Photocell Sensor Garden Light LED Street Light 240W 100W 50W Pole IP66 Ik08 Waterproof Road Sidewalks Parking Light
Contact Person : Claire Li
Phone Number : 86-15999718117
WhatsApp : +8615999718117
| Minimum Order Quantity : | 10pcs | Price : | negotiable |
|---|---|---|---|
| Delivery Time : | 1 week for sample order; 2 weeks for bulk order. | Payment Terms : | L/C, T/T, Western Union, Paypal |
| Supply Ability : | 10, 000PCS/Months |
| Place of Origin: | China | Brand Name: | MF |
|---|---|---|---|
| Certification: | CB, CE, RoHS, SAA, TUV | Model Number: | MFAXXX-L |
|
Detail Information |
|||
| Power: | 300W/240W /180W/120W/60W | Input Voltage: | 120-277VAC/220-240VAC |
|---|---|---|---|
| Luminous Efficacy: | 120-160lm/w | CCT: | 3000-5700K |
| Beam Angle: | Type I Type II Type III Type IV Type V | CRI(Ra): | 70+ |
| PF: | >0.95 | Color: | Bk/Gr/Bz/Wh |
| Thd: | <20% | LED Chip Qty: | 18 |
Product Description
60W/120W/180W/240W/300W IP67 3000-5700K AC100-277V/220-240V Ratel Family LED Parking Light for Parking Lot/Highway/Street/Roadside
Quick Details
1. IP67 60W 120W 180W 240W 300W LED High Mast Light
2. Input: 120-277VAC/220-240VAC 50-60Hz
3. Beam Angle: Type I Type II Type III Type IV Type V
4. CCT: 3000K-5700K
5. CRI: >70
6. Warranty: 5 years
Parameters
| Power |
60/120/180/240/300W
|
IP Rating |
IP67
|
| Efficacy |
135
|
LED Modules | 1/2/3/4/5 |
| LEDs | 18/36/54/72/90 | EPA(sq.ft) |
0.347 /0.347 /0.372/0.404/0.437
|
| Driver Current |
1050mA
|
Luminous Flux |
8100lm/16200lm/24300lm/32400lm/40500lm
|
| Input |
220-240V AC or 120-277V AC
|
SPD |
Optional
|
| PF |
>0.95
|
Certificate |
CUL/ DLC/ LM79/ SAA/ ENEC/ CB/ CE/ ErP/ RoHS/ IK10
|
| THD |
<20%
|
DALI |
Optional
|
| L70/L90 |
>200,000H/>60,000H
|
1-10V |
Optional
|
| Operating Temperature |
-40ºC ~ +50ºC
|
Photocell | Optional |
| Typical Efficacy |
120-160lm/W
|
Smart Control | Optional |
| ANSI CCT |
3000K/4000K/5000K/5700K
|
Optic(IESNA) |
Type I, Type II, Type III, Type IV, Type V
|
| Min CRI |
70* or 80 or 90
|
Color Options |
Grey/Black/Bronze/White
|
Product Advantages
Dimensions
| Model No. | Product Dimensions | Carton Dimensions |
|
MFA60-L
|
15.94" x 12.99" x 2.76"
|
14.37" x 16.34" x 6.3"
|
|
MFA120-L
|
18.31" x 12.99" x 2.76"
|
16.73" x 16.34" x 6.3"
|
|
MFA180-L
|
20.67" x 12.99" x 2.76"
|
19.09" x 16.34" x 6.3"
|
|
MFA240-L
|
23.03" x 12.99" x 2.76"
|
21.46" x 16.34" x 6.3"
|
|
MFA300-L
|
27.76" x 12.99" x 2.76"
|
26.18" x 16.34" x 6.3"
|
Customize Solutions
ACC
Applications
Ideal for Parking Lot, highways, viaducts, urban streets, overpasses, sidewalks, squares, schools and other outdoor lighting place.
FAQ
Q1: What do you sell?
A1: We provide good quality of floodlight, high bay light, explosion proof light, tri-proof light, downlight, and other lighting products, as well as responsible services and reliable after-sales warranty.
Q2: Is it OK to print my logo on led light product?
A2: Yes. We provide ODM and OEM services. Please inform us formally before our production and confirm the design firstly based on our sample.
Q3: How to deal with the faulty?
A3: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
Q4: Can I have a sample order for led light?
A4: Yes, we welcome sample order to test and check quality. One sample or mixed samples are acceptable.
Q5: How long time to ship the goods if place an order?
A5: Usually 7 days for sample or small order,15 working days for bulk order, but sometimes depend on the order quantity.
