High Brightness 100W LED High bay Lighting ,100lm / W IP54 45 Degree Beam Angle

Contact Now

High Brightness 100W LED High bay Lighting ,100lm / W IP54 45 Degree Beam Angle

Minimum Order Quantity :	100PCS	Price :	Negotiable
Packaging Details :	58.53041cm/2pcs, G.W: 7.7Kg	Delivery Time :	Depends on orders
Payment Terms :	T/T, Western Union, L/C, Paypal	Supply Ability :	5,000pcs/Month

Place of Origin:	China	Brand Name:	MF
Certification:	CE, RoHS	Model Number:	MF-HB100

Detail Information

High Light:

led industrial high bay lights

ufo high bay lights

Product Description

High Brightness 100W LED High bay Light ,100lm / W IP54 45 Degree Beam Angle

Quick Detail:

100W LED High bay light
Input: AC 85V-265V, 50/60Hz
Luminous Flux:≧8800Lm
Beam Angle:45°,90°,120°
Brand chip: Bridgelux and Epistar
LED Driver: Meanwell
IP:54
Power Factor:>0.9
Reflector: AL/ PC

Description:

As one of excellent LED lights suppliers in led lighting industry, Ming Feng newly released high bay light series products, which are most completely serialized, low pitched, but powerful in leds lighting industry.

LED high bay light heat dissipation management system is triple effect of heat dissipation and enhancing luminaries performance to elongate lifespan. High vertical illumination, high uniformity of luminance, meet requirements of large space lighting. Plug-play structure is convenient for installation/maintenance. Multiple features of this model such as accurate light distribution, anti-glaring, uniform light color, etc.

Specifications:

Item	MF-HB100
Input voltage	85-265Vac 50Hz/60Hz
LED Power	100W
System Consumption	110W
Delivered Flux	8800lm
IP Rating	IP54
Beam Angle	45°,90°,120°
Color temperature	3000K-6500K
LED Chip	Bridgelux / Epistar
LED Driver	Meanwell
Color Rendering Index	Ra>70
Power Factor	>0.9
Lifespan	≥50,000hrs
Operation Environment	Temperature:-40°C~50°C/Humidity:10%~95%
Material	Aluminum Alloy
Lens	Glass or PC
Net Weight	6.7Kg
Certificate	CE/RoHS
Warranty Period	3 years

Competitive Advantage:

1. The heat sinker is using high quality 250*160 mm diameter sun flower pure aluminum, anodic oxidation for the surface heat sinker

2. The anodic oxidation spinning reflector can be separated from the main body part, easy to transport

3. High light transmittance PC cover used upon the LED

4. Using Epistar or Bridgelux COB LED, make the light even

5. 45°,90°and 120°,three beam angles can be optional

Light Distribution Curve:

High Brightness 100W LED High bay Lighting ,100lm / W IP54 45 Degree Beam Angle 0

High Brightness 100W LED High bay Lighting ,100lm / W IP54 45 Degree Beam Angle 2

Dimension:

Applications:

Factory, warehouse, exhibition hall, airport, shopping mall, train station, lobby etc.
