ETL Industrial UFO LED High Bay Light With IP65 Waterproof 100W-300W High Power For Warehouse Plant Factory

Minimum Order Quantity : 100PCS/negotiation Price : Negotiable
Packaging Details : NW 3kg,GW3.5kg 30.5*30.5*20.5cm/38.5*38.5*27.5cm Delivery Time : 2 weeks delivery time
Payment Terms : T/T, Western Union, Paypal,L/C Supply Ability : 5000pcs/Month
Place of Origin: China Brand Name: MF
Certification: UL,DLC,SAA,TUV,CE, RoHS Model Number: MF-HB02

Detail Information

Power: High 100W/150W/200W/300W Color Temperature: 3000K-6000K
IP Rating: IP65 Lumen Output: >130lm/w
CRI: >80 Input Voltage: AC100-277V
Warranty: 5 Years Lifespan: 50,000 Hours
Light Source: LED Power Factor: >0.95

Product Description

ETL Industrial UFO LED High Bay Light With IP65 Waterproof 100W-300W High Power For Warehouse Plant Factory



Feature:



  1. 5-year warranty for long-lasting performance
  2. IP65 rating for resistance to dust and water
  3. High-power and high-brightness LEDs for exceptional illumination
  4. High color rendering index (CRI) for accurate and vivid colors
  5. Uses international brand power supplies for reliable and efficient performance
  6. Wide voltage range of 110V-220V for versatility in different settings



Product characteristic:

The LED high bay light stands out as the ultimate lighting solution specifically designed for industrial and commercial spaces, offering a range of distinctive features that differentiate it from other lighting options. By harnessing cutting-edge LED technology, this light source delivers unparalleled brightness while consuming minimal power, resulting in substantial energy savings that significantly reduce electricity expenses. Its robust yet lightweight aluminum housing ensures long-term durability, complemented by a heat sink design that optimizes heat dissipation for optimal performance. The adjustable hanging bracket enables versatile installation, while the availability of color temperature and dimming options allows for tailored lighting solutions to suit any application. Moreover, this LED high bay light possesses a wet and damp location rating, making it an ideal choice for environments where moisture is a concern.


DISCRIPTION:



Model Name MF-HB02-100W-XX MF-HB02-150W-XX MF-HB02-200W-XX MF-HB02-300W-XX
Part No 100W 150W 200W 300W
LED Type SAMSUNG/CREE LUMILEDS
LED QTY 2835 3030
216pcs 288pcs 360pcs 490pcs
System Efficacy 140±5% LM/W
Luminous Flux 14000±5% LM 21000±5% LM 28000±5% LM 42000±5% LM
CCT 3000K, 3500K,4000K,4500K, 5000K,5700K
Beam Angle 110°
CRI >80Ra
System E fficiency >90
PowerSupply MEANWELL /SOSEN / ZH
Input Voltage AC100-277V
Power Frequency 50/60Hz
Output Voltage DC108V DC216V DC216V DC42V
Output Current 0.92A 0.69A 0.92A 7.14A
Power Efficiency >90%
Power Factor >0.9
Total Harmonic Distortion <15%
System Power consumption 100±5 W 150±5 W 200±5 W 300±5 W
IP 65
Dimming 0-10V
Safety Certification ETL,DLC5.1
Fixture Material ADC12 Aluminum alloy
Life span >50000Hrs(Ta=50℃ @LM70)
OperatingTemperature -30 ~ 50℃
Operating Humidity 15-90%RH
StorageTemperature -40 ~ 70℃
Storage Humidity 10%-95%










Product dimension:




ETL Industrial UFO LED High Bay Light With IP65 Waterproof 100W-300W High Power For Warehouse Plant Factory 0



Installation:

Chain Mount:



  1. Screw the circular ring tightly.
  2. Fix the lamp with chain to the ceiling.
  3. Connect the wires

Hook Mount:



  1. Screw the circular ring tightly.
  2. Please hang the fixture into the lifting hook and protect it from failing. Make sure the hook can bear over 3 times weight of the fixture.
  3. Connect the wires



ETL Industrial UFO LED High Bay Light With IP65 Waterproof 100W-300W High Power For Warehouse Plant Factory 1ETL Industrial UFO LED High Bay Light With IP65 Waterproof 100W-300W High Power For Warehouse Plant Factory 2

Applications:



LED high bay light is ideal for a wide range of applications, including warehouses, factories, gymnasiums, supermarkets, and more. Its high-efficiency LED technology provides bright and even illumination, while the durable aluminum housing and heat sink design ensure long-lasting performance. The adjustable hanging bracket allows for easy installation, and the light is suitable for use in damp locations. With its customizable color temperature and dimming options, this LED high bay light is a versatile lighting solution for any industrial or commercial space.

ETL Industrial UFO LED High Bay Light With IP65 Waterproof 100W-300W High Power For Warehouse Plant Factory 3ETL Industrial UFO LED High Bay Light With IP65 Waterproof 100W-300W High Power For Warehouse Plant Factory 4

LED High Bay lights are widely utilized in various industrial and commercial applications due to their exceptional lighting capabilities and energy efficiency. Here are some key applications where LED High Bay lights are commonly used:
Warehouses and Distribution Centers: LED High Bay lights are perfect for illuminating large storage spaces, warehouses, and distribution centers. Their high brightness and wide beam angles ensure uniform lighting, enhancing visibility and safety for workers and facilitating efficient operations.
Manufacturing Facilities: LED High Bay lights provide optimal lighting conditions in manufacturing facilities, including assembly lines, production areas, and workshops. Their superior brightness and color rendering capabilities enable workers to perform tasks with accuracy and precision.
Retail Stores and Supermarkets: LED High Bay lights are widely employed in retail environments, such as supermarkets and large stores. These lights offer bright and uniform illumination, enhancing product visibility and creating a pleasant shopping experience for customers.
Gymnasiums and Sports Facilities: LED High Bay lights are commonly used to light up gymnasiums, sports halls, and indoor sports facilities. Their high lumen output and excellent color rendering ensure sufficient lighting for sports activities, enabling participants and spectators to enjoy optimal visibility.
Exhibition Halls and Event Spaces: LED High Bay lights are often chosen for exhibition halls, event spaces, and convention centers. Their powerful illumination and adjustable lighting options allow for highlighting displays, booths, and stages, creating an engaging and visually appealing environment.
Hangars and Airports: LED High Bay lights are suitable for illuminating large spaces, including aircraft hangars and airport terminals. Their high brightness and broad coverage ensure safe and efficient operations, facilitating aircraft maintenance and enhancing passenger experiences.
Indoor Agricultural Facilities: LED High Bay lights

Maintenance caution:



  1. Review the diagrams before beginning and make sure fixture is grounded properly.
  2. Turn power off and wait for fixture cooling to operate.
  3. Maintenance must be done by professionals.
  4. Clean the dusk on the surface and heat sink with dry cloth regularly to keep good heat dissipation.
  5. Suitable for operation location use.
  6. Suitable for operation in ambient not exceeding 55℃
