MF-HGS10 Frameless LED Downlight
IP20/IP44 rated aluminum downlight with anti-glare technology, offering tunable color temperature from 2700K to 6000K. Ideal for exhibition halls, residential, and commercial interior lighting applications.
Product Overview
The MF-HGS10 series frameless COB recessed spotlights feature integrated die-cast aluminum construction for superior heat dissipation. Available in multiple power configurations from 7W to 35W with various cutout sizes to accommodate different ceiling requirements.
Key Features
- Multiple power options: 7W, 10W, 12W, 15W, 20W, 25W, 30W, 35W
- Cutout sizes: 55mm, 75mm, 95mm for versatile installation
- Beam angles: 8°, 15°, 24°, 38°, 55° for precise lighting control
- Full CCT range: 2700K to 6000K with tunable options
- Premium COB chips including CREE and OSRAM
- High CRI Ra90+ for accurate color rendering
- Low UGR less than 19 for eye-friendly anti-glare lighting
- 360° rotation and 30° tilt adjustment capability
- Multiple dimmable driver options: Triac, 0-10V, DALI
- 50,000-hour lifespan with 3-year warranty
Technical Specifications
| Model |
MF-HGS10-7W / MF-HGS10-10W / MF-HGS10-12W / MF-HGS10-15W / MF-HGS10-20W / MF-HGS10-25W / MF-HGS10-30W / MF-HGS10-35W |
| Power |
7W/10W/12W/15W/20W/25W/30W/35W |
| Input Voltage |
AC 200-240V |
| LED Chip |
Bridgelux / OSRAM as optional |
| Color Temperature |
2700K/3000K/4000K/5000K/6000K |
| CRI (Ra) |
Ra80+/Ra90+ |
| Beam Angle |
8°,15°,24°,38°,55° |
| Material |
Die-casting Aluminum |
| Dimmable |
Non-Dim / Triac dimmable as optional |
| UGR |
<19 |
| LED Driver |
Lifud/BOKE/Tridonic/Novbo as optional, Optional 0-10V/DALI |
| Power Factor |
5-15W≥0.50 20-80W≥0.95 |
| Lifespan |
≥50,000 hours |
| Operating Temperature |
-20℃ ~50℃ |
| CCT Adjustable |
2700-6000K Tunable as optional |
| Certificate |
CE/ RoHS (Whole Lamp) CE/ROHS/CB/SAA(Driver) |
| Warranty Period |
3 years |
Product Gallery
Manufacturer Information
With over 14 years of experience in research, development, and manufacturing, we operate under ISO quality management standards since 2009, ensuring premium quality LED lighting solutions.
Frequently Asked Questions
Are you a manufacturer?
Yes, we are a manufacturer with our own factory. We have over 14 years of experience in research and development, as well as manufacturing, and we operate based on ISO quality management since 2009.
Can I order a sample of the LED Light?
Yes, we welcome sample orders to test and check the quality of our products. Mixed samples are also acceptable.
What is the lead time for the LED Light?
For sample orders, the lead time is 3-7 days, and for mass production orders, it is 15-25 days. The exact lead time depends on the order quantities.
How do you ship the finished products?
We offer optional shipping methods such as by SEA, AIR, or Express (DHL, UPS, FedEx, TNT, etc.).
Can I print my logo on the LED Light?
Yes, we provide OEM service to our customers. We can help to make the label and color box according to your requirements.
How do I proceed with an order for the LED Light?
Firstly, please let us know your detailed requirements and application environment. Secondly, we will recommend some suitable products and solutions to you based on your request. Thirdly, after confirming all the details, customers will issue a purchase order and make the payment to confirm, and then we will start production and arrange shipment.
How do you handle defective products?
All of our products are produced in strict quality control systems, and the defective rate is less than 0.2% according to our shipment records. We offer a 3-year warranty for this product. If there is any defect during the warranty period, please provide pictures or videos of the defective lights in working situations, and we will ship new lights to you within a few days or together with your next order.
