Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp
Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp
Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp
Contact Now

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 16.5*15*22cm/1pcs, G.W: 1.2Kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, L/C, Paypal Supply Ability : 5,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS,SAA Model Number: MF Superman III Family

Detail Information
CCT: 3000K,4000K,5000K,5700K, CCT Etc Material: Aluminum Alloy
Power: 150W/200W/240W/300W/400W/450W/720W/960W/1200W IP Rate: IP66
Driver: Sosen/MeanWell Luminous Efficacy: 140LM/W-170LM/W
CRI(Ra): 70+ Beam Angle: 15°/25°/45°
Ik Rate: IK8 Installation: Bracket Installation/Wall Installation/Pole Instal
Surge Voltage: 10kv Life Span: >50, 000hrs
Operation Temperature: Ta=40 Warranty: 5 Years
Highlight:

Waterproof High Power Stadium Light

,

Modular High Power Stadium Light

,

IK10 High Power Stadium Light

Product Description

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp



Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 0



Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 1



Modular design

Modular design of driver box and light source, support large power-span (150W-1250W),easy for installation and maintenance, light weight but ensure effective heat dissipation;

Independent driver cavity
Independent driver cavity design, improved the heat dissipation and reliability, overall protection and ensure longer lifespan;

Efficient heat dissipation
Adopt smooth fin design. The isolated suspended driver cavity and light source modules can avoid heat accumulation and improve heat dissipation efficiency.
Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 2
Professional secondary photometric design
Focus on high pole lighting with secondary photometric design, high uniformity and utilization, multi-angle light distribution options. Anti-overflow light hood design for reducing light pollution.

New Generation LED design
A new generation high brightness outdoor led, lower current drive. The whole lighting efficiency increased by about 10%, and lower light attenuation.

Higher waterproof level design
Integrated structure waterproof design without utilizing glue, ≥IP66, explosion-proof grade IK09, able to support 4 times of its own weight.

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 3


Power 150W 200W 240W 300W 400W
Luminous flux 21000±5%Im 29000±5%Im 33600±5%Im 42000±5%Im 56000±5%Im
LED quantity 176PCS 352PCS 352PCS 352PCS 528PCS
Light efficiency 140lm/W 145lm/W 140lm/W 140lm/W 140lm/W
Power 450W 720W 960W 1200W
Luminous flux 65250±5 Im 100800±5%Im 134400±5%Im 168000±5%Im
LED quantity 528PCS 1056PCS 1408PCS 1760PCS
Light efficiency 140lm/W
Color WW NW CW CW
CCT 3000±300K 4000±300K 5000±300K 5700±300K
CRI. ≥70
Beam angle 20°/15°,45°
Main materials PC,Aluminum Alloy
Storage Temperature -30℃~+60℃
Operating Temperature -30℃~+50℃
Frequency 47~63HZ
Input Voltage 100~240V AC



Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 4

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 5

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 6 Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 7 Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 8

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 9

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 10

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 11



Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 12

Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 13



Application Fields:



Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 14



Modular IP66 IK10 High Power Stadium Light Die-casting Alu Waterproof 150LM/W CRI80 High Mast Lamp 15
