Product Description
FEATURES&BENEFITS
HOUSING
1.Die cast aluminum housing.
2.Modular design allows for easy installation, replacement and maintenance. This design also creates a chimney effect which provides exceptional thermal management.
3.Meets 3G vibration per ANSI C136.31-2010.
4.IK10 rated
FINISH
1.Corrosion resistant polyester powder painted 100μm thickness.
2.Meets a 1000-hour salt spray certification per ASTM B117/ ISO 9227:2012.
3.Standard colors: Grey, Black, Bronze and White.
4.Customized colors are available.
LED ＆ OPTICAL ASSEMBLY
1.Each PCB are mounted with a TVS (Transient Voltage Suppressors) to protect the LEDs from voltage transients induced by lightning and other transient voltage events.
2.High-uniformity LED optics are constructed of durable optical polycarbonate that is impact and UV resistant.
3.The metal plate provides double protection for the LED light engine and prolongs LED optics life.
4.Over 15 optical lenses are available for virtually any application.
5.Each LED module are 100% tested prior to assembly which is IP67 rated.
MOUNTING
1.Extremely flexible with 360 degree rotation.
2.Interchangeable with the other GAMA Series with a bracket change.
3.Brackets are available for different installations.
Electrical/ Key Components/ Controls
1.220-240VAC and 120-277VAC available.
2.Surge protection to 20kV/10kA per ANSI/IEEE C62.41.2-2002 available.
3.High quality LEDs, driver and components, e.g. MOLEX, WAGO connectors.
4.Multiple smart lighting control options are available, e.g. photocell, motion sensor, 1-10V.
|
Model No.
|
System
Power
|
|
LEDs
|
EPA
(sq.ft)
|
Net Weight
|
Gross Weight
|
Product deminsions |
Carton Dimensions
|
Drive
Current
|
Luminous Flux(5000K)
|
Efficacy
(lm/W)
|
|
MFA60-C
|
60W |
1 |
18 |
0.324 |
4.45KG |
5.14KG |
5.91" x 13.58" x 4.41"
|
14.37" x 16.34" x 6.3"
|
1050mA
|
8100lm
|
135 |
|
MFA120C
|
120W |
2 |
36 |
0.347 |
5.56KG |
6.62KG |
8.27" x 13.58" x 4.41"
|
14.37" x 16.34" x 6.3"
|
16200lm
|
135 |
|
MFA180C
|
180W |
3 |
54 |
0.372 |
6.38KG |
7.21KG |
10.63" x 13.58" x 4.41"
|
16.73" x 16.34" x 6.3"
|
24300lm
|
135 |
|
MFA240C
|
240W |
4 |
72 |
0.404 |
7.1KG |
8.22KG |
12.99" x 13.58" x 4.41"
|
16.73" x 16.34" x 6.3"
|
32400lm
|
135 |
|
MFA300C
|
300W |
5 |
90 |
0.437 |
8.62KG |
9.59KG |
17.72" x 13.58" x 4.41"
|
21.46" x 16.34" x 6.3"
|
40500lm
|
135 |
LED flood lights have numerous applications across different settings due to their versatility and high-performance characteristics. Here are some common applications of LED flood lights:
1.Outdoor Lighting:
LED flood lights are extensively used for outdoor lighting purposes. They are commonly employed to illuminate large areas such as parking lots, stadiums, sports fields, building facades, parks, and gardens. Their wide beam angle and high brightness make them suitable for providing even and efficient illumination over expansive outdoor spaces.
2.Security Lighting:
LED flood lights are popularly used for security lighting due to their powerful illumination capabilities. They help enhance visibility and deter potential trespassers or intruders. LED flood lights with motion sensors are commonly used in residential, commercial, and industrial settings to provide instant and targeted lighting when motion is detected.
3.Architectural Lighting:
LED flood lights are employed for architectural lighting to highlight and accentuate the architectural features of buildings, monuments, bridges, and landmarks. Their versatility in terms of beam angles, color temperature options, and color-changing capabilities allows for creative lighting designs and dramatic effects.
4.Sports Lighting:
LED flood lights are extensively used for sports lighting applications, enabling high-quality illumination for various sporting events and activities. They are employed in stadiums, arenas, tennis courts, golf courses, and other sports facilities to provide uniform and shadow-free lighting, ensuring optimal visibility for players and spectators.
5.Billboard and Signage Lighting:
LED flood lights are commonly used for illuminating billboards, signage, and advertising displays. Their high brightness, energy efficiency, and long lifespan make them a popular choice for outdoor advertising, ensuring clear visibility of promotional content both during the day and at night.
6.Industrial Lighting:
LED flood lights find application in industrial settings such as warehouses, factories, construction sites, and loading docks. They provide bright and focused lighting for tasks that require high visibility, ensuring a safe and productive working environment.
7.Landscape Lighting:
LED flood lights are utilized for landscape lighting to enhance the aesthetics of outdoor spaces such as gardens, pathways, trees, and water features. They can be used to create different lighting effects, highlight focal points, and add ambiance and drama to landscapes.
8.Event Lighting:
LED flood lights are often employed for event lighting purposes, such as concerts, festivals, weddings, and stage productions. They offer versatile lighting options, including color-changing capabilities, to create dynamic and visually stunning lighting displays.
