High Power LED Flood Light 140lm/W IP67 Sanan Chip 100W/1200W Wide Voltage Dimmable Agricultural Fields Parking Lots For Public Areas

Contact Now

High Power LED Flood Light 140lm/W IP67 Sanan Chip 100W/1200W Wide Voltage Dimmable Agricultural Fields Parking Lots For Public Areas

Minimum Order Quantity :	1PCS	Packaging Details :	210x160x28mm
Delivery Time :	7 weeks days	Payment Terms :	L/C, D/A, D/P, T/T, Western Union
Supply Ability :	5000pcs/months

Place of Origin:	China	Brand Name:	MF
Certification:	TUV,CB,CE,SAA,RoHs	Model Number:	MF-TM07

Detail Information
Power:	100W-1200W	Projection Distance:	Depends On Power
IP Rating:	IP67	Operating Voltage:	100-277 VAC
Input Voltage:	100-277 VAC	LED Chips Brand:	Sanan
Ik:	08	Salt Spray:	C4 Anti-Corrosion
Warranty:	5 Years	PF:	>0.95
Dimmable:	Option Of Dali / 0-10V / PWM	Working Temperature:	-40°c To +70°c
Luminous Efficacy:	140 Lm/W
Highlight:	Agricultural Fields LED Flood Light , Parking Lots LED Flood Light , 140lm/W LED Flood Light

Product Description

High Power LED Flood Light 140lm/W IP67 Sanan Chip 100W/1200W Wide Voltage Dimmable Agricultural Fields Parking Lots for Public Areas

Features:

1. High efficiency and flexible configuration

Luminous efficiency up to 140 lumens/watt, energy-saving design to reduce costs.

Power range 100W-1200W, adapting to different scenes.

The beam angle is freely adjustable and supports 360° rotation.

2. All-weather protection

IP67 waterproof and dustproof, IK08 impact resistance, suitable for extreme environments.

C4 anticorrosive coating, adapting to high corrosive environments, wide temperature resistance range.

Heat dissipation system ensures stable operation under high temperature.

3. Intelligent and Energy Saving

Supports multiple dimming protocols, easy to integrate intelligent systems.

Designed to reduce grid interference and improve energy efficiency.

Key Advantages

Power and light effect

Multi-speed power selection, adapting to the needs of the whole scene.

Intelligent drive maintains high light efficiency of 140 lumens/watt.

Protection and Stability

Military-grade protection, adapt to extreme environments.

High-efficiency heat dissipation system, prolonging the service life.

Optical Control

Flexible beam angle adjustment to meet diversified needs.

Universal bracket realizes fast positioning in complex terrains

Electrical Specification
Power	100W / 200W / 300W / 400W / 600W / 900W / 1200W
Driver Brand	MOSO
Input Voltage	100-277 VAC
Power Factor	>0.95
Dimmable Optional	DALI / 0-10V / PWM
Intelligent Control Optional	Zigbee Wireless
Working Temperature	-40°C to +70°C

Photometrical Specification
Luminous Efficacy	140 Lm/W
LED CHIP	SANAN 3035
Color Temperature	4000K / 5000K / 5700K
Color Rendering Index	>80 (Ra)
Beam Angle	10° / 30° / 60° / 90° / 120°
THD	<20%

Mechanical Specification
LED Module QTY	1 / 2 / 3 / 4 / 6 / 9 / 12
LED Module Placement	Horizontal / Vertical
Body Material	Die Cast Aluminium Housing (Black)
Mounting Type	Bracket
Mounting Location	High Mast
Cable Length	300mm (Input Cable)

Standards & Certificates
Ingress Protection	IP67
IK	IK08
Salt Spray	C4 Anti-Corrosion
Certificates	CE, RoHS
Warranty	5 Years
