Factory Price ATEX Certified Explosion Proof Flood Light, Oil Gas LNG Chemical Plant Minging LED Explosion Proof Highbay Light, IP66 Ik08 Die-Cast Aluminum

Minimum Order Quantity :	1PC	Price :	US$134.00-145.00
Packaging Details :	1PCS/Carton	Delivery Time :	7days
Payment Terms :	T/T	Supply Ability :	10, 000PCS/Months

Place of Origin:	China	Brand Name:	MF
Model Number:	MF-EX02-C-50W

Detail Information
CCT:	3000K,4000K,5000K,5700K,6500K	Lumen Efficiency:	140LM/W (±5%)
Volts:	AC100-277V/120-347V/277-480V,50-60Hz	Beam Angle:	30°/45°/60°/90°/120°
Driver Efficiency:	90%	Housing Material:	Die-casting Aluminum
Cover Material:	Tempered Glass

Product Description

Goat Family Explosion-proof Flood Light
Explosion-proof floodlights are mainly used in dangerous areas such as petrochemical plants, chemical plants, and oil pump rooms where there are flammable gases and dust. They prevent the possible electric arcs, sparks and high temperatures inside the lamp from igniting the surrounding environment.
The LED light source has a luminous efficacy of up to 140LM/W, with a power range of 50W to 400W, and the correlated color temperature can be adjusted from 3000K to 6500K. The housing is made of Die-casting Aluminum and uses Tempered Glass, featuring an IP66 protection level and anti-shock, corrosion-resistant properties. Factory Price ATEX Certified Explosion Proof Flood Light, Oil Gas LNG Chemical Plant Minging LED Explosion Proof Highbay Light, IP66 Ik08 Die-Cast Aluminum

• Working Temperature: -40°C ~ +55°C.
• High quality SMT LED and Brand Driver
• Heavy-duty and high impact resistance.
• Integrated junction box for driver .

• Zinc-rich powder coated finish treatment.
• Up to 5 years warranty .
• Various installation ways for different applications.
• Glass lens or polycarbonate lens to make different beam angles.

3 Sizes range from 50W to 400W

Model No.	MF-EX02-C-50W	MF-EX02-C-75W	MF-EX02-C-100W	MF-EX02-C-150W	MF-EX02-C-200W	MF-EX02-C-240W	MF-EX02-C-300W	MF-EX02-C-400W
General
Watts	50W	75W	100W	150W	200W	240W	300W	400W
LED Type	SMD 2835
LED Quantity	168PCS		168PCS		336PCS		504PCS
CCT	3000K,4000K,5000K,5700K,6500K
Lumen Efficiency	140LM/W (±5%)
Volts	AC100-277V/120-347V/277-480V,50-60Hz
CRI	Ra>80(70,90 Optional)
Beam Angle	30°/45°/60°/90°/120°
Hours Rated	60,000 hours
Electrical
Power Factor	>0.9
THD	<20%
Driver Efficiency	90%
Dimming	NO
Mechanical
Housing Material	Die-casting Aluminum
Cover Material	Tempered Glass
IP Rating	IP 66
IK Rating	IK 08
Net Weight
Dimension(LWH)	250*194mm		250*194mm		320*205mm		400*202mm
Addtional
Warranty	5 Years
Working Temperature	-40℃~ +55℃
Working Humidity	20%~90%
Storage Temperature	-40℃~ +80℃
Storage Humidity	10%~90%

Factory Price ATEX Certified Explosion Proof Flood Light, Oil Gas LNG Chemical Plant Minging LED Explosion Proof Highbay Light, IP66 Ik08 Die-Cast Aluminum
LIGHT DISTRIBUTION

Oil and Gas industry
• All petroleum production and refining
• Petroleum loading and transportation
• Petroleum storage and retail
• LNG industry
• All mining operations and service
Chemical industry
• All types of paint facilities
• Chemical production and storage
Ocean, marine and aerospace field
• Ocean platform operation
facilities and structure
• Aerospace clean room and production
• Ocean vessel operations
Metal treatment
• Steel and aluminum factories
• Pumping stations in any environment
• Metal smelting, foundry and fabrication
Food and alcohol industry
• Flour and fine particle production
and storage
• Food and distilling production
• Alcohol industry

Other high humidity, high dust,
high temperature, vapor locations
