IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station
IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station
IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station
Contact Now

IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station

Minimum Order Quantity : 1PCS Delivery Time : depends on order
Supply Ability : 5000pcs/months
Place of Origin: China Brand Name: MF
Certification: CCC,CE,CQC,ETL,RoHs,SAA,ETL Model Number: EX-xxWB3YZDA

Detail Information
Lens: Tempered Glass Housing: Copper-free Aluminum
POWER: 20/40/60W Mounting Bracke: Stainless Steel
CCT Range: 2000K-7000K Voltage Range: 100V~227V
Warranty: 5Years IP: IP66
IK: IK10 Working Temp: -40°~+60
LED Driver: IEC Certified Efficiency: 140lm/w
Chip Matching: Cree·lumen·atmospherics LED Brand: SMT
Highlight:

Dimmable Explosion Proof Light

,

IEC Certifiled Explosion Proof Light

,

IK10 Explosion Proof Light

Product Description

IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 0

IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 1

>FEATURES

•Working Temperature: -40°C ~ +55°C.
•High quality SMT LED.
•Heavy-duty and high impact resistance.
•Replaceable LED board and drivers.
•Integrated junction box for driver .
•Dimmable and battery back up function available.
•Marine rating powder coated finish treatment.
•Up to 5 years warranty .
•Various installation ways for different applications.
•Glass lens or polycarbonate lens to make different beam angles.



>SPECIFICATION

Product Number Wattage Color Temperture Voltage Lumens Warranty CRI Emergency Time
EX-20W B3YZDA 20w 2200K-7000K AC200-250V/DC12-48V 2600 5YEARS 70 3Hours
EX-40W B3YZDA 40w 4200
EX-60W B3YZDA 60w AC200-250V/DC12- 48V 7800/11200

"B3,B4"=Product code."Y"=D or N D:Dimmable or N: non-dimmable "Z"=CCT, from 2200-7000k, 22 for 2200k...70 for 7000K."D"=Beam angle,D40 for 40°, D60 for 60°, D90 for 90°, D120 for 120° "A"=glass type. blank for flat glass, C for spherical glass.

>EXPLOSION PROTECTION

Marking ATEX
II 2 G Ex eb mb IIC T6...T4 Gb
II 2 D Ex tb IIIC T80°C...T100°C Db IP66
Marking IECEx
Ex eb mb IIC T6...T4 Gb
Ex tb IIIC T80°C...T100°C Db IP66
Marking UL844 (North American)
Class I, Division 2, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G
Class III
Marine Marking
UL1598, UL1598A
ABS
Other Rating
IP 66
>MATERIALS
• Housing: Copper-free aluminum
• Lens: Tempered Glass
• Mounting Bracket: Stainless steel
• Hardware: Stainless steel
>ACCESSORIES

IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 2



IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 3





IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 4



IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 5



IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 6





IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 7

IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 8



IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 9

1. Petrochemical enterprises
With the rapid expansion of petrochemical enterprises, the level of labor protection technology has also been correspondingly improved. Petrochemical industry is a continuous large-scale production that is technology intensive and capital intensive
Full production is particularly important, and explosion-proof lamps are one of the necessary equipment for safe production in the petrochemical industry.
2. Ports and docks
Ports and docks are used to handle and store the increasing amount of crude oil, liquefied natural gas, and sensitive grain, all of which increase the need for on-site use of hazardous area lighting
Seek. The nature of port applications and their coastal location also require the use of anti slow lighting fixtures.
3. Offshore Platforms
The nature of offshore platforms provides a challenging environment for designated lighting- Once a danger occurs, the relevant areas of the platform may experience or accumulate explosive hazards
Gas. When this gas reaches the explosive concentration range and encounters an open flame, it will explode. Considering continuous exposure to ocean conditions such as high wind speeds and saline environments, high quality and
Durable explosion-proof lighting fixtures that can withstand these factors are crucial.
IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 10
IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 11
IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 12





IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 13

IP66 IK10 IEC Certifiled 20W 40W 60W Dimmable Explosion Proof Light For Ocean Vessel Pumping Station 14
