Factory Price Spring Leaf Tunable Dali 7W/10W/12W/15W/20W/25W/30W LED Spot Light LED Down Light Recessed Down Light for Bathroom Kitchen

Contact Now

Factory Price Spring Leaf Tunable Dali 7W/10W/12W/15W/20W/25W/30W LED Spot Light LED Down Light Recessed Down Light for Bathroom Kitchen

Minimum Order Quantity :	1	Price :	7.4

Certification:	CCC, CE, RoHS, SAA

Detail Information
Color Temperature:	2700K/3000K/3500K/4000K/5000K/6000K	PF:	7-15W≥0.50, 20W≥0.95
Operating Temperature:	-20°C ~50°C	CCT Adjustable:	2700-6000K Tunable
Specification:	40.516.543CM	Luminous Flux:	100lm/W
LED Chip:	O-Sram/Brid-Gelux	Housing Colour:	White Ring
Power:	7W/10W/12W/15W/20W/25W/30W	Dimmable:	Non-Dim/Triac/0-10V/Dali-2 Dimmable
IP Rating:	IP20/IP44	Ugr:	<19
CRI(Ra):	Ra80+/Ra90+	Lamp Body Material:	Die-Casting Aluminum
Lifespan:	≥50000hrs
Highlight:	tunable LED down light , recessed LED spot light , bathroom kitchen LED down light

Product Description

Factory Price Spring Leaf Tunable Dali LED Spot Light

Available in 7W, 10W, 12W, 15W, 20W, 25W, and 30W versions, this recessed downlight is ideal for bathroom, kitchen, and various commercial applications.

Technical Specifications

Model	MF-HGS10-7W/10W/12W/15W/20W/25W/30W
Input Voltage	100-277Vac or 200-240Vac, 50hz/60hz, DC24V available
Power	7W/10W/12W/15W/20W/25W/30W
Color Temperature	2700K/3000K/3500K/4000K/5000K/6000K, 2700-6500K Tunable
LED Chip	O-SRAM/Bridgelux
LED Driver	Aohua/Weiye/Lifud/BOKE Brand for different dim version
PF	7-15W≥0.50, 20W≥0.95
Housing Colour	White Ring
Luminous Flux	100-110LM/W
CRI (Ra)	Ra80+/Ra90+
Lifespan	≥50000hrs
Beam Angle	8°/15°/24°/38°/55°
Material	Die-casting Aluminum
Operating Temperature	-20°C ~50°C
Dimmable	Non-Dim/Triac/0-10V/Dali-2 dimmable as options
CCT Adjustable	2700-6000K Tunable as optional
IP Rating	IP44
UGR	< 19
Certificate	CE/RoHS (Whole Lamp); CE/ROHS/CB/SAA (Driver)
Warranty Period	3 years

Product Details

Product Features

Long Lifespan: Integrated die-cast aluminum heat sink ensures lifespan of 50,000 hours or more
Anti-Glare Design: Deep recessed structure with UGR<19 provides eye-friendly lighting for bedrooms and offices
Flexible Dimming Options: Supports Non-Dim, TRIAC, 0-10V, and DALI dimming with smart control via APP
Wide Color Temperature Range: Available in 2700K to 6000K, with tunable CCT options for customized lighting scenes
High Luminous Efficiency: Delivers 100 lumens per watt with high CRI options (Ra80+/Ra90+) for accurate color rendering

Installation Instructions

Easy Spring Clip Installation

Ceiling Hole Cutting: Use appropriate tools to cut a hole in the ceiling according to the size of the corresponding luminaire
Connect the Wires: Connect the wires to the luminaire terminals correctly according to the installation manual. It is best to be operated by a professional electrician
Insert into the Ceiling: Align the spring clips on both ends of the product vertically and insert it into the ceiling hole
Lower the Spring Clips: After confirming that the hole size fits the product and the wiring is correct, lower the clips, then you can turn on the power for use

Product Dimensions

Product Applications

MF-HGS21-TR are designed for recessed installation and are suitable for various applications that require waterproof lighting solutions such as:

Outdoor Lighting: Outdoor walkways, gardens, or building exteriors
Bathroom Lighting: Bathrooms and other wet areas where moisture resistance is essential
Kitchen Lighting: Kitchens where steam and cooking splashes are common
Swimming Pool Areas: Around swimming pools or in pool houses where water resistance is crucial
Spa or Wellness Areas: Spa environments where high humidity and moisture are present
Industrial Settings: Industrial environments where dust, moisture, or water exposure can be an issue
Retail or Commercial Spaces: Retail stores, restaurants, or other commercial spaces where water resistance and durability are needed
