Product Overview
Professional 200W LED UV light designed for multiple industrial and commercial applications including resin curing, pet urine detection, gel nail curing, and printing processes.
Technical Specifications
| Model No. |
MF-GUV-200W |
| Power |
200W |
| Frequency Range |
50Hz-60Hz |
| Product Size |
520×105×80mm |
| CRI |
80+ |
| Light Color |
Violet |
| Material |
PC + Aluminum |
| Input Voltage |
85-265V AC |
| Certifications |
CE, ROHS, CB, TUV |
| Temperature Range |
-10°C to +45°C |
| Light Lifespan |
50,000 hours |
| Product Color |
Grey/White |
| Plug Options |
EU/US/CN |
| Protection Rating |
IP43 |
| Wavelength |
UV395nm, UV365nm, UV405nm |
| Gross Weight |
3.22KG |
Additional Details
Color Options: Grey/White
Available Power Outputs: 60W/120W/200W/300W
Light Source: 120/240/360 LEDs with 3535 chip
Active Power: 60W/120W/200W/300W
Power Supply: 85-265V AC 50/60Hz
Dimming Mode: No standard dimming
Operating Temperature: -10°C to +45°C
Material Construction: PC + Aluminum
Protection Rating: IP43
Warranty: Housing - 36 months
LED Lifetime: 50,000 work hours
Key Features
- Europe and United States hot models with CB CE certification
- Patented product design with customization options
- Whole picture printing laser engraving capability
- Multiple mounting options: hanging, wall, ceiling, side mounting
- Customized patterns and wavelengths (395NM/365NM)
- Customized LOGO available for small orders
Applications
This versatile UV lamp supports numerous industrial and commercial applications including:
- 3D resin curing and glow filament applications
- Gel nail curing and beauty industry uses
- Pet urine detection and forensic applications
- Counterfeit money detection and security
- Solder joint protection in electronics
- Ink curing for printing industry
- Shadowless adhesive curing
- Photosensitive resin solidification
- Printing, repairing, and painting processes
Product Capabilities
Rapid Solidification:
Cures materials within three seconds
- Sterilization and disinfection functions
- Healing and therapeutic applications
- Quick-curing bandage technology
- Fluorescence detection capabilities
- Medical cancer cell tracking function
- Chip welding and bonding applications
- Traceless pasting technology
LED UV lights are primarily used for rapid curing of material coatings including paints, adhesives, and inks on various surfaces such as panels, tiles, glass, and furniture. UV curing delivers exceptional durability, high gloss finish, and superior resistance to weather, water, acids, and abrasion. Standard LED UV curing lamps typically accommodate workpieces up to 1000mm in length.
Customization & Support
If this product exceeds your market requirements, affecting profitability?
Contact our professional team immediately for more suitable product recommendations.
Need higher performance products?
We will source the most appropriate products for your needs in the shortest timeframe.
Require completely different exterior design?
No problem! We specialize in custom lighting solutions tailored to your specifications.
Can I print my logo on the LED light?
Yes, we provide comprehensive OEM services including custom labeling and packaging according to your requirements.
What if I receive defective products?
Our defect rate is below 0.2%. During warranty, provide evidence of malfunction and we'll ship replacements promptly.
Do you have your own factory?
Yes, we specialize in LED lighting R&D and manufacturing since 2009, operating under ISO quality management.
Can I order samples for testing?
Yes, we welcome sample orders and accept mixed samples for quality verification.
Packaging & Shipping
We support air shipment, marine shipment, and other delivery methods. Strategically located in Dongguan with proximity to major ports including Shenzhen Shekou Port, Dongguan Humen Port, and Zhanjiang Haian New Port. Also conveniently located near Shenzhen Airport, Guangzhou Baiyun Airport, and Foshan Airport. Our location benefits from extensive railway and highway networks for efficient transportation.
Our multi-layer packaging includes internal and external protection with sponge cushioning around products to minimize transit damage.
Company Profile
Ming Feng Lighting Co., Ltd is a leading LED lighting manufacturer based in Guangdong Province, China. Established in 2009 with over 15 years of LED lighting export experience. Our product range includes LED Indoor Lights (Triproof Lights, Vapor Tight Lights, Down Lights, Flat Panels) and LED Outdoor Lights (Flood Lights, High Bay Lighting, Stadium Lights, Landscape Lights, Aviation Obstruction Lights, and Search Lights. Our rapidly expanding R&D department continuously innovates to meet market demands with global partnerships.
