200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor

Minimum Order Quantity : 1pcs Price : Ex-work/FOB price
Packaging Details : Depends on each model Delivery Time : 2 weeks
Payment Terms : T/T, Western Union, Paypal Supply Ability : 1000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE,RoHS Model Number: MF-TGD-B150W

Detail Information

Input Voltage: 90-305V~50/60Hz Power: 10W 20W 30W 50W 100W 200W
Luminous Efficiency: 140~150lm/W IP Rating: IP66
CCT: 3000K-4000K-5700K Beam Angel: 120°
Driver: International Driver Brand Body Color: Black/Silver
Housing: Powder Coated Aluminium Alloy Chips: Lumileds
Dimming: 1-10V, Dali2.0 Precision Aiming Device: MF
High Light:

IP66 Waterproof Lamp Projector Floodlight

,

RGB Flood Lamp Projector Floodlight

,

200W High Power LED Flood Light

Product Description

200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor



200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 0


200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 1


Die-casting technology by ADC12, excellent thermal management, reduce the temperature difference and ensure the lumen depreciation.

4mm tempered glass, Integrated Breather Valve: Balances The Internal & External Temperature and Humidity

Offset bracket design, Racked Angle ±120 ° adjustable, Allows For Precise Installation

Top brand LED chip and driver, ensure the product quality and lifetime


2-16m PIR Sensor

Ingress Protection Rating: IP66

Operation Temperature: -25ºC-+50ºC

4000K,5000K,5700K Adjustable

CRI >70,80

5 years Warranty



Model MF-TGD-B10W MF-TGD-B20W MF-TGD-B30W MF-TGD-B50W MF-TGD-B100W MF-TGD-B150W MF-TGD-B200W MF-TGD-B300W
Rated Power 10W 20W 30W 50W 100W 150W 200W 300W
LED Chips 12 pcs 24 pcs 40 pcs 72 pcs 140 pcs 208 pcs 280 pcs 448 pcs
Input Voltage AC100 -277V
Chip O-sram
Driver ZH / Sosen / Meanwell
CRI 70+/80+
CCT 3000K-4000K-5700K
Power Factor >0.95
Driver Efficiency 92%
Luminous
Efficacy
120-130lm/W
IP Rating IP66
IK Rating IK08
Housing Die-Cast Aluminum
Cover Material Tempered glass
operation
Temperature
-25°C- +50°C
Beam Angle 120°
Warranty 3 / 5 years
Dimension 127*159*44mm 147*188**43mm 193*242*46mm 237*293*47mm 280*344*55mm 320*424*61mm 337*476*63mm 407*569*70mm


200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 2



Breather Valve, balance the internal andexternal pressure and humidity
Racked Angle,10°steps, allows for 270° installation adjustment.
Galvanized bracket, corrosion resistant




200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 3







Die-casting technology by ADC12
Hem corner, strengthen stability
With hexagon socket screws, the surface looks neater



200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 4



4mm Tempered Glass : clear,frosted,milky, highimpact resistance lK08



PIR Sensor: Distance 2-16m(<24C) / Time-Delay :10s-7m / Range :180° / Ambient:<10-2000lux



Offset Bracket: make the installation easier.allowthe installation process withoutremoving the bracket, save timeand labor cost



200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 5200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 6

1. High performance and reputable brand LED chips and driver
2. Clear tempered glass decrease risk of lamp breaking for strong industrial applications
3. Optimized aluminum alloy housing design for superior thermal management
4. Instant light up with no warm up time
5. No cool down needed before restart
6. High mechanical impact resistance and ingress protection rating
7. Compact in size and easy for transportation

Options

1. Housing color and glass color
2. Length wire and special plug
3. Dimming 0-10V, 1-10V, DALI

200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 7
200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 8
200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 9200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 10

10W / 20W / 30W / 50W

200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 11

100W / 150W / 200W / 300W

200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 12
200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 13

Installation

200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 14







Roads and highways / Parking lots / Sports stadiums / Railroad yards / Shipyards / Warehouses / Truck stops and rest areas /
Outdoor parks and recreation areas / Playgrounds / Storage facilities
Any Outdoor place,Etc

200W IP66 Waterproof RGB Flood Lamp Projector Floodlight Smart Remote Control Multicolor 15
