Home ProductsLED Vapor Tight Lights20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor
20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor
20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor
20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor
Contact Now

20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 125.5*18.5*18.5cm/25pcs N.W:8KG , G.W:16kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, Paypal，L/C Supply Ability : 20,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS Model Number: MF-T8120

Detail Information
High Light:

Vapor Tight Parking Lot Light Fixtures

,

50w Vapor Tight Lights

Product Description

20w 40w 50w Led Parking Lot Light Fixtures Vapor Tight Lights Waterproof For Outdoor
Quick Detail:


  1. IP65 Tri-proof LED Light Fixture
  2. Input: AC 100-277V, 50/60Hz
  3. Luminous Flux: 140lm/w±10%
  4. CRI: >85
  5. PF: >0.95
  6. Lifespan: ≧50000Hrs
  7. IP rate: IP65
  8. IK rate: IK08
  9. Sensor: Motion sensor




Specifications:


Model No

 MF-T118/MF-T136/MF-T158

Input voltage

AC100-277Vac, 50hz/60hz

Power(watt)

 20W/40W/50W

Product size(mm)

2ft(600mm)/4ft(1200mm)/5ft(1500mm)/6ft(1800mm)

Color temperature

Warm White(3000K-4500K), Pure White(5000K-5500K), Cold White(6000K-6500K)

LED Chip

SAMSUNG

Base Type

 G13

Luminous Flux (lm)

140LM/W±10%

CRI(Ra)

>85

Lifespan

≥50000hrs

Beam Angle

120°

Material

Aluminum + PC

Operating Temperature

-20C ~40C

IK

08

IP

65

THD

≤15%(MAX)

Certificate

CE/RoHS

Warranty Period

5 years


 20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 0

20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 1
Product Characteristics



*Slotted iron Board, excellent heat dissipation.
*Driver: Osram; Meanwell or other Chinese brand options.
*IP65/IP66, IK08, and 850 degrees glow wire test requirement.
*Microwave sensor and PIR sensors, emergency kits, etc. It can be easily available and installed.
*Modular installation,save labor cost.
*Suitable for supermarket, warehouse, underground parking place, garage, productionplant, suitable for outdoor and wet location lighting application

*Radar technology automatic control induction, capture your every move in the dark.



Product Detail:

20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 220w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 3


 20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 4

Dimension:
20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 5


20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 6

 20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 7
Clasp type:
20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 8
28trips/SMD2835:
20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 9

20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 10
Luminous Intensity Distrbution Diagram:
20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 11
Applications:

Emporium, superstore, school, factory, underground parking, passageway, hospictal, official large building and so on public place lighting.

20w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 1220w 40w 50w LED Parking Lot Light Fixtures , Vapor Tight Lights Waterproof For Outdoor 13



FAQ:

Q1: Are you a manufacturer?

MF: Yes,we have our own factory with over 14 years R&D and manufacture experience base on ISO quality management since 2009.


Q2. Can I have a sample order for  LED Vapor Tight Light ?
MF: Yes, sample order to test and check quality is welcomed. Mixed samples are acceptable.


Q3. How about the lead time of LED Vapor Tight Light ?
MF: 3-7 days for sample order, 15-25 days for mass production order base on order quantities.


Q4: How do you ship the finished production ?
MF:By SEA, AIR or Express(DHL,UPS,Fedex,TNT,etc) are optional.


Q5: Is it OK to print my logo on  LED Vapor Tight Light ?
MF:We provide OEM service to our customers, we can help to make the label and color box according to your requirements.


Q6: How to proceed an order for  LED Vapor Tight Light?
MF:Firstly, please let us know your detail requirement and application environment. secondly we will recommend some suitable products and solutions to you according to your request. Thirdly, after confirm all the details, customers will issue the purchase order and make the payment to confirm, then we start for the production and arrange the shipment.


Q7: How to deal with the defective?
MF: AlI of our product are produced in strict quality control system, the defective rate is less than 0.2% according to our shipment records. We offer 5 years warranty for this product, if there is any defective during the warranty, please provide the picture or video for the working situation of the defective lights, we will ship the new lights to you within a few days or send it together with your next order.





Tag:

LED Tri-proof Light

Tri-Proof Light

Vapor Tight Light
