Factory Price 100lm/W 10W 12W 18W 20W 25W 30W IP65 Waterproof Recessed LED Spot Light LED Down Light for Bathroom Swimming Pool Kitchen

Contact Now

Factory Price 100lm/W 10W 12W 18W 20W 25W 30W IP65 Waterproof Recessed LED Spot Light LED Down Light for Bathroom Swimming Pool Kitchen

Minimum Order Quantity :	1	Price :	8

Certification:	CCC, CE, RoHS, SAA

Detail Information
Housing Colour:	White/Black/Rose Gold/Bronze/Silver	CRI(Ra):	Ra80+/Ra90+
PF:	10-12W≥0.50, 20W≥0.95	CCT Adjustable:	2700-6000K Tunable As Optional If Need
Operating Temperature:	-20 0c ~50 0c	Power:	10W/12W/18W/20W/25W/30W
Luminous Flux:	100lm/W	IP Rating:	IP65
Installation:	Recessed	Lifespan:	≥50000hrs
Dimmable:	Non-Dim/Triac/0-10V/Dali-2 Dimmable As Options	Color Temperature:	2700K/3000K /3500K/ 4000K / 5000K /6000K
Lamp Body Material:	Die-Casting Aluminum	LED Driver:	Done/Aohua/Lifud/Eaglerise Brand For Different Dim
Reflector Color:	Matte White/Matte Silver/Matte Black/Bright Sliver
Highlight:	IP65 waterproof LED down light , recessed LED spot light for bathroom , high lumen LED down light

Product Description

High-Efficiency Waterproof LED Downlight

Factory-priced recessed LED spot lights offering 100lm/W efficiency with IP65 waterproof rating, suitable for bathrooms, swimming pools, kitchens, and various wet environments.

Technical Specifications

Model	MF-HGS20-S10W/12W/18W/20W/25W/30W
Input Voltage	100-277Vac or 200-240Vac, 50hz/60hz
Power	10W/12W/18W/20W/25W/30W
Color Temperature	2700K/3000K/3500K/4000K/5000K/6000K
LED Chip	O-SRAM/Bridgelux
LED Driver	DONE/Aohua/Lifud/Eaglerise Brand for different dim version
Power Factor	10-12W ≥0.50, 20W ≥0.95
Housing Color	White/Black/Rose Gold/Bronze/Silver
Reflector Color	Matte White/Matte Silver/Matte Black/Bright Silver/Gun Black/Rose Gold/Bronze
Luminous Flux	100LM/W
CRI (Ra)	Ra80+/Ra90+
Lifespan	≥50,000 hours
Beam Angle	24°, 36°, 55°
Material	Die-casting Aluminum
Operating Temperature	-20°C ~50°C
Dimmable	Non-Dim/Triac/0-10V/DALI-2 dimmable as options
CCT Adjustable	2700-6000K Tunable as optional
IP Rating	IP65
UGR	< 19
Certificate	CE/RoHS (Whole Lamp); CE/ROHS/CB/SAA (Driver)
Warranty Period	3 years

Product Design Features

Advanced Engineering Components

Waterproof Screw: Prevents moisture ingress for long-lasting durability
Upgraded Optical Lens: Enhanced light focusing effect with beautiful wide beam angle
Uniquely Shaped Radiator: Made of die-cast aluminum for powerful and reliable heat dissipation

Multi-layer Anti-Glare for Comfortable Eye Protection
We use an extended lamp cup to increase the distance between the light source and the light outlet, ensuring glare-free illumination right from the light exit.

Key Product Features

IP65 Waterproof Rating: Full waterproof and dustproof design suitable for wet areas like bathrooms and outdoor spaces
Long Lifespan: Integrated die-cast aluminum heat sink ensures lifespan of 50,000 hours or more
Anti-Glare Design: Deep recessed structure with UGR<19 provides eye-friendly lighting for bedrooms and offices
Flexible Dimming Options: Supports Non-Dim, TRIAC, 0-10V, and DALI dimming with smart control via APP
Wide Color Temperature Range: Available in 2700K to 6000K, with tunable CCT options for customized lighting scenes
High Luminous Efficiency: Delivers 100 lumens per watt with high CRI options (Ra80+/Ra90+) for accurate color rendering
Multiple Housing Colors: Available in White, Black, Rose Gold, Bronze, and Silver to match various interior styles

Installation Instructions

Easy Spring Clip Installation

Ceiling Hole Cutting: Use appropriate tools to cut a hole in the ceiling according to the size of the corresponding luminaire
Connect the Wires: Connect the wires to the luminaire terminals correctly according to the installation manual. It is best to be operated by a professional electrician
Insert into the Ceiling: Align the spring clips on both ends of the product vertically and insert it into the ceiling hole
Lower the Spring Clips: After confirming that the hole size fits the product and the wiring is correct, lower the clips, then you can turn on the power for use

Product Dimensions

Product Applications

MF-HGS20-S are designed for recessed installation and are suitable for various applications that require waterproof lighting solutions:

Outdoor Lighting: These waterproof downlights can be used for outdoor applications where exposure to the elements is a concern, such as in outdoor walkways, gardens, or building exteriors
Bathroom Lighting: Due to their waterproof design, these downlights are suitable for use in bathrooms and other wet areas where moisture resistance is essential
Kitchen Lighting: In kitchens where steam and cooking splashes are common, waterproof downlights can provide both functional and aesthetic lighting solutions
Swimming Pool Areas: These lights can be used around swimming pools or in pool houses where water resistance is crucial
Spa or Wellness Areas: Waterproof downlights are ideal for use in spa environments where high humidity and moisture are present
Industrial Settings: In industrial environments where dust, moisture, or water exposure can be an issue, waterproof lighting like these downlights can be beneficial
Retail or Commercial Spaces: These downlights can also be used in retail stores, restaurants, or other commercial spaces where water resistance and durability are needed
