IP65 Triproof LED Linear Lights Dimmable For Food Factory

Minimum Order Quantity : 10PCS Price : USD28.5-39.5/PCS
Packaging Details : Standard brown carton box packing, 66*35*33cm/6pcs, N.W:7.2KG, G.W:8.0KG Delivery Time : 2 weeks
Payment Terms : L/C, T/T Supply Ability : 5000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS Model Number: MF-LTP20A-2FTSensor

Detail Information

Power: 20Watt/40Watt/60Watt Length: 2ft/4ft
Input Voltage: AC100-277V, 50/60Hz PF: >0.9
CRI: 80Ra+ Beam Anle: 120 Deg
IP Rating: IP65 Warranty: 3 Years
Lumen Efficiency: 130LM/W Dimmable: 0-10V
Sensor: Microware Sensor(On/off Version)
High Light:

Triproof LED Linear Lights

,

Dimmable IP65 LED Linear Lights

,

Food Factory IP65 Triproof LED Light

Product Description

LED Linear Tri Proof Light IP65 Waterproof LED Lights Dimmable

Main Features:



1. The Vapor Tight light is a Cost saving, energy efficient alternative to traditional fluoresent tubes.
2. Easy installation design.
3. Suit for Damp/Wet location.
4. Water-proof, dust-proof, corrosion proof, full polycarbonate LENs and non-corrosive polycarbonate body, can be used for food factory.
5. The options of 3 CCT selection and 3 Wattage selection to provide flexibility to customer.



IP65 Triproof LED Linear Lights Dimmable For Food Factory 0


Ordering Information:

 Microwave Sensor Version

Model No

Power Length Lumens CCT Remark Size
MF-LTP20A-2FT Sensor 20W 2ft 130lm/w 3000k/4000K/5000K


Microwave Sensor

on/off Version

0-10V Dimming

600*100.7*77mm
MF-LTP40A-4FT Sensor 40W 4ft 130lm/w 1200*100.7*77mm
MF-LTP60A-4FT Sensor 60W 4ft 130lm/w 1200*100.7*77mm



CCT & Watt Selectable -Standard

Model No Power Length Lumens CCT Remark Size
MF-LTP20S-2FT



20W

2ft 130lm/w 3000k/4000K/5000K


No Flicker

0-10V Dimming

600*100.7*77mm
MF-LTP40S-4FT



40W

4ft 130lm/w 1200*100.7*77mm
MF-LTP60S-4FT



60W

4ft 130lm/w 1200*100.7*77mm




CCT & Watt Selectable -Microwave Sensor Version

Model No Power Length Lumens CCT Remark Size

MF-LTP20G-2FT

Sensor

20W 2ft 130lm/w 3000k/4000K/5000K


Microwave Sensor

on/off Version

0-10V Dimming



600*100.7*77mm

MF-LTP40G-4FT

Sensor



40W

4ft 130lm/w 1200*100.7*77mm

MF-LTP60G-4FT

Sensor



60W

4ft 130lm/w 1200*100.7*77mm


Microwave Sensor Information:

Sesor Parameters Operaton Frequency

  5.8GHz7±5MHz,ISM Band.

Transmitting Power   0.5mW Max.
Hold time   5s/30s/1min/3min/5min/10min/20min/30min
Stand-by Dim Level

  10%(1.4-1.6V),20%(1.9-2.1V), 30%(2.9-3.1V),

  50%(4.9-5.1V)

Twilight Time   0S/10S/1min/3min/5min/10min/20min/30min/+
Detection Area   25%/50%/755/100%
Daylight Sensor

  5lux/15lux/30lux/50lux/100lux/150lux/Disable

  Daylight Priority; ON/OFF value

  (5lux/15lux/30lux/50lux)/150lux

  100lux/200lux

  150lux/300lux

Detecting Radius   ≧4m(Mounting height 3m, moving speed 0.3m/s)
Mounting Height   6m Max
Detecting Angle

  150°



Luminous intensity distribution diagram:                Factory Lighting: Workshop, Warehouse ,Storage Rack, ETC


IP65 Triproof LED Linear Lights Dimmable For Food Factory 1  IP65 Triproof LED Linear Lights Dimmable For Food Factory 2



What is the LED Tri proof light ?


LED Tri Proof Light products means water-proof, dust-proof, and corrosion-proof. And this will be through the anti-oxidation and anti-corrosion materials and the silicon seals.High durability since the double insulation of the connector clip makes sure the safety of the circuit. The silicon seals eliminate the dust and water entry.



MF-LTP is adurable and eco-friendly alternative lighting system to traditional fluorescent tubes. Also, the design of LED vapor light is to withstand severe environments and will help you reduce your energy consumption by up to 80%.



As well as, MF-LTP LED led tri-proof lights are specifically withstanding conditions susceptible to water, dust and corrosion impacts. GS LIGHT tri proof led are Incredibly durable and long lasting, they are highly resistant to heavy impacts and can withstand temperature variations of up to 50°C.
