Factory Price 28W 1100- 1300lm Zoom 15-36° LED Shapeable Commercial Track Lighting Contour Spotlight Track Light

Contact Now

Factory Price 28W 1100- 1300lm Zoom 15-36° LED Shapeable Commercial Track Lighting Contour Spotlight Track Light

Minimum Order Quantity :	1	Price :	424

Certification:	CE, RoHS

Detail Information
Power:	28W	Luminous Flux:	1100-1300LM
Beam Angle:	15-36°	Color Temperature:	2700-5700K
Color Rendering:	Ra≥97	Housing Color:	Black/White
Dimensions:	Ø85*H266mm	Lens Diameter:	Ø58mm
Weight:	1.41Kg	Zoom System:	11-lens Optical
Distortion:	≤0.5% TV	Rotation Range:	90° Vertical/355° Horizontal
Radiator Material:	1070# Pure Aluminum	Thermal Conductivity:	226W/m.K
Track Compatibility:	2/3/4/6 Wires
Highlight:	28W LED track spotlight , shapeable commercial track light , zoomable contour spotlight 15-36°

Product Description

Factory Price 28W 1100-1300lm Zoom 15-36° LED Shapeable Commercial Track Lighting

The T3008K-5836B is a professional-grade 28W LED contour spotlight from Kingfisher 2 Series featuring a 15°-36° zoom range and 870-1000LM output. It utilizes an advanced 11-lens optical system with ≤0.5% TV distortion for ultra-sharp projections and uniform illumination. The fixture boasts exceptional color rendering (Ra≥97) with adjustable CCT (2700K-4000K) via DIP CCT technology. Its robust design includes a φ125mm radiator and supports 90° vertical/355° horizontal rotation for flexible positioning. Weighing 1.41Kg with a black/white casing, it's ideal for museums, galleries, and architectural lighting, offering precise beam control and smart system compatibility (DALI/Zigbee/Bluetooth) for professional applications requiring high lumen output and optical precision.

Technical Specifications

Item no.	T3008K - 5836B
Power	28W
Luminous Flux (3000K)	1100-1300LM
Beam Angle (Lens Model)	Zoom 15-36° (5836B)
Ra	97
Color of housing	Black / White
Dimension (mm)	¢85*H266 (¢58 lens)
Track type	2/3/4/6 wires / surface mount

Key Features

High-Precision Zoom Optics: 15°-36° adjustable beam with 11-lens system delivers ultra-sharp, distortion-free projection (≤0.5% TV distortion) for professional lighting control.
Premium Color Quality: Ra≥97 CRI ensures museum-grade color accuracy, perfect for art galleries and high-end retail displays requiring true color rendition.
Smart Lighting Control: Compatible with DALI, Zigbee and Bluetooth systems for seamless dimming and 2700K-4000K CCT adjustment in smart environments.
Robust Thermal Design: φ125mm radiator and aluminum housing provide superior heat dissipation, ensuring stable performance and long lifespan.
Versatile Positioning: 90° vertical and 355° horizontal rotation enables flexible aiming for architectural, stage and exhibition lighting applications.
High-Efficiency Output: Delivers 870-1000 lumens at just 28W, combining powerful illumination with energy savings for commercial installations.

Design Advantages

Cold Forging Integrated Radiator Design

A radiator made of 1070# pure aluminum and molded by molding pressure. It has high thermal conductivity, low-temperature differences, low light failure, and long service life. Thermal conductivity 226W/m.K

360° Manual Rotation Design

Loosen the manual screw and turn the lens to achieve the 360° spot rotation adjustment function. Device to solve the 360° rotation of the projection and light spot.

High-Definition Optical Lens Design

It is formed by a plurality of high-definition coated optical lenses. The whole lamp has the characteristics of high luminous efficiency, high spot uniformity, minor distortion, extensive linear zoom range, good spot cut-off line, etc. A new optical path specially designed for COB light sources.

Optical-Grade Variable Aperture Design

An optical diaphragm made of high-precision special material with no blurring and freezing. Manual insertion and removal of the light cutting device can freely change the shape of the spot.

Multi-Layer Dry Damping Design

The invention is a focusing device not requiring the application of lubricating oil and has a silky feel. It is stable, reliable, wear-resistant, resistant to high temperatures, and does not wear off after extended use. Rotating the device can change the sharpness of the spot.

Enhanced Linear Zoom Mechanism

Short stroke, considerable focal length, high short-focus and long-focus recognition, visible to the naked eye, linear zoom is enhanced and more convenient. Rotate the device to adjust the spot size.

Product Parameters

Application Scenarios

Art Galleries & Museums Perfectly illuminates delicate artworks with its high CRI (Ra≥97) and adjustable 15°-36° beam for precise artifact highlighting without damaging UV/IR emissions.

Luxury Retail Displays Enhances premium merchandise with crisp, shadow-free illumination and tunable white light (2700K-4000K) to perfectly showcase products.

Theater & Stage Lighting Delivers professional-grade projections with ultra-low 0.5% distortion and smooth dimming for dramatic performances and events.

Architectural Accent Lighting Ideal for building facades and structural features with its powerful 870-1000 lumen output and flexible 355° rotation capabilities.

High-End Hospitality Spaces Creates elegant ambiance in hotel lobbies and restaurants through precise beam control and warm-to-cool white adjustment.

Corporate & Exhibition Spaces Provides flicker-free, high-quality illumination for professional environments requiring both functional lighting and aesthetic projection capabilities.

Packaging & Shipping

Certifications

Company Profile

Frequently Asked Questions

Q1: What do you sell?

A1: We provide good quality of floodlight, high bay light, explosion proof light, tri-proof light, downlight, and other lighting products, as well as responsible services and reliable after-sales warranty.

Q2: Is it OK to print my logo on led light product?

A2: Yes. We provide ODM and OEM services. Please inform us formally before our production and confirm the design firstly based on our sample.

Q3: How to deal with the faulty?

A3: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

Q4: Can I have a sample order for led light?

A4: Yes, we welcome sample order to test and check quality. One sample or mixed samples are acceptable.

Q5: How long time to ship the goods if place an order?

A5: Usually 7 days for sample or small order, 15 working days for bulk order, but sometimes depend on the order quantity.
