2ft 4ft 5ft 140lm/W IP66 LED Tri Proof Light 90min Emergency With Motion Sensor
Contact Person : Claire Li
Phone Number : 86-15999718117
WhatsApp : +8615999718117
Minimum Order Quantity : | 100PCS | Price : | Negotiable |
---|---|---|---|
Packaging Details : | 16.5*15*22cm/1pcs, G.W: 1.2Kg | Delivery Time : | Depends on orders |
Payment Terms : | T/T, Western Union, L/C, Paypal | Supply Ability : | 5,000pcs/Month |
Place of Origin: | China | Brand Name: | MF |
---|---|---|---|
Certification: | CE, RoHS,SAA | Model Number: | MF-stainless steel tri proof |
Detail Information |
|||
Application: | Parking Lot/Tunnal/Commercial/Warehouse | Feature: | Anti-corrosion/Dust Proof/Waterproof/explosion Proof |
---|---|---|---|
Material: | Auminum Stainless Steel PC | Power: | 25W 35W 50W 45W 65W |
Voltage: | AC220-240V 50/60Hz | Installation: | Easyand Quick To Installunder Cellingor On Surface |
Housing/Diffuser: | 304 Stainless Steel Housing,Tempered Glassdiffuser | Driver: | OSram / PHilip / Tridonic / Chinese Localbrand |
LED Brand: | SMD2835 / SMD3030 | CCT: | 2700-6500K (ANSI C78.377) |
CRI: | > 80 | Powerfactor: | >0.9 |
Beam Angel: | 90°/120° | Warranty: | 5 Year |
High Light: | 25w Tri Proof Light 5ft,Ik08 Led Tri Proof Light,Aluminum Led Tri Proof Light |
Product Description
2ft 4ft 5ft Ip65 Stainless Steel Aluminum 25w Ip66 Ik08 Led Tri Proof Light For Swimming Pool Farm Tunnels Warehouse
1.Technical Paramenters (Test Conditions:25C/55-%60%Humidity) | |||||
ltem Code | MF-SS-25W-600 | MF-SS-35W-1300 | MF-SS-50W-1300 | MF-SS-45W-1600 | MF-SS-65W-1600 |
Power(W)+/-10% | 25w | 35w | 50w | 45w | 65w |
Input Voltage/Frequency | AC 220-240V50/60Hz | ||||
lnstallation | Easyand quick to installunder cellingor on surface | ||||
Housing/Diffuser | 304 stainless steel housingTemperedglass diffuser. | ||||
Driver | Osram/ Philip/Tridonic/Chinese localbrand | ||||
LED Brand | SMD2835/ SMD3030 | ||||
CCT | 2700-6500K(ANSIC78.377) | ||||
CRI | >80 | ||||
5000K/Opal Diffuser | 3,500 lm | 4,900lm | 7,000 lm | 6,300 lm | 8,680 Im |
Light output(+/-3%) | |||||
Power factor | PF>0.9 | ||||
Beam Angel | 90°/120° | ||||
IP Rating | IP65 | ||||
Warranty | 5Year | ||||
Operating temp range | -20ºC~40ºC | ||||
Clips Qty(pcs) | 6 | 10 | 10 | 12 | 12 |
Product Size(mm) | 670*110*65 | 1280*110*65 | 1590*110*65 |
Detail:
Suitable for Zone 1&2 (Gas), Zone 21&22 (Dust)
High luminous efficacy - Up to 120-140 lumens per watt
0-10V dimming
Waterproof and dust-proof, without internal cleaning and
maintenance
Simple structure for easy and quick installation
Stainless steel fasteners, ADC12 aluminum housing, good corrosion resistance
Tempered glass, high light transmittance and impact resistan
Luminaire:
