Aluminum Housing 40W-300W LED Work Bench Pendant Light Shop Lights LED Linear High Bay Light

Contact Now

Aluminum Housing 40W-300W LED Work Bench Pendant Light Shop Lights LED Linear High Bay Light

Minimum Order Quantity :	100PCS	Price :	Negotiable
Packaging Details :	1PCS/Carton	Delivery Time :	Depends on orders
Payment Terms :	T/T, Western Union, L/C, Paypal	Supply Ability :	5,000pcs/Month

Place of Origin:	China	Brand Name:	MF
Certification:	CE, RoHS	Model Number:	MF-HBXXXW-L2

Detail Information
Power:	40W 80W 100W 150W 200W 250W 300W	Input Voltage:	AC100-277V/347V/480V, 50-60Hz
Lumens Flux:	200lm/W	LED Chips:	Lumileds2835
Beam Angle:	120°	CRI:	80+
Warranty:	5 Years	Driver:	IEC Certified Driver
PF:	>0.95	Lifespan:	≤100, 000hrs
IP Grade:	IP22
High Light:	300W LED Work Bench Pendant Light , Aluminum Housing Linear High Bay Light , 40W Linear High Bay Light

Product Description

40W 80W 100W 150W 200W 250W 300W IP22 150LM/W 3000K-6500K IEC Certified Driver Linear High Bay Light For Supermarket/Shopping Mall/Warehouse

Aluminum Housing 40W-300W LED Work Bench Pendant Light Shop Lights LED Linear High Bay Light 0

Quick Detail:

IP22 40W 80W 100W 150W 200W 250W 300W LED Linear High Bay Light
Input: AC100-277V/347V/480V, 50-60Hz
Beam Angle: 120°
CCT: 3000K-6500K
PF: >0.95
Lifespan: ≤100, 000hrs

Description:

ENERGY SAVING CONTROL OPTION- DIM - 0-10 volt dimming enabled with controls by others.

EXPECTED LIFE - 100,000 hours depending upon the ambient temperature of the installation location.

LEDS - Select high-brightness LEDs in Warm White, Neutral White or Cool White color temperature

DISTRIBUTION/PERFORMANCE- High performance, multifaceted, reflector provides uniform Forward Throw (FT) distribution

with sharp backlight cutoff. Photometric data is tested in accordance with IESNA guidelines

HOUSING - One-piece, die-formed aluminum housing contains factory prewired driver in a gasketed

OPTICAL UNIT - PC lens with frosted and corrugated for options

OPERATNG TEMPERATURE - -30° C to +55ºC (-40°F to +122°F)

WARRANTY - 5 years warranty

Specifications:

Power	40W 80W 100W 150W 200W 250W 300W
LED Chip	Lumilled
Luminous Flux	200lm/W
CCT	3000K-6500K
CRI	80+
Beam Angle	120°
Driver Brand	IEC Certified Driver
Input Voltage	AC100-277V/347V/480V, 50-60Hz
IP	IP22
Lifespan	≤100,000hrs
Housing	Aluminum
Lens Material	PC

ACC:

Aluminum Housing 40W-300W LED Work Bench Pendant Light Shop Lights LED Linear High Bay Light 1

Key Features:

Housing material: aluminum

High luminous output 200LM/W, energy saving 50%

Translucent lens standard to minimize glare L80 lumen maintenance of 100,000 hours

Intelligent control: infrared remote control,Zigbee, Bluetooth Mesh, high-altitude microwave sensor, infrared light sensor, Zigbee version supports heat map, supports light decay compensation

Multiple Mounting Options: Suspended mounted

The Economic L2 High Bay is a cost-effective and quality solution for lighting warehouses, distribution centers, manufacturing facilities, big box retailers, and other industrial applications.

A dimmable and compact product, it delivers a high lumen output to replace both traditional fluorescent and HID high bay

fixtures.

Dialux Simulation:

Aluminum Housing 40W-300W LED Work Bench Pendant Light Shop Lights LED Linear High Bay Light 2

Dimension:

Aluminum Housing 40W-300W LED Work Bench Pendant Light Shop Lights LED Linear High Bay Light 3

Product NO.	Dimensions(MM)	N.G(KG	G.W (KG)	Package Size(MM)
MF-HB40W-L2	300L x 342W x55H	1.9kg	4.7kg	345L x 387W x 228H
MF-HB80W-L2
MF-HB100W-L2	600L x 342W x 55H	3kg	7.7kg	645L x 387W x 228H
MF-HB150W-L2
MF-HB200W-L2	900L x 342W x 55H	4.3kg	11.5kg	945L x 387W x 228H
MF-HB250W-L2
MF-HB300W-L2	1200L x 342W x 55H	5.5kg	15.5kg	1245L x 387W x 228H

Applications:

Potential applications for the Flamingo Linear LED High Bay Light:

1.Warehouses and distribution centers
2.Manufacturing facilities and factories
3.Gymnasiums and sports facilities
4.Exhibition halls and convention centers
5.Retail stores and showrooms
6.Large supermarkets and hypermarkets
7.Assembly lines and inspection areas
8.Precision manufacturing processes
9.Workshops and garages

etc.

Aluminum Housing 40W-300W LED Work Bench Pendant Light Shop Lights LED Linear High Bay Light 4

Why Choose Us:

Our LED light is in high quality standard at reasonable and competitive price, our designer and engineer help our LED light in tasteful design and excellent performance.We are able to offer our valuable clients:
OEM/ODM Service
Photometric/IES File
Dialux simulation Design
PCB Design/Driver Design
Heat Management/Optical Design
Industry Design
Market Support
3D Printing
Multiple Listing/Private Label
