Anti-Glare COB Recessed LED Spot Downlight Optical Lens,15-55° Beam Angle,0-30° Adjustable Illumination,110Vac 5CCT DIP & 200-240VAC Dimmable Recessed Spotlight

Contact Now

Anti-Glare COB Recessed LED Spot Downlight Optical Lens,15-55° Beam Angle,0-30° Adjustable Illumination,110Vac 5CCT DIP & 200-240VAC Dimmable Recessed Spotlight

Minimum Order Quantity :	1PC	Price :	US$6.9-11.6/PC
Packaging Details :	523724.5CM,11.0KG/50PCS	Delivery Time :	7days
Payment Terms :	T/T	Supply Ability :	5, 000PCS/Month

Place of Origin:	China	Brand Name:	MF
Certification:	CE/ RoHS（Whole Lamp）; CE/ROHS/CB/SAA(Driver)	Model Number:	MF-DLT15-40W

Detail Information
Input Voltage:	200-240Vac Or 110Vac, 50hz/60hz, DC24V Available	Power(watt):	7W/10W/12W/15W/20W/25W
Color Temperature:	2700K/3000K /3500K/ 4000K / 5000K /6000K, 2700-6000K Tunable	LED Chip:	Bridgelux COB
Housing Colour:	White/Black	Reflector Color:	Matte White/Matte Silver/Matte Black/bright Sliver/Gun Black/Rose Gold/Champagne Gold
Luminous Flux (lm):	110-120LM/W	CRI（Ra）:	Ra90+
Lifespan:	≥50000hrs	Material:	Die-casting Aluminum
IP:	IP20/IP44

Product Description

Anti-Glare LED Spot Downlight MF- HGS23 Family-Lens Version

Anti-Glare COB Recessed LED Spot Downlight Optical Lens,15-55° Beam Angle,0-30° Adjustable Illumination,110Vac 5CCT DIP & 200-240VAC Dimmable Recessed Spotlight

MF-HGS23 is an anti-glare LED spot downlight made of die-cast aluminum. It delivers high-quality lighting with CRI>90, UGR<19 anti-glare performance and multiple beam angle options of 15°/24°/36°/55°.

The lamp body supports 0-30° angular adjustment with smooth, comfortable hand-feel when tilting to aim light where you need. It offers rich CCT selections, various dimming modes including TRIAC, 0-10V, DALI and Tuya smart control. Rated IP20/IP44, it has a 50000-hour lifespan and comes with 5-year warranty, ideal for home, retail and commercial indoor lighting.

Anti-Glare COB Recessed LED Spot Downlight Optical Lens,15-55° Beam Angle,0-30° Adjustable Illumination,110Vac 5CCT DIP & 200-240VAC Dimmable Recessed Spotlight

Parameters:
Model	MF-HGS23-7W/10W/12W/15W/20W/25W
Input voltage	200-240Vacor 110Vac, 50hz/60hz, DC24V available
Power(watt)	7W/10W/12W/15W/20W/25W
Color temperature	2700K/3000K /3500K/ 4000K / 5000K /6000K, 2700-6000K Tunable
LED Chip	BridgeluxCOB
LED Driver	Aohuaweiye/Lifud/BOKEBrand for different dim version
PF	7-15W≥0.50, 20W-25W≥0.95
Housing Colour	White/Black
Reflector color	Matte White/Matte Silver/Matte Black/bright Sliver/Gun Black/Rose Gold/Champagne gold
Luminous Flux (lm)	110-120LM/W
CRI(Ra)	Ra90+
Lifespan	≥50000hrs
Beam Angle	15°/24°/36°/55°
Material	Die-casting Aluminum
Operating Temperature	-200C ~500C
Dimmable	Non-Dim/Triac/0-10V/Dali-2/Tuyadimmable as options
CCT Adjustable	2700-6000K Tunable as optional if need
IP	IP20/IP44
UGR	<19
Certificate	CE/ RoHS(Whole Lamp); CE/ROHS/CB/SAA(Driver)
Life Spain	≥50,000Hrs
Warranty Period	5years

Product Features

IP20/IP44 Protect Rating: Anti-humid and dustproof design suitable for wet areas like bathrooms spaces.

Long Lifespan: Integrated die-cast aluminum heat sink ensures lifespan of 50,000 hours or more.

Anti-Glare Design: Deep recessed structure with UGR<19 provides eye-friendly lighting for bedrooms and offices.

Flexible Dimming Options: Supports Non-Dim, TRIAC, 0-10V, Tuya and DALI dimming with smart control via APP.

Wide Color Temperature Range: Available in 2700/3000K/ 3500K/4000/ 5000K/6000K for 200-240Vac input version, American Standard 110Vac Driver support DIP 5 CCT 2700K-3000K-3500K-4000K-5000K.

High Luminous Efficiency: Delivers 110-120 lumens per watt with high CRI >90 for accurate color rendering.

Multiple reflector Colors: Available in Matte White/Matte Silver/Matte Black/bright Sliver/Gun Black/Rose Gold/ Champagne gold

Multi-level adjustable beam angle: 15°/24°/36°/55°, Also The illumination angle of the lamp body can be adjusted 0-30 °.

Anti-Glare COB Recessed LED Spot Downlight Optical Lens,15-55° Beam Angle,0-30° Adjustable Illumination,110Vac 5CCT DIP & 200-240VAC Dimmable Recessed Spotlight

Power	Carton Size(cm)	G.W(KG)	PCS/CTN
7W	*523724.5CM*	11.0KG	50PCS
10W	603730CM	13.5KG	30PCS
12W	603730CM	13.5KG	30PCS
15W	603730CMM	13.5KG	30PCS
20W	703133CM	14.6KG	20PCS
25W	703133CM	14.6KG	20PCS

Anti-Glare COB Recessed LED Spot Downlight Optical Lens,15-55° Beam Angle,0-30° Adjustable Illumination,110Vac 5CCT DIP & 200-240VAC Dimmable Recessed Spotlight
