Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle

Minimum Order Quantity : 50PCS Price : Factory price
Packaging Details : 54*41*49cm/36pcs, G.W: 27.5KG,N.W:26.5 Delivery Time : 1 week for sample order, 2 weeks for mass order
Payment Terms : T/T, Western Union, Paypal, L/C Supply Ability : 10,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS Model Number: MF-B090015

Detail Information

Power: 15W Input Voltage: 85-265Vac, 50/60Hz
Luminous Flux: 1980lm@3000K, 2100lm@4000K, 2200lm@5000K LED Chip: Cree COB(CXA1512)
Beam Angle: 10°/15°/24°/38° CRI: >80Ra
LED Driver: Lifud Driver Power Factory: >0.95
Head Type: Adjustable/Fix Head Housing Color: White RAL9003
High Light:

led ceiling lights

,

led down light

Product Description



Anti-glare 10Watt COB LED Downlights ,with degree adjustable, 10°/15°narrow beam angle

 Anti-glare 10Watt COB LED Downlights Spec down load: MF-B090015 Spec -15W.pdf




Technical data:



Input voltage 220-240Vac, 50hz/60hz
Product Size 110*135mm
Cut out Size 90mm
Power(watt) 15W
Color temperature 3000K / 4000K / 5000K
LED Chip Cree COB(CXA1510)
LED Driver Lifud
PF ≥0.95
Housing Colour White RAL9003
Luminous Flux (lm) 1350lm@3000K, 1400lm@4000K, 1500lm@5000K
CRI(Ra) >83
Lifespan 50000hrs
Beam Angle 10°/ 15°/ 24°/ 38°
Material Aluminum Alloy
Operating Temperature -200C ~500C
Head type Adjustable/Fix head
IP IP44
Certificate CE/ RoHS
Warranty Period 5 years





Description:



1. LEDS:  Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle 0
Use the latest high-efficiency COB CREE CXA1820 leds, make the light output
efficiency up to 100LM / W, color rendering index up to more than 85.


2. LED Driver:  Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle 1
Using certified TUV,CE, ROHS Lifud driver, stable performance, power factor up to 0.95 and above. Set the stability working environment for the 30W COB LED Down lights, and keep long lifetime.


3. Reflector: Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle 2

High reflectivity materials reflector cup imported from Japan, anti-glare sand reflectivity up to 95%.



4. Face ring: International standard RAL9003 dusting white, high-end atmosphere, beautiful. At the same time can be customized color too.

5. Spring and  Screws: corrosion-resistant, anti-rust treatment.
6. Applications: this CREE COB LED Down lights, 22W@100LM/W widely used in automobile exhibition, clothing shop, furniture store, shoe stores, jewelry store, exhibition, art exhibition hall, the villa, and some outdoor place.





Anti-glare 10Watt COB LED Downlights​​ characters:



1.Much competitive price and short lead time.7 days for sample order, 15 days for mass order quantity 500pcs.
2. Good heat dissipation: stable body, aluminum housing, aluminum print circuit board.high-end atmosphere, beautifu housing color.
3. Safe experience: Isolated driver, input voltage: AC85-265V/50-60Hz, the voltage is avaliable for different countries'request.

4.Eyes protected: UGR<19 Light ray is emited from edge, making the light softer and evener, which protect the eyes from direct rays of the lights.
5. Less power consumption: LED light source provide a lot more luminum flux than the original light source while they cost less power consumption at the same condition.
6. Led light saving 80% electricity compare to the HPS and Metal Halide lamp.
7. Environmental friendly-fully recyclable, no mercury or other hazardous materials





Anti-glare COB LED Downlights Power Range:



Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle 3



Anti-glare 10Watt COB LED Downlights​ dimension:



Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle 4







Anti-glare 10Watt COB LED Downlights head options:



Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle 5







Application:



Anti-glare 15Watt ceiling spotlights, Rotatable, 10°/15°narrow beam angle 6
