Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 39.5*39.5*20.8cm/1pcs, G.W: 9.5Kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, Paypal Supply Ability : 5,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE,RoHS, DLC, TUV-GS Model Number: MF-OWL STREET LIGHT

Detail Information

CCT: 3000K/4000K/5000K/5700K/6500K Material: ADC12 Aluminum Die-Casting + PC
Power: 30W/50W/60W/80W/100W/120W/150W/180W/200W/240W IP RATE: IP66
Luminous Efficacy: 140lm/W 150lm/W Driver: Meanwell/Sosen
Lifespan: >50, 000hrs Power Factor: >0.95
Driver Efficiency: 92% Accessory: 0-10V Dim/Photocell/on Off Switch
Ik Rate: Ik08

Product Description

Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub


Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 0

  1. Lumiled /Osram chips, high brightness, low light decay & long life-time
  2. Die-casting technology with ADC12, excellent thermal management and balance the internal & external temperature, reduce chip Tj and light decay.
  3. mm tempered glass cover with 94% light transmi ance, IK08. Light Distribution: T2-M, T3-M.
  4. Pole installation. operation temperature: -35C- +50C
  5. International driver brand, overheat protection, high convert efficiency, high PF & surge protection, (1-10V,DALI2.0)


Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 1

  • Energy Efficiency: LED street lights are highly energy-efficient, consuming less electricity compared to traditional street lights, resulting in cost savings and reduced environmental impact.
  • Long Lifespan: LED street lights have a significantly longer lifespan than traditional lights, reducing the frequency of replacements and maintenance.
  • Bright and Uniform Illumination: LED street lights provide bright and uniform illumination, ensuring enhanced visibility and safety on the streets.
  • Instantaneous On/Off: LED street lights have instant on/off capabilities, eliminating the warm-up time required by traditional lighting technologies.
  • Directional Lighting: LED street lights offer directional lighting, allowing for better light control and minimizing light pollution by directing light where it is needed most.
  • Smart Lighting Controls: LED street lights can be integrated with smart lighting controls, enabling features such as dimming, remote monitoring, and adaptive lighting, optimizing energy usage and enhancing operational efficiency.

Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 2





Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 3



Model No. MF-LD-B30w MF-LD-B50w MF-1D-B60w MF-LD-B80W MF-LD-B100w MF-LD-B120W MF-LD-B150W MF-LD-B180w MF-LD-B200w MF-LD-B240w
lnput Voltage AC100-277v AC100-277v AC100-27N AC100-277N AC100-277M AC100-277v AC100-277V AC100-277v AC100-277V AC10-277v
output Voltage DC36V DC36V DC36V DC36V DC36V DC36V DC36V DC36V DC36V DC36V
Rated Power 30w 50w 60w 80w 100w 120W 150w 180W 200w 240w
Qty of LD 64PCS*2835
48PCS3030
96PCS*2835
72pCS*3030
96PCS*2835
72PCS*3030
192PCS*2835
144PCS3030
192PCS-2835
144PCS*3030
192PCS*2835
144PCS*3030
256PCS2835
192PCS-3030
256PCS*2835
192PCS*3030
384PCS*2835
288PCS*3030
384PCS*2835
288PCS*3030
PF >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95
LED Brand Lumileds Lumileds Lumileds Lumileds Lumileds Lumileds Lumileds Lumileds Lumileds Lumileds
lumhous Flux 4200m±5% 7000lm±5% 8400m±5% 11200lm±5% 14000lm±5% 16800lm±5% 21000m±5% 25200m±5% 28000lm±5% 33500m±5%
CRI Ra>70,80 Ra>70,80 Ra>70,80 Ra>70,80 Ra>70,80 R>70,80 Ra>70,80 Ra>70,80 Ra>70,80 Ra>70,80
ccr 3000-6500K 3000-6500K 3000-6500K 3000-6500K 3000-6500K 3000-6500K 3000-6500K 3000-6500K 3000-6500K 3000-6500K
Beam Angle T2-MT3-M T2-MT3-M T2-MT3-M T2-MT3-M T2-MT3-M T2-MT3-M T2-MT3-M T2-MT3-M T2-MT3-M T2-MT3-M
Driver Brand MW/SOSEN MW/SOSEN MW/SOSEN MW/SOSEN MW/SOSEN MW/SOSEN MW/SOSEN MW/SOSEN MW/SOSEN MW/SOSEN
THD <10% <10% <10% <10% <10% <10% <10% <10% <10% <10%
lK Rating IK08 IK08 IK08 IK08 IK08 IK08 IK08 IK08 IK08 IK08
lP Rating IP66 IP66 IP66 IP66 IP66 IP66 IP66 IP66 IP66 IP66
Life Span 50000Hs 50000Hrs 50000Hs 50000Hrs 50000Hrs 50000Hrs 50000Hrs 50000Hrs 5000CHrs 50000Hrs
Size 424*908*94mm 424*908*94mm 424*908*94mm 519*297*111mm 519*297*111mm 610*297*111mm 610*297*111mm 610*297*111mm 610*297*111mm 610*297*111mm
Nw 2.75kg 2.75kg 2.75kg 5.15kg 5.15kg 5.15kg 6.20kg 6.20kg 7.25kg 7.25kg
Gw 3.25kg 3.25kg 3.25kg 5.90kg 5.90kg 5.90kg 5.90kg 6.90kg 8.15kg 8.15kg




Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 4
Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 5



Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 6Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 7






Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 8



Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 9

Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 10


Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 11

  1. Parking lot light
  2. Urban/Village Street
  3. Country Road
  4. Highways
  5. Garden/Park
  6. School/Square/Hospital
  7. Avenues
  8. Square and residential area.
  9. Any Large Outdoor Are,et

Robust Weather Resistant IP66 LED Street Light With Photocell 30W-240W For Platform Bus Stop Transit Hub 12

LED Street Lights are versatile lighting solutions that find extensive applications in various urban and suburban settings. Their energy efficiency, long lifespan, and superior illumination make them ideal for enhancing safety and visibility on streets and roads. Here are some key applications of LED Street Lights:
City Streets and Roads: LED Street Lights are commonly used to illuminate city streets, including main thoroughfares, residential roads, and downtown areas. They provide clear visibility for drivers, pedestrians, and cyclists, ensuring safer navigation during nighttime.
Highways and Expressways: LED Street Lights are crucial for lighting up highways and expressways, ensuring optimal visibility for high-speed traffic. Their bright and uniform illumination enhances road safety and reduces the risk of accidents.
Residential Neighborhoods: LED Street Lights are employed in residential neighborhoods to provide adequate lighting for residents and pedestrians. They contribute to a sense of security, allowing people to feel safe while walking, jogging, or engaging in outdoor activities.
Commercial Areas and Business Districts: LED Street Lights play a vital role in illuminating commercial areas and business districts. They enhance the visibility of shops, restaurants, and other establishments, creating a vibrant and welcoming atmosphere.

Pedestrian Walkways and Sidewalks: LED Street Lights are utilized to light up pedestrian walkways, sidewalks, and footpaths. They ensure the safety of pedestrians, enabling clear visibility and reducing the risk of accidents or falls.
Parking Lots and Garages: LED Street Lights are commonly installed in parking lots and garages to provide bright and efficient illumination. They improve visibility for drivers, enhancing safety and security in these areas.
Public Parks and Recreational Areas: LED Street Lights are used to illuminate public parks, playgrounds, and recreational areas. They allow people to enjoy outdoor activities even after dark, promoting safety and community engagement.
School and College Campuses: LED Street Lights are employed in school and college campuses to provide lighting for pathways, parking lots, and outdoor facilities. They ensure a safe environment for students, staff, and visitors during nighttime hours.
Industrial Complexes and Factories: LED Street Lights are utilized in industrial complexes and factories to provide efficient lighting for outdoor areas, including loading docks, storage yards, and access roads. They enhance safety and productivity in industrial settings.
Railway Stations and Platforms: LED Street Lights are installed in railway stations and platforms to provide clear visibility for commuters, ensuring their safety during boarding and alighting from trains.
Bus Stops and Transit Hubs: LED Street Lights are used to illuminate bus stops and transit hubs, providing safe and well-lit waiting areas for passengers, especially during evening hours.



Shopping Malls and Retail Centers: LED Street Lights are employed in shopping malls and retail centers to enhance visibility in parking lots and surrounding areas. They contribute to a secure and pleasant shopping experience for visitors.
Outdoor Sports Fields and Stadiums: LED Street Lights are utilized to illuminate outdoor sports fields, stadiums, and arenas. They provide excellent visibility for players, spectators, and officials, enabling nighttime sporting events and activities.
Pedestrian Bridges and Tunnels: LED Street Lights are installed on pedestrian bridges and tunnels to ensure safe passage for pedestrians, cyclists, and motorists, enhancing visibility and reducing accidents.
Tourist Attractions and Landmarks: LED Street Lights are used to highlight and illuminate tourist attractions, historical landmarks, and architectural features, enhancing their visual appeal and attracting visitors.







About us:





Our factory has been producing LED lights for indoor and outdoor applications, Such as LED down lights, LED Panel Light,LED wall light,LED tube light, LED spot light, LED track light,LED ceiling light,LED high bay light,LED tri-proof light,LED flood light, LED high mast light, LED Stadium light, LED street light, LED Garden light and LED explosion proof light. Our products are widely intalled in large-scale lighting applications, such as in large farms, factories, schools, bridges, tunnels, ports, subways,airports,minings, hospitals and many other applications.

Mingfeng specializes in LED lights, and produces and exports high-quality LED light fixtures to Asia, Europa, North American, Latin American and Pacafic ocean island for almost 132 countries, all LED lights are under ISO9001 system with professional team management, the certificate of CE, CB, ENEC,RoHS,CSA, UL, SAA and REACH are certifiedy by SGS or TUV depends on LED lights family.

MF R&D team are with passion, persistence and technology know-how to develp our LED lights, our engineers takes our LED develpment as baby care onto any single tiny details, the aim to this is that providing high quality LED lights by our vision plus knowleadge ,and at the end of story,enable an quality life and work under MF lights for all users in this planet, MF stuff knows "LIGHTS THE WORLD" is not a joke, but make it happen day by day with hard working.
