Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 16.5*15*22cm/1pcs, G.W: 1.2Kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, L/C, Paypal Supply Ability : 5,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS,SAA,TUV,CB,ETL,UL Model Number: MF-BEE1

Detail Information

Beam Angle: 24°/36°/45°/50°/60° Input Voltage: AC 100-240V
Power: 10W/12W/15W/20W/30W/40W CCT: 3000K/4500K/6000K
Material: Aluminum Installation: Recessed
Switch: Turn On/Off Warranty: 3 Years
Application: Shopping Mall,warehouse,Office,hotel,bedroom,restaurant IP Rate: IP40
Product Color(Ring): White/Black Housing Color: White/Black/Grey/Red
Body Material: Aluminum Type Of Connection: Terminal, 2-Pin
Mounting Location: Ceiling Mounting Diameter: 75mm/90mm/100mm/115mm/145mm/170mm
Lifespan L70/B50 At 25°C: 30000 H Luminous Efficacy: 100 Lm/W/Higher
High Light:

AC240V led spot down light

,

Square Recessed Ceiling Lamp

,

Spot LED Down Light 10W

Product Description

Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space ShowroomSpot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 0



  1. − High luminous efficacy
  2. − Direct replacement for compact fluorescent lamp downlights
  3. − Energy savings up to 60 % (compared to luminaires that use CFL lamps)
  4. − Very homogenous light − Functional design
  5. − Easy installation with fast connection
  6. − 3 years guarantee
  7. − Diameter of required ceiling cut-out: 10W 75mm,12W 90mm,15W 100mm,20W 115mm,30W 145mm,40W 170mm
  8. − Type of protection, back side: IP40
  9. − Type of protection, front side: IP44





Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 1

                       Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 2






Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 3

Electrical data:

Nominal wattage 10W/12W/15W/20W/30W/40W
Nominal voltage 100-240 V
Mains frequency 50-60 Hz
Nominal current 350.000 mA
Power factor 0.9
Protection class II
Operating mode Electronic control gear (ECG)



Photometrical data

Luminous flux 1000lm/1200lm/15001m/20001m/30001m/4000lm
Luminous efficacy 100 Im/W
Color temperature 3000 K 4500 K 6000 K
Light color (designation) Warm White
Color rendering index Ra ≥80
Beam angle 24°/36°/45°/50°/60°

                                 Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 4

Ambient temperature range -20°C~+40°C
Type of connection Terminal, 2-pin
Type of protection IP40
Dimmable No
Mounting type Recessed
Mounting location Ceiling
Application environment Indoor
Mounting diameter 10W 75mm,12W 90mm,15W 100mm,20W 115mm,30W 145mm,40W 170mm
LED module replaceable Not replaceable





LIfe Span:

Lifespan L70/B50 at 25 °C 30000 h
Number of switching cycles 15000



: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Control Gear FONTE LED OTI DALI 25/220…240/700 LT2 (Order No. 7010945)
Certificates & Standards TÜV / NOM

Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 5

Diameter(D) 10W(82mm),12W(9mm),15W(106mm),20W(123mm),30W(155mm),40W(185mm)
Length(H) 10W(82mm),12W(9mm),15W(106mm),20W(123mm),30W(155mm),40W(185mm)
Height 60.00 mm
Product weight 610.00g

                                                                    Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 6

Power D(MM) H(MM) C(MM)
10W 82 53 75
12W 96 58 90
15W 106 63 100
20W 123 68 115
30W 155 76 145
40W 185 83 170





Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 7



LED downlights are versatile lighting fixtures that find wide application in various settings.With their sleek design and energy-efficient performance, LED downlights are commonly used in residential, commercial, and hospitality environments.

In residential settings, LED downlights are often installed in kitchens, living rooms, and bedrooms to provide ambient or task lighting. They offer a modern and stylish lighting solution while consuming less energy compared to traditional lighting options. LED downlights can create a warm and inviting atmosphere, enhancing the overall aesthetic appeal of the space.

In commercial spaces such as offices, retail stores, and showrooms, LED downlights are utilized to illuminate the area effectively. These downlights offer a focused and uniform light distribution, making them ideal for highlighting specific areas or products. LED technology ensures long-lasting performance, reducing maintenance costs and providing consistent lighting quality.

Hospitality venues, including hotels, restaurants, and bars, benefit from LED downlights to create a welcoming and visually appealing ambiance. These downlights can be used for general lighting, accenting architectural features, or accentuating artwork and displays. Additionally, the dimmable feature of LED downlights allows for flexible lighting control, enabling the adjustment of light levels to create different moods and atmospheres.




Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 8




Overall, LED downlights are widely used due to their energy efficiency, long lifespan, and versatility. They offer excellent lighting performance, enhance aesthetics, and contribute to energy savings, making them a popular choice for a range of applications in both residential and commercial settings.

Hospitality: LED downlights are commonly used in hotels, resorts, and spas to create a soothing and luxurious atmosphere in lobbies, corridors, guest rooms, and common areas. They provide soft, warm illumination that enhances the guest experience and adds a touch of elegance to the space.
Museums and Galleries: LED downlights are preferred in art galleries and museums to illuminate exhibits and artwork with precision and accuracy. Their directional lighting helps to highlight the details and colors of the art pieces while minimizing heat and UV emissions that could
potentially damage the artwork.
Showrooms: LED downlights are ideal for showcasing products in retail showrooms, car dealerships, and jewelry stores. Their focused beam and adjustable angles allow for effective accent lighting, drawing attention to specific merchandise and creating a visually appealing display.

Offices and Workspaces: LED downlights are widely used in office environments to provide bright, glare-free illumination for workstations, conference rooms, and common areas. They offer a comfortable working environment, reduce eye strain, and contribute to better productivity.
Educational Institutions: LED downlights are employed in schools, universities, and libraries to create conducive learning environments. They provide uniform lighting in classrooms, libraries, and study areas, enhancing concentration and visual comfort for students and teachers.
Healthcare Facilities: LED downlights are utilized in hospitals, clinics, and healthcare facilities for general lighting in corridors, waiting areas, and patient rooms. They offer a clean and bright light source, promoting a sense of well-being and aiding in accurate medical examinations. Outdoor Spaces: LED downlights with suitable IP ratings can be used for outdoor applications such as building facades, pathways, gardens, and parking areas. They provide efficient and durable lighting solutions that enhance safety and security while reducing energy consumption.

Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 9

Packing and Production:



The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit

Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 10

Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 11

Spot LED Down Light 2.5/3/3.5/4/5/6 Inch 10W-40W Square Recessed Ceiling Lamp Hallway Closet Garage Space Showroom 12
