 5ft 140lm/W IP66 LED Tri Proof Light 90min Emergency With Motion Sensor
Contact Person : Claire Li
Phone Number : 86-15999718117
WhatsApp : +8615999718117
| Minimum Order Quantity : | 10PCS | Price : | 19.5-20.0USD/PCS |
|---|---|---|---|
| Packaging Details : | L632*W240*H245 /4pcs/CTN, G.W: 9Kg/CTN | Delivery Time : | 7-10 days delivery time |
| Payment Terms : | T/T, Western Union, Paypal | Supply Ability : | 20,000pcs/Month |
| Place of Origin: | China | Brand Name: | MF |
|---|---|---|---|
| Certification: | CE, RoHS | Model Number: | MF24-600 |
|
Detail Information |
|||
| Power: | 24W/36W/48W/34W/54W | Material: | PC + Stainless Steel Clip |
|---|---|---|---|
| Length: | 600mm | IP Rating: | IP65 |
| Input Voltage: | AC 100V-240V / AC 100-277V/DC12/24V | Lumen Efficiency (Lm/w): | 130LM/W |
| CRI: | >80 | Beam Angle: | 120 Degree |
| Led Chip: | Epistar | Warranty: | 3 Years |
| High Light: | 130LM/W LED Tri Proof Linear Light,Tri Proof Linear Light 24W,LED Tri Proof Lights 36W |
||
Product Description
130LM/W LED Whearhouse Parking Lot Tri Proof Light Linear Light 24W 36W 48W 54W
Data sheet Download:MF24-600 LED tri-proof Light Technical data sheet....
Data sheet :
| Optical Data | Electrical Data | ||
| LED Type | Everlight SMD chip | Power Supply | CE driver |
| System Efficacy | 130lm/W(CCT=5000K) | Input Voltage | 100~240VAC |
| Luminous Flux | 2600lm(CCT=5000K) | Power Frequency | 50~60Hz |
| CCT | 3000K/4000K/5000K/6000K | Output Voltage | 28.8~48VDC |
| Beam Angle | 120° | Output Current | 1.4A(Constant Current) |
| CRI | Ra80 | Power Efficiency | >90% |
| System Efficiency | >90% | Power Factor | >0.94 |
| Total Harmonic Distortion | <10% | ||
| Others | |||
| System Power Consumption | 24W | Junction Temperature(Tj) | <65°C(Ta=25°C) |
| LED Power Consumption | 20W | Storage Temperature | -40~+70°C |
| Fixture Material | ABS Difusor Material Polycarbonate Acid |
Operating Temperature | -30~+50°C |
| Ingress Protection | IP65 | Operating Humidity | 15~90%RH |
| Luminaire Net Weight | 1.0±0.3kg | Dimensions | L600XW95XH80mm |
| Life Span | >80000Hrs(Ta=25°C@L70) | Export Carton Size | 632X243248mm,4PCS/CTN |
| Optional Info. | |||
| Installation Method | Ceiling/ Hang Mounting | ||
| Fixture Color | Grey | ||
| Intelligent Control | N/A | ||
Features Details:
1. Input Voltage:AC220-240V,50/60Hz.
2. Driver: Lifud or other options.
3. Reflector:MCPCB or PCB for your option.
4. Body and diffuser could meet the IK08,and 850 degree glow wire test requirement.
5. Perfect replacement for the whole set of T8 fluorescent lighting fixture.
6. Save up to 60% in electricity consumption compared to fluorescent lighting fixture.
7. Lifetime: 3 Years.
8. Lightweight body material ,corrosion resistant,waterproof and dustproof.
9. Easy Installation with fast connection design,shorten the installation process and save labor cost. Suitable for supermarket,underground
10. It could be fitted with the Microwave sensor,fitted with the Emergency battery to meet the requirement
Offering Emergency battery : 10W 90min or others are available
Driver : LiFud Driver, OSRAM, driver or other options.
Can be fitted with the Microwave sensor , PIR sensor
Green, Red, Blue Color temperature are available.
Normal white light.
Packing Information :
Using the strong boxes for the package, there is a inner box with a set of lamp. 6 sets of lamp for outer box.
Applications:
Car washing yard,Parking Lot ,Meat processing ,Farm, Food processing yard,Low temperature storage room , Department store ,Railway stations, Bus stations, Tunnels .......
