IP66 IK08 5 years warranty Various installation ways Ra>80 ATEX Certified Die-Cast Aluminum Explosion Proof highbay Ligh

Contact Now

IP66 IK08 5 years warranty Various installation ways Ra>80 ATEX Certified Die-Cast Aluminum Explosion Proof highbay Ligh

Minimum Order Quantity :	1PCS	Price :	US$145.00-152.00
Packaging Details :	1PCS/Carton	Delivery Time :	7days
Payment Terms :	T/T	Supply Ability :	10, 000PCS/Months

Place of Origin:	China	Brand Name:	MF
Model Number:	MF-EX02-C-50W

Detail Information
CCT:	3000K,4000K,5000K,5700K,6500K	Lumen Efficiency:	140LM/W (±5%)
Volts:	AC100-277V/120-347V/277-480V,50-60Hz	Beam Angle:	30°/45°/60°/90°/120°
Driver Efficiency:	90%	Housing Material:	Die-casting Aluminum
Cover Material:	Tempered Glass	CRI:	Ra>80
Hours Rated:	60,000 Hours	Power Factor:	>0.9
THD:	<20%	Dimming:	NO
IP Rating:	IP 66	IK Rating:	IK 08

Product Description

IP66 IK08 5 years warranty Various installation ways Ra>80 ATEX Certified Die-Cast Aluminum Explosion Proof highbay Ligh

Model No.	MF-EX02-C-50W	MF-EX02-C-75W	MF-EX02-C-100W	MF-EX02-C-150W	MF-EX02-C-200W	MF-EX02-C-240W	MF-EX02-C-300W	MF-EX02-C-400W
General
Watts	50W	75W	100W	150W	200W	240W	300W	400W
LED Type	SMD 2835
LED Quantity	168PCS		168PCS		336PCS		504PCS
CCT	3000K,4000K,5000K,5700K,6500K
Lumen Efficiency	140LM/W (±5%)
Volts	AC100-277V/120-347V/277-480V,50-60Hz
CRI	Ra>80(70,90 Optional)
Beam Angle	30°/45°/60°/90°/120°
Hours Rated	60,000 hours
Electrical
Power Factor	>0.9
THD	<20%
Driver Efficiency	90%
Dimming	NO
Mechanical
Housing Material	Die-casting Aluminum
Cover Material	Tempered Glass
IP Rating	IP 66
IK Rating	IK 08
Net Weight
Dimension(LWH)	250*194mm		250*194mm		320*205mm		400*202mm
Addtional
Warranty	5 Years
Working Temperature	-40℃~ +55℃
Working Humidity	20%~90%
Storage Temperature	-40℃~ +80℃
Storage Humidity	10%~90%

IP66 IK08 5 years warranty Various installation ways Ra>80 ATEX Certified Die-Cast Aluminum Explosion Proof highbay Ligh

• Working Temperature: -40°C ~ +55°C.
• High quality SMT LED and Brand Driver
• Heavy-duty and high impact resistance.
• Integrated junction box for driver .

• Zinc-rich powder coated finish treatment.
• Up to 5 years warranty .
• Various installation ways for different applications.
• Glass lens or polycarbonate lens to make different beam angles.

IP66 IK08 5 years warranty Various installation ways Ra>80 ATEX Certified Die-Cast Aluminum Explosion Proof highbay Ligh

Oil and Gas industry
• All petroleum production and refining
• Petroleum loading and transportation
• Petroleum storage and retail
• LNG industry
• All mining operations and service
Chemical industry
• All types of paint facilities
• Chemical production and storage
Ocean, marine and aerospace field
• Ocean platform operation

facilities and structure
• Aerospace clean room and production
• Ocean vessel operations
Metal treatment
• Steel and aluminum factories
• Pumping stations in any environment
• Metal smelting, foundry and fabrication
Food and alcohol industry
• Flour and fine particle production IP66 IK08 5 years warranty Various installation ways Ra>80 ATEX Certified Die-Cast Aluminum Explosion Proof highbay Ligh

and storage
• Food and distilling production
• Alcohol industry

Other high humidity, high dust,
high temperature, vapor locations IP66 IK08 5 years warranty Various installation ways Ra>80 ATEX Certified Die-Cast Aluminum Explosion Proof highbay Ligh
