Home ProductsLED Stadium Lights150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field
150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field
150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field
150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field
Contact Now

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 16.5*15*22cm/1pcs, G.W: 1.2Kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, L/C, Paypal Supply Ability : 5,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS,SAA Model Number: MF Superman III Family

Detail Information
CCT: 3000K,4000K,5000K,5700K, CCT Etc Material: Aluminum Alloy
Power: 150W/200W/240W/300W/400W/450W/720W/960W/1200W IP Rate: IP66
Driver: Sosen/MeanWell Luminous Efficacy: 140LM/W-170LM/W
CRI(Ra): 70+ Beam Angle: 15°/25°/45°
Ik Rate: IK8 Installation: Bracket Installation/Wall Installation/Pole Instal
Surge Voltage: 10kv Life Span: >50, 000hrs
Operation Temperature: Ta=40 Warranty: 5 Years
Highlight:

outdoor stadium flood lights 150W

,

outdoor stadium flood lights 1200W

,

outdoor stadium flood lights IP66

Product Description

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field



150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 0



150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 1



Modular design

Modular design of driver box and light source, support large power-span (150W-1250W),easy for installation and maintenance, light weight but ensure effective heat dissipation;

Independent driver cavity
Independent driver cavity design, improved the heat dissipation and reliability, overall protection and ensure longer lifespan;

Efficient heat dissipation
Adopt smooth fin design. The isolated suspended driver cavity and light source modules can avoid heat accumulation and improve heat dissipation efficiency.
150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 2
Professional secondary photometric design
Focus on high pole lighting with secondary photometric design, high uniformity and utilization, multi-angle light distribution options. Anti-overflow light hood design for reducing light pollution.

New Generation LED design
A new generation high brightness outdoor led, lower current drive. The whole lighting efficiency increased by about 10%, and lower light attenuation.

Higher waterproof level design
Integrated structure waterproof design without utilizing glue, ≥IP66, explosion-proof grade IK09, able to support 4 times of its own weight.

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 3


Power 150W 200W 240W 300W 400W
Luminous flux 21000±5%Im 29000±5%Im 33600±5%Im 42000±5%Im 56000±5%Im
LED quantity 176PCS 352PCS 352PCS 352PCS 528PCS
Light efficiency 140lm/W 145lm/W 140lm/W 140lm/W 140lm/W
Power 450W 720W 960W 1200W
Luminous flux 65250±5 Im 100800±5%Im 134400±5%Im 168000±5%Im
LED quantity 528PCS 1056PCS 1408PCS 1760PCS
Light efficiency 140lm/W
Color WW NW CW CW
CCT 3000±300K 4000±300K 5000±300K 5700±300K
CRI. ≥70
Beam angle 20°/15°,45°
Main materials PC,Aluminum Alloy
Storage Temperature -30℃~+60℃
Operating Temperature -30℃~+50℃
Frequency 47~63HZ
Input Voltage 100~240V AC



150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 4

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 5

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 6 150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 7 150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 8

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 9

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 10

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 11



150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 12

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 13



Application Fields:



150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 14

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 15

150W-1200W IP66 High Mast Stadium Light IK08 IK10 High Power Waterproof 140lm/W CRI80 5000K for Baseball Field 16
