Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle

Minimum Order Quantity : 1 Price : Negotiable
Packaging Details : 2450*130*105mm, 5.2kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, Paypal Supply Ability : 20,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS Model Number: MF-624

Detail Information

Power: 20W/40W/60W/80W LED Type: SMD2835
LED Chip: Optional Luminous: 130-180lm/w
Beam Angle: 120° IP Rate: IP66
IK Rate: IK08 Application: WAREHOUSE
Highlight:

Emergency Sensor LED Triproof Light

,

180lm/W LED Triproof Light

Product Description





Waterproof IP65 LED Triproof Light with Emergency Sensor 120 Deg Light Angle



Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 0




Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 1



This series of IP65-rated waterproof, dustproof, and anti-corrosive LED three-proof lights employ high-quality LED chips, boasting high luminosity and extended lifespan. With a versatile power range from 20W to 80W, they cater to diverse lighting requirements across various settings. Utilizing Crystal 2835 LED chips from Taiwan, these lamps deliver excellent color rendering (CRI 80-90) and a wide 120° beam angle for consistent and comfortable illumination. Available in a choice of color temperatures, including 3000K, 4000K, 5000K, and 6000K, they accommodate the lighting preferences for different environments. The lights feature a high power factor (PF>0.95) and come with CE-certified imported or in-house manufactured constant-current drivers, ensuring stable and dependable operation.

Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 2



Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 3

Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 4

Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 5
1.High quality LED lamp beads: Taiwan Jingyuan 2835 LED lamp beads provide high brightness and long life lighting.
2.High efficiency: High luminous efficiency, low power consumption, and high power factor to ensure the effective use of energy.
3.Multi-color temperature options: Provide a variety of color temperature options to meet the needs of different scenes.
4.Wide light Angle: 120° light Angle to ensure uniform distribution of light, reduce lighting dead Angle.
5.IP65 protection grade: waterproof and dust-proof, suitable for a variety of harsh environments, including outdoor, underground parking.
6.5 years warranty: Provide up to 5 years of quality assurance to ensure the service life and stability of the product

Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 6

Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 7

1.Urban Main Roads: Provides bright and even lighting for city streets, ensuring nighttime driving safety.
2.Parks and Landscape Lighting: Offers aesthetically pleasing and energy-efficient lighting for park pathways and landscaped areas, enhancing the night scenery.
3.Parking Lot Lighting: Provides high-intensity lighting for large outdoor parking areas, improving safety for vehicles and pedestrians.
4.Manufacturing Factories: Offers high-efficiency and low-maintenance lighting for production lines, ensuring stable operation.
5.Warehouse Centers: Provides ample lighting for warehouse areas, enhancing loading/unloading efficiency and reducing accidents.
Logistics Centers: Delivers high-intensity lighting for logistics centers, ensuring accuracy and efficiency in cargo sorting and transportation.
6.Malls and Shopping Centers: Illuminates mall corridors and public areas with bright and comfortable lighting, attracting customers and enhancing the shopping experience.
7.Hotels and Leisure Facilities: Offers warm and high-quality lighting for hotel lobbies, restaurants, gyms, and other areas, creating a comfortable and inviting environment.
8.Multi-Level Underground Parking: Provides uniform lighting for multi-level underground parking structures, reducing dark corners and improving safety for vehicles and pedestrians.

Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 8Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 9


Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 10



Model No. MF-624-20W MF-624-30W MF-624-40W MF-624-50W MF-624-60W MF-624-50W-5 MF-624-60W-5 MF-624-80W-5
Dimension(mm) 600x83x68 1200x83x68 1500x83x68
Input Voltage AC220-240V
Frequency 50Hz to 60Hz
Power 20W 30W 40W 50W 60W 50W 60W 80W
PF Conversion >0.95
Power Supply MW/MF CE TUV driver
LED Quantity 120 192 240 288 336 288 336 432
LED Brand TAIWAN EPISTAR
LED Type 2835 LED
Luminous Efficiency 2044 3082 4111 5250 6069 5163 6045 8247
Color Temperature 3000K/4000K/5000K/6000K
CRI 80-90
Beam Angle 120°
Warranty 5 Years
Approval CE RoHS
Main Materials Aluminum Housing + PC Milky Cover/Stripped Cover
IP Rating IP65
Lifespan 50000HRS
Standard Packing 6PCS/CTN 6PCS/CTN 4PCS/CTN 4PCS/CTN 4PCS/CTN 4PCS/CTN 4PCS/CTN 4PCS/CTN
G.W. 11 11 12 13 13 15 15 16
Catron Size(mm) 67x27x24 127x24x20 157x24x20


Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 11
Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 12


Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 13
Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 14Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 15

Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 16
Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 17  Waterproof IP65 LED Triproof Light With 180lm/W Emergency Sensor 120 Deg Light Angle 18


FAQ


Q1: What products do you offer?
A: We offer a wide range of products, including LED Indoor light and LED Outdoor light.

Q2: Do you offer customization services?
A: Yes, we offer
customization services for many of our products.

Q3: What are your payment terms?
A: Our
payment terms are typically 30% deposit and 70% balance before shipment,depends on product.

Q4: What is your lead time?
A: Our lead time varies depending on the product and order quantity.

Q5: What is your quality control process?
A: We have a strict quality control process in place to ensure that every product meets our high-quality standards.



after-sales issues



  • We offer a free 5-year warranty from the date of purchase, which covers any defects in materials and workmanship. This warranty does not cover damage caused by mishandling or improper use, such as failure and damage caused by unpacking the product, or failure caused by falling and touching during handling and use.
  • It is important that the product is operated in accordance with the instructions provided to prevent any failure that may occur due to improper use. Therefore, any failure caused by the failure to operate the product in accordance with the instructions is not covered by the warranty.
  • After the warranty period, we offer maintenance services at the cost of materials only for any parts that may need to be replaced. However, any additional labor costs incurred during the maintenance process will not be covered by the warranty.
  • We are committed to providing exceptional customer service and support, and our team is available to answer any questions or concerns you may have regarding the product warranty or maintenance process.
  • We believe that our warranty policy demonstrates our commitment to providing high-quality products and ensuring customer satisfaction. With our warranty, you can be confident in the quality and reliability of our product.
