IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 58.5*36.5*18.5cm/1pcs, G.W: 7.0Kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union,L/C Paypal Supply Ability : 5,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS, DLC, UL Model Number: MF-Sea Gull High Mast

Detail Information

CCT: 2700K-6500K Material: ADC12 Aluminum Die-Casting Fixture Housing
IP: 66 Power: 400W-600W-800W
Certificated: CE/ETL/FCC/ROHS/SAA/TUV/CB/UL Application: Wharf/Airport/Aproan/Stadium/Highway/Sea Port/etc
Input Voltage: AC100-305V,50-60Hz LED Brand: Lumileds
Luminous Efficacy: 140lm/W CRI(Ra): 70+/80+/90+
Beam Angle: 30/45/60/90/80*140°/Asymmetrica L60° Output Voltage: DC48
Installation: Pole

Product Description

IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard


IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 0

1.Quick and Easy Pole Installation: Designed for hassle-free installation on poles with diameters ranging from 60mm to 100mm, saving time and effort.
2.Tool-Free Clip-on Design: Features a convenient tool-free design with two clips, allowing for effortless opening and maintenance without the need for additional tools.
3.Convenient Installation Features: Equipped with a 10KV/20KV SKD and a spirit level for easy and accurate installation, ensuring proper alignment. The ADC12 aluminum die-casting driver box provides durability and efficient heat dissipation for long-lasting performance.
4.Flexible 360° Rotation: The lighting fixture can be effortlessly rotated 360 degrees, providing flexibility in directing the light exactly where it is needed and simplifying the installation process.
5.Enhanced Compatibility with NEMA Socket: Includes a NEMA socket, ensuring compatibility with various lighting control systems and enabling seamless integration.
6.High-Brightness LED Options: Utilizes top brand LED chips, delivering exceptional brightness. Choose between 3030 LEDs with a luminous efficacy of 140lm/W or 5050 LEDs with a luminous efficacy of 150lm/W.
7.Durable and Compact Aluminum Die-Casting Fixture Housing: Constructed with an ADC12 aluminum die-casting fixture housing, providing a sleek appearance, excellent thermal management, and a compact design that optimizes space utilization.
8.Premium Quality Polycarbonate Lens: Incorporates a high-quality polycarbonate lens from a renowned Japanese brand, TElJIN PC. The lens features multiple optical lighting designs, offering anti-UV properties and high mechanical strength for long-lasting performance.



9.Photometry: Provides various photometry options, including symmetrical options of 30°, 45°, 60°, and 90°, as well as asymmetric options of 140°80° and 120°40°*60°.

10.Tempered Glass Cover Options: Offers the choice of a 4mm high-strength tempered glass cover, which further reduces UV exposure and is designed to withstand rust, making it suitable for coastal areas.

11.Copper Breather Valve: Equipped with a copper breather valve to balance internal and external humidity and pressure, ensuring optimal performance and longevity.
IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 1

IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 2





IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 3



Optical Data
Power 400w
LED Chips Lumileds
Luminous Efficacy 140lm/W15%
Luminous Flux Refer to lES
CCT 2700K-6500K
Beam Angle 30/45°/60/90/80*140R/Asymmetrica 160°
CRI(RA) 70+/80+/90+



Electrical Data
Driver Mean-well/So-sen/Inven-tronics
InputVoltage AC100-305V,50-6OHz
Power Factor >0.95
OutputVoltage DC48
Total Harmonic Distortion <15%
DriverEfficiency 92%



Others
lRating lP66
Lifespan 60,000Hrs
Housing Die-Cast Aluminum
Lens Material Polycarbonate
Fixture Size 672*430*304mm
Carton Size
Net Weight 16.9KG
Gross Weight 18.9KG
lnstallation Pole
Diameter 60mm-100mm

IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 4
IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 5







Luminous Intensity Distribution Diagram:




IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 6



Installation:
IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 7





Accessory:



IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 8

IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 9
LED High Mast Light

  1. Roads and highways
  2. Parking lots
  3. Sports stadiums
  4. Railroad yards
  5. Shipyards
  6. Warehouses
  7. Truck stops and rest areas
  8. Outdoor parks and recreation areas
  9. Playgrounds
  10. Storage facilities
  11. Any Outdoor place,Etc

IP66 Outdoor Waterproof LED Flood Light Stadium Light With 400W-800W High Power For Sport Field Shipyard Railroad Yard 10

LED High Mast Lights are powerful lighting solutions that are primarily used for illuminating large outdoor areas. Here is an example of an application for LED High Mast Lights:
Sports Stadium Lighting: LED High Mast Lights are extensively used in sports stadiums to provide high-quality lighting for various sporting events. These lights offer exceptional brightness and uniform illumination, ensuring optimal visibility for players and spectators alike. The powerful beams of LED High Mast Lights can cover large areas, allowing for clear visibility of the entire playing field, enabling athletes to perform at their best. Additionally, these lights can be easily adjusted and directed to focus on specific areas of the stadium as needed.
Industrial Facilities: LED High Mast Lights are often employed in industrial settings, such as ports, warehouses, and construction sites. These lights effectively illuminate vast areas, providing ample visibility for workers to carry out their tasks safely and efficiently, even during nighttime operations. The robust construction of LED High Mast Lights ensures durability and resistance to harsh environmental conditions, making them suitable for demanding industrial environments.
Airport Lighting: LED High Mast Lights are used to provide efficient and reliable lighting for airport runways, taxiways, and aprons. These lights offer high luminosity and excellent color rendering, allowing pilots to navigate and land aircraft safely, even in low visibility conditions. LED High Mast Lights also contribute to enhanced security and visibility during aircraft operations, ensuring the smooth flow of air traffic.

Parking Lots and Outdoor Areas: LED High Mast Lights are commonly installed in large parking lots and outdoor spaces, such as shopping centers, stadiums, and public parks. These lights provide bright and uniform illumination, ensuring the safety and security of pedestrians and vehicles. LED High Mast Lights can effectively cover vast areas, reducing dark spots and creating a well-lit environment that discourages criminal activities.
Highways and Interchanges: LED High Mast Lights are deployed along highways and interchanges to ensure clear visibility for drivers, improving road safety during nighttime driving. These lights offer high luminosity and excellent light distribution, minimizing glare and providing uniform illumination across the entire roadway. LED High Mast Lights also contribute to better visibility of road signs and markings, assisting drivers in navigating complex road networks.
