High Power Recessed COB LED Down Light Waterproof Spot Light anti-Glare 100lm/W 1-10V Dali Dimable 7W 15W 30W 60W

Product Description

High Power Recessed COB LED Down Light Waterproof Spot Light nti-Glare 100lm/W 1-10V Dali Dimable 7W 15W 30W 60W

Electrical data

Nominal wattage			10W 15W 20W 30W 40W 60W
Nominal voltage			100.…240 v
Mains frequency			50…60 Hz
Nominal current			350.000 mA
Power factor λ			0.90
Protection class			II
Operating mode			Electronic control gear (ECG)

Photometrical data

Luminous flux		10W/1000lm 15W/1200lm 20W/2000lm 30W/3000lm 40W/4000lm 60W/6000lm
Luminous efficacy		100 lm/W
Color temperature		3000 K 4500K 6000 K
Light color (designation)		Warm White
Color rendering index Ra		≥80
Beam angle		60°

Materials & Colors

Product color(Ring)	White
Housing color	Multiple Color Optional
Body material	Aluminum
Mercury content	0.0 mg

Application & Mounting

Ambient temperature range	-20…+40 ºC
Type of connection	Terminal,2-pin
Type of protection	IP65
Dimmable	Yes
Mounting type	Recessed
Mounting location	Ceiling
Application environment	Indoor/Outdoor
Mounting diameter	Refer to Dimensions & Weight
LED module replaceable	Not replaceable

Lifespan

Diameter of required ceiling cut-out:

MF-D1001B
15W,Φ100mm;20W,Φ110mm;30W, Φ145mm,50W,Φ200mm

MF-D1002B
5W,L90xW90mm; 20W,L110xW110mm; 30W,L145xW145mm; 50W,L200xW200mm;

LED downlights are versatile lighting fixtures that find wide application in various settings.With their sleek design and energy-efficient performance, LED downlights are commonly used in residential, commercial, and hospitality environments.

In residential settings, LED downlights are often installed in kitchens, living rooms, and bedrooms to provide ambient or task lighting. They offer a modern and stylish lighting solution while consuming less energy compared to traditional lighting options. LED downlights can create a warm and inviting atmosphere, enhancing the overall aesthetic appeal of the space.

In commercial spaces such as offices, retail stores, and showrooms, LED downlights are utilized to illuminate the area effectively. These downlights offer a focused and uniform light distribution, making them ideal for highlighting specific areas or products. LED technology ensures long-lasting performance, reducing maintenance costs and providing consistent lighting quality.

Hospitality venues, including hotels, restaurants, and bars, benefit from LED downlights to create a welcoming and visually appealing ambiance. These downlights can be used for general lighting, accenting architectural features, or accentuating artwork and displays. Additionally, the dimmable feature of LED downlights allows for flexible lighting control, enabling the adjustment of light levels to create different moods and atmospheres.

Overall, LED downlights are widely used due to their energy efficiency, long lifespan, and versatility. They offer excellent lighting performance, enhance aesthetics, and contribute to energy savings, making them a popular choice for a range of applications in both residential and commercial settings.

Hospitality: LED downlights are commonly used in hotels, resorts, and spas to create a soothing and luxurious atmosphere in lobbies, corridors, guest rooms, and common areas. They provide soft, warm illumination that enhances the guest experience and adds a touch of elegance to the space.
Museums and Galleries: LED downlights are preferred in art galleries and museums to illuminate exhibits and artwork with precision and accuracy. Their directional lighting helps to highlight the details and colors of the art pieces while minimizing heat and UV emissions that could
potentially damage the artwork.
Showrooms: LED downlights are ideal for showcasing products in retail showrooms, car dealerships, and jewelry stores. Their focused beam and adjustable angles allow for effective accent lighting, drawing attention to specific merchandise and creating a visually appealing display.

Offices and Workspaces: LED downlights are widely used in office environments to provide bright, glare-free illumination for workstations, conference rooms, and common areas. They offer a comfortable working environment, reduce eye strain, and contribute to better productivity.
Educational Institutions: LED downlights are employed in schools, universities, and libraries to create conducive learning environments. They provide uniform lighting in classrooms, libraries, and study areas, enhancing concentration and visual comfort for students and teachers.
Healthcare Facilities: LED downlights are utilized in hospitals, clinics, and healthcare facilities for general lighting in corridors, waiting areas, and patient rooms. They offer a clean and bright light source, promoting a sense of well-being and aiding in accurate medical examinations. Outdoor Spaces: LED downlights with suitable IP ratings can be used for outdoor applications such as building facades, pathways, gardens, and parking areas. They provide efficient and durable lighting solutions that enhance safety and security while reducing energy consumption.

IP65 LED downlights are widely used in various applications due to their superior waterproof and dustproof capabilities. These downlights are specifically designed to withstand harsh environmental conditions, making them suitable for both indoor and outdoor use.

In indoor applications, IP65 LED downlights are commonly installed in areas where moisture or water exposure is a concern, such as bathrooms, kitchens, and swimming pool areas. Their high IP65 rating ensures protection against water splashes and steam, making them ideal for these damp environments. These downlights not only provide excellent illumination but also enhance the aesthetic appeal of the space.

In outdoor applications, IP65 LED downlights are extensively used to illuminate pathways, gardens, parking lots, and building exteriors. Their robust construction and weatherproof design allow them to withstand rain, snow, and other outdoor elements. With their energy-efficient LED technology, these downlights offer bright and uniform lighting, enhancing safety and security while reducing energy consumption.

Moreover, IP65 LED downlights find applications in commercial and industrial settings. They are commonly employed in warehouses, factories, and workshops, where dust, moisture, and other contaminants can be present. The IP65 rating ensures protection against dust ingress and water jets, making them suitable for these demanding environments. These downlights provide reliable and long-lasting illumination, contributing to improved productivity and safety in these spaces.

In summary, the versatile IP65 LED downlights are extensively used in indoor and outdoor applications, ranging from residential homes to commercial and industrial settings. Their waterproof and dustproof features make them a preferred choice for areas that require reliable and robust lighting solutions in the face of challenging environmental conditions.

Packing and Production:

The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit
