Product Description
80W LED contruction light for tunnels,bridges,hotels, landscapes, construction zone,disaster sight, outside building.
80W LED contruction light data sheet down load: MF-FL-80S Tech data sheet.pdf
Product Features:
1.material is made of PC , Japan brand. UV-resistance, high light transmittance 92%+
2. Symetric lens of beam angle 30°,60°, 90°, 120° and asmytric lens beam of 60°x135° and 85°x135° for various applications.
3. Certified by CE,CB, ENEC, GS, RoHS, and UL listed, DLC, SAA, EMC, LM-79,PSE certificates are available, MF-FL-80S is a universal version for all around the world.
4. Little fuse SPD is available for 10KV and 20KV, work stable even in unstable power grid.
.
5. IES files and photometric test reports are vailable, highly skilled engineer and designer team can provide light calculations and solutions for all kinds of applications
6. 280° angle adjustable bracket, heavy duty design.
80W LED Construction Lights Specifications:
|
Item
|
MF-FL-80S
|
|
Input voltage
|
85-265Vac 50Hz/60Hz
|
|
LED Power
|
77W
|
|
System Consumption
|
80W
|
|
Delivered Flux
|
80x130lm,80x160lm
|
|
IP Rating
|
IP67
|
|
Beam Angle
|
30°,60°, 90° and 120° ,asymetric lens 135°x60° and 135°x85°
|
|
Color temperature
|
3000K / 5000K / 6000K
|
|
LED Chip
|
Lumileds |
|
LED Driver
|
Meanwell
|
|
Color Rendering Index
|
Ra>80,70 as options
|
|
Power Factor
|
≧0.90
|
| Color of Housing |
Black in stock, grey, white as options |
|
Lifespan
|
1000,000hrs @ conditions, regular life span:50,000 hours, 9 years.
|
|
Operation Environment
|
Temperature:-30°C~45°C/Humidity:10%~90%
|
| Storge Temperature |
-40°C~50°C(@25°C) |
|
Material
|
Anti-corrosion Die Cast Aluminum Alloy
|
|
Product Size(mm)
|
377(L)x 321(W)x 91(H)
|
|
Net Weight
|
5.60 Kg/PCS. 1PCS/CTN
|
|
Certificate
|
CE/RoHS/TUV/ETL/GS/SAA/FCC/DLC
|
|
Warranty Period
|
5 years,and 10 years @ conditions
|
Competitive Advantage:
1.Lumileds chips, 130lm/w or 160lm/W, CRI up to Ra80. Junction temperature <75°C.
2.World Calss Brand, MeanWell LED Drivers, wide AC90V~305V, PF>0.98, low THD<15%.Built-in Mean well drivers, make the lamp safer for operation.
3.L70>80,000hrs. Design lifespan 100,000hrs @ conditions.9 years @ 15 hours/day.
4.Adjustable to project aimed lighting area accurately.
5. Constant current design, much more reliable in life-span.
6. Japan secondary optical DIWL lens, light transmittance up to 92%.
7. Intelligent dimming system, 1-10V, Dali, PWM dimming models are available
8. Certificated: CE, TUV, RoHS,ETL,CB,SAA, FCC, DLC
Application photos
