Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication
Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication
Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication
Contact Now

Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication

Minimum Order Quantity : 1PCS Delivery Time : depends on order
Supply Ability : 5000pcs/months
Place of Origin: China Brand Name: MF
Certification: CCC,CE,CQC,ETL,RoHs,SAA,ETL Model Number: EX-xxWX3YZDA

Detail Information
Lens: Glass Housing: Copper-free Aluminum
POWER: 20/40/60W Mounting Bracke: Stainless Steel
CCT Range: 2000K-7000K Voltage Range: 100V~227V
Warranty: 5Years IP: IP66
IK: IK10 Working Temp: -20°~+60
LED Driver: IEC Certified Efficiency: 140lm/w
Chip Matching: Cree·lumen·atmospherics LED Brand: SMT
Power: 18/38/45W
Highlight:

45W Explosion Proof Light

,

Metal Smelting Fabrication Explosion Proof Light

,

High Quality Explosion Proof Light

Product Description

Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 0

Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 1

>FEATURES

Compact structure, small size and light weight for easy installation.
High vibration and impact resistant.
Protective metal cage against light potential damage.
Working Temperature: - 20ºC ~ +60ºC.
Impact resistant and thermally stable toughened glass



>SPECIFICATION

Product Number Wattage Color Temperture Voltage Lumens Warranty CRI
EX-18WX3YZDA 18w 2200K-7000K AC100-277/220-480V 2520 5YEARS 80
EX-36WX3YZDA 36w 5040
EX-45WX3YZDA 45w 6300
"x"=Product code, "Y"=D or N:Dimmable or non-dimmable "Z"=CCT, from 2200-7000K
"D"=Beam angle, D40 for 40°, D60 for 60°, D90 for 90°, D120 for 120°
A for glass info. blank for flat glass, c for spherical glass.

>EXPLOSION PROTECTION

Marking ATEX
II 2 G Ex eb mb IIC T6 Gb
II 2 D Ex tb IIIC T80°C...T100°C Db IP66
Marking IECEx
Ex eb mb IIC T6 Gb
Ex tb IIIC T80°C...T100°C Db IP66
Marking UL844 (North American)
Class I, Division 2, Groups A, B, C, D
Class II, Division 2, Groups F, G
Class III
Marine Marking
UL1598A
Other Rating
IP 66
NEMA3,4X
>MATERIALS
• Housing: Copper-free aluminum
• Lens: Tempered Glass
• Mounting Bracket: Stainless steel
• Hardware: Stainless steel
>ACCESSORIES

Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 2



Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 3





Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 4



Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 5



Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 6Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 7

Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 8Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 9





Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 10

Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 11



Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 12

Explosion-proof lights are specifically designed to operate safely in hazardous environments where there is a risk of explosive gases, vapors, or dust particles. These lights are constructed with robust materials and feature specialized components to prevent the ignition of flammable substances and reduce the likelihood of explosions.
Lighting:
Mini tunnels often require adequate illumination to ensure visibility for workers, equipment operators, or drivers. Explosion-proof lights provide reliable and consistent lighting in these confined spaces, enhancing safety and productivity.
Hazardous Environment Protection:
Tunnels can contain flammable gases, vapors, or dust particles, particularly in industries such as mining, oil and gas, or chemical processing. Explosion-proof lights are built with robust materials and specialized components to withstand harsh environmental conditions and prevent the ignition of flammable substances, offering protection against potential explosions.
Safety Compliance:
Many countries and industries have strict safety regulations and standards in place to ensure the protection of workers and the prevention of accidents. The use of explosion-proof lights in mini tunnels helps to comply with these safety requirements, avoiding potential penalties and ensuring a safer working environment.
Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 13
Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 14



Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 15

Factory Price 18W/36W/45W IP66 IK10 Explosion Proof Light With High Quality SMT LED For Metal Smelting Fabrication 16
