IP67 160LM Per Watt LED Flood lights Industrial, 150W/400W600W billboard lights
MingFeng Lighting Company has great professional on producing LED flood lights, here we would like to recommend our MF-FL series flood lights.
We can produce it in 80W,100W,150W,200W,250W,300W,400W,500W,600W available.
Different beam angle 30 degree, 60 degree, 90 degree, 60*135 degree, 85*135 degree, 70*140 degree.
Working Voltage is 100-240Vac.
Lamp luminous Efficiency is 130LM/W or 160LM/W
Led light Source is 3030 or 5050 chip; Meanwell Driver.
Our this FL LED Flood Lights comes with a waterproof rubber ring inside. Its well-designed het sink with fins helps air to flow and prevent water to accumulate. Each LED module is totally-enclosed. 90Deg preventing water to permeate. Additionally, It gets a IK10 impact-resistant grade, which provides better protection for outdoor usage.
Technical data :
|Product Name :
|Input Voltage :
|Beam Angle :
|LED Type :
|| 3030 or 5050
||-30℃ to 45℃
||-40℃ to 60℃
|System Efficiency :
150W IP67 160LM Per Watt LED Flood lights Industrial Dimensions:
1. Different power and house color (Black/Silver/Grey)for choose , 80W/100W/150W/200W/250W/300W/400W/500W/600W.
2. 3 type bracket with angle adjustable for options, heavy duty design.
3. Strong Struction , Good heat Sink, IK10, Meanwell Driver , a kind of great LED flood light Industrial
4. Warm white/White/RGB color temperature available.
5. Suitable for different installation.
IP67 billboard Lights Installation Steps:
Step1: Open the box and check your product, In case of damage contact your merchandiser.
Step2: Fasten the brackets on the wall/surface with stainless steel screws.
Step3: Adjust the floodlighttodirect the light in desired direction beforetighteningthe screws.
Step4: Be sure to connect the wires correctly. Brown-Live,Blue-Null, Yellow/Green-Grounding.
Make surepower cord was fixed for anti-pull purpose,and the connection is waterproofinoutdoor
Step5: Switch the voltage on and check to see that the floodlight works properly.
Parking lots, billboards, playgrounds (soccer fields, tennis courts, etc.), exterior lighting, amusement parks, airports, Bridges, tunnels, etc
