100W 150W 200W LED High Bay Lights, IP65, 0-10V/Dali dimmer , Sensor, Emergency kit
Contact Person : Claire Li
Phone Number : 86-15999718117
WhatsApp : +8615999718117
| Minimum Order Quantity : | 5PCS | Price : | Ex-work/FOB price |
|---|---|---|---|
| Packaging Details : | 33*33*21cm/1pcs, N.W: 3.3KG, G.W: 3.9KG | Delivery Time : | 2 weeks |
| Payment Terms : | T/T, Western Union, Paypal | Supply Ability : | 5,000pcs/Month |
| Place of Origin: | China | Brand Name: | MF |
|---|---|---|---|
| Certification: | CE,RoHS | Model Number: | MF-UFO02A-S2835 |
|
Detail Information |
|||
| Lamp Power: | 150W | Lamp Luminous Efficiency: | ≧19500LM |
|---|---|---|---|
| Lamp Body Material: | ADC12 Aluminum Alloy | CRI: | >80Ra |
| Warranty: | 5 Years | Input Voltage: | 85-265Vac, 50/60Hz |
| IP Rating: | IP65 | Beam Angle: | 60° And 90°and 105° Zoomable |
| Mounting Type: | Rings Mounted/hanging | PF: | > 0.90 |
| High Light: | 150W Industrial High Bay LED Lights,IP65 Industrial High Bay LED Lights,19500lm ufo high bay light |
||
Product Description
Dust-Proof Ufo Led Industrial High Bay Lights Ip65 White
Description:
Ming Feng Lighting Co., Ltd develop a new kind of UFO IP65 LED high bay light, can fluctuate different beam angle lens as 60°/90°/ 105° apply to workshop, factory building, warehouse, highway toll stations, gas stations, supermarkets, exhibition halls, stadiums and other places of lighting required. With ADC12 Aluminum alloy materials radiator, with air duct design principle of both inside and outside ventilation, and better heat dissipation performance. Varities of Joint, include ring, sling chain, U shapre bracket installation type. Unique design for Meanwell driver, to keep low temperature when operating. Beautiful appearance, own high light efficiency, can achieve 140LM / Watt.
UFO high bay light application instructions:
- Compared to traditional halogen high bay, leds will be more energy saving.
- Reliable meanwell series of driver,and the driver can be 0-10v, PWM dimming.
- Installation methods: Rings, hanging chain, U shape bracket. All accessories will be provided according to customers requirements.
- Optimum installation height: 8-15 meters.
- Waterproof IP65.
Specifications:
Item | 150W LED Highbay light |
Input voltage | 85-265Vac 50Hz/60Hz |
LED Power | 150W |
Luminaire Efficiency | 130lm/W |
Delivered Flux(Tj80°c) | 19500lm+ |
IP Rating | IP65 |
Color temperature | 3000K/4000K/5000K/6000K |
LED Chip | SAMSUNG |
LED Driver | LIFUD/MeanWell/Lonsng |
Color Rendering Index | >80 Ra |
Power Factor | >0.97 |
Lifespan | ≥50,000hrs />100,000hrs |
Operation Environment | Temperature:- 30°C~50°C/Humidity:10%~95% |
Material | ADC12 Aluminum alloy |
| Packing INFO | 305*305*205mm |
Net Weight | 3.2Kg |
| Gross Weight | 3.7Kg |
Certificate | CE/RoHS |
Warranty Period | 5 years |
Main Features:
1. The material of heat sink is high thermal conductivity No.ADC12 aluminum, good for heat dissipation.
2. The unique design of housing help to speed up the heat dissipation, further ensuring the life of the fixture.The integrated design of apperance makes the fixtures looks elegant.
3. This fixture is waterproof, dustproof, anticorrosive.
Photos show of LED highbay lights :
There three kinds with different functions for your reference.
Photos show of LED Highbay light fluctuation of 60° 90° 105° :
Packing INFO of 150 Watt LED Highbay light:
Production Lines:
