Factory Price Anti-Glare High Luminous Efficiency IP20 7W/10W/12W/15W/20W LED Spot Light LED Down Light Recessed Down Light for Bathroom Kitchen

Minimum Order Quantity : 1 Price : 11.4
Certification: CCC, CE, RoHS, SAA

Detail Information

Color Temperature: 2700K/3000K/3500K/4000K/5000K/6000K IP Rating: IP20/IP44
Ugr: <19 Specification: 40.5*16.5*43CM
Power: 7W/10W/12W/15W/20W Luminous Flux: 100lm/W
PF: 7-15W≥0.50, 20W≥0.95 Lifespan: ≥50000hrs
CRI(Ra): Ra80+/Ra90+ Operating Temperature: -20°C ~50°C
LED Driver: Aohuaweiye/Lifud/Boke Brand For Different Dim Vers Dimmable: Non-Dim/Triac/0-10V/Dali-2 Dimmable As Options
LED Chip: O-Sram/Brid-Gelux Lamp Body Material: Die-Casting Aluminum
Beam Angle: 8°/15°/24°/38°/55°
Highlight:

anti-glare LED down light

,

high luminous efficiency recessed down light

,

IP20 LED spot light

Product Description

Product Overview
Factory Price Anti-Glare High Luminous Efficiency IP20 LED Spot Light - Available in 7W, 10W, 12W, 15W, and 20W models. Ideal recessed down lighting solution for bathrooms, kitchens, and commercial spaces.
LED Down Light product overview showing modern recessed design
Technical Specifications
ModelMF-HGS10F-7W/10W/12W/15W/20W
Input Voltage100-277Vac or 200-240Vac, 50hz/60hz, DC24V available
Power7W/10W/12W/15W/20W
Color Temperature2700K/3000K/3500K/4000K/5000K/6000K, 2700-6500K Tunable
LED ChipO-SRAM/Bridgelux
LED DriverAohua/Weiye/Lifud/BOKE Brand for different dim versions
Power Factor7-15W≥0.50, 20W≥0.95
Housing ColorWhite Ring
Luminous Flux100-110 LM/W
CRI (Ra)Ra80+/Ra90+
Lifespan≥50,000 hours
Beam Angle8°/15°/24°/38°/55°
MaterialDie-casting Aluminum
Operating Temperature-20°C ~50°C
DimmableNon-Dim/Triac/0-10V/Dali-2 dimmable as options
CCT Adjustable2700-6000K Tunable as optional
IP RatingIP44
UGR< 19
CertificateCE/RoHS (Whole Lamp); CE/ROHS/CB/SAA (Driver)
Warranty Period3 years
Product Details
Close-up view of LED down light construction and components LED down light installation view showing spring clip mechanism LED down light side profile and dimensional details LED down light illuminated demonstration
Key Features
  • Long Lifespan: Integrated die-cast aluminum heat sink ensures lifespan of 50,000 hours or more
  • Anti-Glare Design: Deep recessed structure with UGR<19 provides eye-friendly lighting for bedrooms and offices
  • Flexible Dimming Options: Supports Non-Dim, TRIAC, 0-10V, and DALI dimming with smart control via APP
  • Wide Color Temperature Range: Available in 2700K to 6000K, with tunable CCT options for customized lighting scenes
  • High Luminous Efficiency: Delivers 100 lumens per watt with high CRI options (Ra80+/Ra90+) for accurate color rendering
LED down light performance demonstration in various settings LED down light technical specifications and performance data LED down light application examples in commercial spaces
Installation Instructions
Easy spring clip installation diagram for LED down lights
Easy Spring Clip Installation
  1. Ceiling Hole Cutting: Use appropriate tools to cut a hole in the ceiling according to the size of the corresponding luminaire
  2. Connect the Wires: Connect the wires to the luminaire terminals correctly according to the installation manual. Professional electrician recommended
  3. Insert into the Ceiling: Align the spring clips on both ends of the product vertically and insert it into the ceiling hole
  4. Lower the Spring Clips: After confirming proper fit and correct wiring, lower the clips and turn on power for use
Product Dimensions
Detailed dimensional drawing of LED down light with measurements
Product Applications
Outdoor Lighting: Waterproof downlights for outdoor walkways, gardens, or building exteriors
Bathroom Lighting: Suitable for bathrooms and wet areas where moisture resistance is essential
Kitchen Lighting: Functional and aesthetic lighting solution for kitchens with steam and splashes
Swimming Pool Areas: Ideal for pool areas and pool houses where water resistance is crucial
Spa or Wellness Areas: Perfect for spa environments with high humidity and moisture
Industrial Settings: Beneficial for industrial environments with dust, moisture, or water exposure
Retail or Commercial Spaces: Suitable for retail stores, restaurants, and commercial spaces requiring water resistance and durability
LED down light application in commercial retail environment LED down light installation in modern architectural setting
