45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor

Contact Now

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor

Minimum Order Quantity :	100PCS	Price :	Negotiable
Delivery Time :	Depends on orders	Payment Terms :	T/T, Western Union, L/C, Paypal
Supply Ability :	5,000pcs/Month

Place of Origin:	China	Brand Name:	MF
Certification:	CB, DLC, SAA	Model Number:	MF-SLXXXW-D

Detail Information
Power:	45W 75W 100W 150W 200W 250W	Input Voltage:	AC100-277V
LED Chips Brand:	Lumiled3030	Lifespan:	50, 000hrs
Lumens:	175lm/W	With Light Source:	With Light Source
IP Rating:	IP65	Storage Temperature:	-40~+70°c
PF:	0.95	CRI:	Ra≥80
Warranty:	7 Years	CCT:	3000K-6500K
Lamp Body Material:	Aluminum	Power Supply:	AC
High Light:	150W LED Street Light , Waterproof LED Street Light , 250W LED Street Light

Product Description

45W 75W 100W 150W 200W 250W IP65 IK10 3000-6500K AC100-277V Owl-3 Family LED Street Light for Highway/Street/Roadside

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 0

Specifications:

WATT	75W	100W	120W	150W	200W	250W
LUMEN OUTPUT	13125lm	17500lm	21000lm	26250lm	35000lm	43750lm
LED QUANTITY	96pcs	96pcs	96pcs	96pcs	288pcs	360pcs
EFFICACY	175LM/W
LED CHIP	Lumiled 3030
Light Angle	25°/60°/90°
CCT&CRI	3000K-6500K ≥80
Voltage	AC100-277V/347V/480V 50/60Hz
Certification	DLC Premium SAA VEET CB

Descriptions:

ENERGY SAVING CONTROL OPTION- DIM - 0-10 volt dimming enabled with controls by others.

EXPECTED LIFE - Minimum 100,000 hours depending upon the ambient temperature of the installation location.

LEDS - Select high-brightness LEDs in Warm White, Neutral

White or Cool White color temperature, 80 CRI.

DISTRIBUTION/PERFORMANCE- High performance, multifaceted, reflector provides uniform Forward Throw (FT) distribution with sharp backlight cutoff. Photometric data is

tested in accordance with IESNA guidelines.

HOUSING - One-piece, die-formed aluminum housing contains factory prewired driver in a gasketed, weather-resistant wiring compartment.

Hinged wiring access door (with safety lanyard) located underneath.

Fixture is IP65 rated

OPTICAL UNIT - Precision engineered lenses made of optical grade Mitsubishi polycarbonate for maximum light

intensity. Come standard with field-rotatable light.

Key Features:

· Waterproof IP65, high thermal conductivity housing

· Beam angle TypeII, TypeIII, TypeIV, TypeV, 25° 60°

90° PC+glass lens

· Support smart control: photocell, motion sensor, lora, zigbee etc

· High lumen SMD3030 chip, luminous efficacy 175Im/w

· Ultra slim heat sink design makes the lamp lighter and betier in heat dissipation

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 4

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 5

Light Distribution Curve:

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 6

Dimensions:

Part Number	Dimensions(MM)	N.G(KG)	G.W (KG)	Package Size(MM)
75W	599 L x 162 W x 108 H	3.6kg	4.2kg	641 L x204 W x 311 H
100W	599 L x 162 W x 108 H	3.6kg	4.2kg	641 L x204 W x 311 H
120W
150W
200W	742.5 L x 217 W x 108 H	5kg	5.8kg	784.5 L x259 W x 311 H
250W

Production Line:

Ming Feng Lighting manufactures LED street lights with precision and expertise. The production process begins with the careful selection of high-quality materials. Advanced manufacturing techniques are employed to ensure the efficiency and durability of the lights.

First, the LED chips, known for their energy-saving properties, are meticulously placed on circuit boards. These boards undergo thorough testing to ensure optimal performance.

Next, the assembled components are housed in rugged and weather-resistant casings, designed to withstand the harshest outdoor conditions.

Quality control measures are implemented at every stage of production. Rigorous testing procedures guarantee that each LED street light meets the highest industry standards.

Ming Feng Lighting's commitment to innovation and reliability has positioned them as a leading provider of LED street lights. Their dedication to producing top-quality products ensures long-lasting performance, energy efficiency, and customer satisfaction.

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 7

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 8

Applications:

Ideal for highways, squares, schools and other outdoor lighting place.

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 9

Viaducts, urban streets

Overpasses, sidewalks

45W 75W 100W 150W 200W 250W IP65 Waterproof Garden Roadway Floodlights LED Street Light With Photocell Motion Sensor 11

FAQ:

Q1: What do you sell?
A1: We provide good quality of floodlight, high bay light, explosion proof light, tri-proof light, downlight, and other lighting products, as well as responsible services and reliable after-sales warranty.

Q2: Is it OK to print my logo on led light product?
A2: Yes. We provide ODM and OEM services. Please inform us formally before our production and confirm the design firstly based on our sample.

Q3: How to deal with the faulty?
A3: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

Q4: Can I have a sample order for led light?
A4: Yes, we welcome sample order to test and check quality. One sample or mixed samples are acceptable.

Q5: How long time to ship the goods if place an order?
A5: Usually 7 days for sample or small order,15 working days for bulk order, but sometimes depend on the order quantity.
