38W 3 Years Warranty LED Down Light IP65 Waterproof Dustproof 100lm/W 5700K High Brightness For Restaurant

Product Description

38W 3 Years Warranty LED Down Light IP65 Waterproof Dustproof 100lm/W 5700K High Brightness For Restaurant

Power: 15/18/28/38/48W

Voltage: 100-240Vac

Lumens: 100lm/W

CCT:3000/4500/6000K

Housing Color: White/Black

Material:Alu+PC+Metal

Optical Beam: 15°24°38°60°

Waterproof IP65 Driver

MING FENG's Dragonfly-1 Family presents a variety of waterproof downlights available in 15W, 18W, 28W, 38W, and 48W options, covering a color temperature range from 2700K to 6500K. These downlights are equipped with internal drivers and are tailored for recessed installation. They conform to a range of standards such as the IEC60598 Series, EMC, LVD, and others. With stylish designs available in Black, Grey, or Golden finishes, these downlights showcase lamp bodies crafted from ADC12 material, white PC diffusion plates, pressing covers, and springs. Each model features distinct dimensions and cutting sizes to accommodate various lighting requirements. Moreover, they demonstrate exceptional reliability attributes including a long lifespan, high optical efficiency, and robust durability testing. For additional information and detailed specifications, please reach out to MING FENG Lighting using the provided contact details.

The Dragonfly-1 downlights provide a broad selection of beam angles ranging from 15° to 60°, offering versatility in lighting design. They deliver a high lumen output with outstanding efficacy, ensuring bright and energy-efficient lighting. With color temperature options spanning from 3000K to 6500K and a color rendering index (CRI) exceeding 80, these downlights guarantee precise color representation.
These downlights are not just visually appealing but also exceptionally reliable, boasting a long lifespan of 30,000 hours and excellent thermal efficiency. They undergo thorough testing procedures, including high-low temperature cycles and humidity tests, ensuring durability and consistent performance in various conditions.

Whether illuminating residential areas, commercial spaces, or outdoor settings, the Dragonfly-1 Family downlights from MING FENG excel as a fusion of style, dependability, and functionality, establishing them as a top-tier choice for lighting solutions.

Waterproof Design: These downlights are specifically engineered with a waterproof design, rated at IP66, making them suitable for areas where exposure to water or moisture is a concern.

Wattage Options: The Dragonfly-1 Family downlights are available in various wattages including 15W, 18W, 28W, 38W, and 48W, providing flexibility in choosing the appropriate brightness level for different lighting needs.

External Driver: Equipped with external drivers, these downlights simplify installation and maintenance while ensuring reliable performance.

Color Temperature Range: The downlights offer a wide color temperature range from 2700K to 6500K, allowing users to select the desired lighting ambiance.

Product Standards: They comply with various product standards such as IEC60598 Series, EMC, LVD, RoHS, and others, ensuring safety, quality, and regulatory compliance.

Efficiency: These downlights exhibit high thermal efficiency (90%) and luminaire efficiency (75%), contributing to energy savings and environmental sustainability.

Optical Data: The downlights provide high lumen output, luminous efficacy, and optical efficiency, along with features like specific beam angles and color rendering index (CRI) greater than 80.

Reliability: With a rated lifetime of 30,000 hours and overload & shortcut protection, these downlights are designed to offer long-lasting performance and durability.

Installation: Designed for recessed installation, these downlights blend seamlessly into various architectural settings, providing functional and aesthetically pleasing lighting solutions.

In summary, the Dragonfly-1 Family waterproof downlights by MING FENG Lighting combine robust waterproof construction, energy efficiency, compliance with standards, and high-quality lighting performance, making them a versatile choice for diverse indoor and outdoor lighting applications that demand reliability and longevity.

Product Features:

Electronic Data
Parameter	Units	Min	Rating	Max	Remark
Supply Voltage	V	100	110/220	240
Supply Frequency	Hz	50	50/60	60
Supply Current	A	0.072		0.033
Power Consumption	W	18W 48W	4	48W
Power Factor		>0.5/100VAC	>0.5/220VAC	0.5/240VAC
THD
Surge	V	500
IP			65
IK			03
Thermal Efficiency	%		90
Luminaire Efficiency	%		75
LED Driver Current	mA		63
LED Driving Voltage	V		54
LED Driver Efficiency	%		85
Work Temperature	°C	-20		40
Stroage Temperature	°C	-20		60
LED Driver Lifetime
Driver Luminaire TC			/
Overload shortcut protection					Yes
Light Source Date
LED Size	mm	COB
LED Qty (pcs)	pcs	1
LM80 Report	-	yes
Optical Data
Parameter	Units	Min	Rating	Max	Remark
Lumen output	Lm		1800lm	4800lm
Luminous Efficacy	lm/w		100
Chromaticity Coordinate		CIE
Color Temperature	K		3000K-6500K
CRI			>80
UGR	%	<22
Optical Efficiency			>80%
Beam Angle	15D/24D/38D/60D

Applications:



They are designed for recessed installation and are suitable for various applications that require waterproof lighting solutions such as:



Outdoor Lighting: These waterproof downlights can be used for outdoor applications where exposure to the elements is a concern, such as in outdoor walkways, gardens, or building exteriors.



Bathroom Lighting: Due to their waterproof design, these downlights are suitable for use in bathrooms and other wet areas where moisture resistance is essential.



Kitchen Lighting: In kitchens where steam and cooking splashes are common, waterproof downlights can provide both functional and aesthetic lighting solutions.



Swimming Pool Areas: These lights can be used around swimming pools or in pool houses where water resistance is crucial.



Spa or Wellness Areas: Waterproof downlights are ideal for use in spa environments where high humidity and moisture are present.



Industrial Settings: In industrial environments where dust, moisture, or water exposure can be an issue, waterproof lighting like these downlights can be beneficial.



Retail or Commercial Spaces: These downlights can also be used in retail stores, restaurants, or other commercial spaces where water resistance and durability are needed.



Overall, the waterproof downlights from the Dragonfly-1 Family are versatile and can be applied in a variety of indoor and outdoor settings where moisture resistance and quality lighting are required.
