Alu. PC Anti Glare IP40 Recessed Light Spotlight Ceiling Mounted Down Light For Home Furnishing Corridor Public Areas

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 8pcs (13kg/CTN) 45.5*45.5*32cm Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, Paypal, L/C Supply Ability : 10,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CCC, CE, CQC, ETL, RoHS, SAA Model Number: MF-TH229-20W

Detail Information

Power: 10W / 12W / 15W / 20W / 30W / 40W Luminous Flux: 100lm/W
Beam Angle: 24° 36 °45 °50 °60 ° CRI: >80Ra Or 90Ra
Warranty: 3 Years Optional LED Brand: Cree Or Epistar COB LED
Application: Engineering, Home Furnishing, Residential Gardens, Commercial Buildings, And Pub Nominal Current: 350,000mA
Protection Class: II Operating Mode: Electronic Control Gear
Luminous Flux (Lm): 640-800lm Lifespan: ≥35000hrs
High Light:

IP40 Recessed Light

,

Anti Glare Ceiling Mounted Down Light

,

800lm Recessed Light

Product Description

Factory Price 2in3in4in5in6in Alu. PC anti glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Product Description



Our LED downlights offer numerous benefits and features that make them an excellent lighting choice:

High Luminous Efficacy: Our LED downlights are designed to provide a high level of brightness while consuming minimal energy. With their efficient light output, they offer excellent illumination for various applications.

Direct Replacement for Compact Fluorescent Lamp Downlights: Our LED downlights are specifically designed as a direct replacement for traditional compact fluorescent lamp (CFL) downlights. This makes the transition to LED lighting seamless and hassle-free.

Energy Savings up to 60%: By utilizing advanced LED technology, our downlights offer significant energy savings compared to luminaires that use CFL lamps. With up to 60% energy savings, you can reduce your energy consumption and lower utility costs.

Homogenous Light: Our LED downlights provide a uniform and homogenous distribution of light, ensuring consistent and even illumination across the space. This helps create a visually pleasing environment with minimal glare or dark spots.

Functional Design: Our downlights feature a functional design that blends seamlessly with various interior styles and architectural settings. The sleek and compact design adds a modern touch to any space while providing efficient lighting.

Easy Installation with Fast Connection: Installing our LED downlights is quick and straightforward. They are designed for easy installation, and with the fast connection feature, you can save time and effort during the installation process.

3 Years Guarantee: We stand behind the quality and performance of our LED downlights. To provide you with peace of mind, we offer a 3-year guarantee, ensuring that you receive a reliable and durable lighting solution.

Experience the benefits of high luminous efficacy, energy savings, homogenous light, functional design, easy installation, and our 3-year guarantee with our LED downlights. Upgrade your lighting system and enjoy efficient and quality illumination in your space.

Specialized design apperance

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

108 processes

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Each layer is carefully design

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Len

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Reflective cup

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Aluminum structure with strong heat dissipation

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

High quality Hardware Spring

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
Beam angle:

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas





Product pictures:
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas




Product Parameters

Parameters
Electrical Data:

Nominal Wattage 10W/12W/15W/20W/30W/40W
Nominal Voltage 100-240V
Mains Frequency 50-60Hz
Nominal Current 350,000mA
Power Factor λ 0.9
Protection Class II
Operating Mode Electronic Control Gear (ECG)


Application & Mounting:

Ambient Temperature Range -20 °C~ 40°C
Type of Connection Terminal, 2-pin
Type of Protection IP40
Dimmable No
Mounting Type Recessed
Mounting Location Ceiling
Application Environment Indoor
Mounting Diameter 10W 75mm,12W 90mm,15W 100mm,20W 115mm,30W 145mm,40W 170mm
LED module Replaceable Not replaceable
Lifespan L70/B50 at 25 °C 30000 h1)
Number of Switching Cycles 15000


Material & Color:

Product Color White Black
Housing Color White Black Grey Red
Body Material Aluminum
Mercury Content 0.0mg
Diameter 10W 82mm,12W 96mm,15W 106mm,20W 123mm,30W 155mm,40W 185mm
Length 10W 82mm,12W 96mm,15W 106mm,20W 123mm,30W 155mm,40W 185mm
Height 60.00 mm
Product Weight 610.00g
Power D(mm) H(mm) C(mm)
10W 82 53 75
12W 96 58 90
15W 106 63 100
20W 123 68 115
30W 155 76 145
40W 185 83 170
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Photometry

Luminous Flux 10W 1000lm/12W 1200lm/15W 1500lm/20W 2000lm/30W 3000lm/40W 4000lm
Luminous Efficacy 100 lm/W
Color Temperature 3000K 4000K 6000K
Light Color (designation) Warm White
CRI ≥80
Beam Angle 24°36 °45 °50 °60 °

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Application



Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas
Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas



Packaging & Shipping

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas




Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Certifications

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

Company Profile

Factory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public AreasFactory Price 20W 2in3in4in5in6in Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light for Home Furnishing Corridor Public Areas

About US
We are a factory specializing in the production of LED lights for a wide range of indoor and outdoor applications. Our product portfolio includes LED downlights, LED panel lights, LED wall lights, LED tube lights, LED spotlights, LED track lights, LED ceiling lights, LED high bay lights, LED tri-proof lights, LED flood lights, LED high mast lights, LED stadium lights, LED street lights, LED garden lights, and LED explosion-proof lights. These products are widely installed in various large-scale lighting applications, such as farms, factories, schools, bridges, tunnels, ports, subways, airports, mines, hospitals, and more.
With a focus on LED lighting, we have gained expertise in producing and exporting high-quality LED light fixtures to over 132 countries in Asia, Europe, North America, Latin America, and the Pacific Ocean islands. Our LED lights are manufactured under the ISO9001 system, and our professional team ensures efficient management throughout the production process. We hold certifications such as CE, CB, ENEC, RoHS, CSA, UL, SAA, and REACH, which are accredited by reputable organizations like SGS or TUV, depending on the LED light family.
At MF, our dedicated R&D team is driven by passion, persistence, and technological expertise. Our engineers meticulously develop our LED lights, paying attention to even the smallest details. Our goal is to provide high-quality LED lighting solutions by combining our visionary approach with in-depth knowledge. We firmly believe in the power of lighting to enhance the quality of life and work for users worldwide. As a team, we understand that "LIGHTS THE WORLD" is not just a slogan but a commitment that we strive to fulfill through our hard work, day by day.
