Product Description
OEM ODM IP66 IK08 Atex Lamp Explosion Proof LED Highbay Light 140LM/W IP66 IK08 50W 100W 150W 200W 300W 400W With Tempered Glass Lens For Oil Gas Chemical Mining Hazardous Zone
MF EX02 B Goat 2 Family explosion-proof highbay light is purpose-built high-bay lighting hardware for gas and dust classified hazardous locations.
Power portfolio ranges 50W up to 400W adopting high-efficiency SMD light source reaching 140LM per watt.
Full ATEX and IECEx compliance guarantees safe operation inside explosive-prone industrial zones.
It carries IP66 dust-water tight rating plus IK08 mechanical impact resistance.
Zinc-rich powder coated die cast aluminum housing stands severe corrosive coastal and chemical-site atmosphere.
Multiple beam angles from 30 degree to 120 degree with durable tempered glass lens.
Wide multi-range industrial input voltage covers AC100-277V, AC120-347V, AC277-480V.
Flexible mounting selections include ceiling mount, wall mount and hook pendant mount.
Backed by 5-year factory warranty, fit for oil gas refinery, LNG facility, mining, offshore platform and food distilling hazardous-site projects.
ATEX & IECEx Full Explosion‑Protection Qualification For Hazardous Zones
| Item |
Specification |
| Model |
MF EX02 B-50W /75W /100W /150W /200W /240W /300W /400W |
| Rated Power |
50W,75W,100W,150W,200W,240W,300W,400W |
| LED Type |
High-performance SMD 2835 |
| Color Temperature |
3000K,4000K,5000K,5700K,6500K |
| Luminous Efficacy |
140LM/W (±5%) |
| Input Voltage |
AC100-277V / AC120-347V / AC277-480V,50-60Hz |
| Beam Angle |
30°/45°/60°/90°/120° |
| Rated Lifespan |
60000 Hours |
| Power Factor |
>0.9 |
| THD |
<20% |
| Driver Efficiency |
90% |
| Dimmable |
Non-dimmable (standard version) |
| Housing Material |
Die-casting Aluminum with zinc-rich powder coated finish |
| Cover Lens |
Tempered Glass |
| IP Rating |
IP66 |
| IK Rating |
IK08 |
| Explosion-proof Standard |
ATEX, IECEx certified for hazardous gas and dust zone |
| Working Temperature |
-40ºC ~ +55ºC |
| Working Humidity |
20% ~ 90% |
| Storage Temperature |
-40ºC ~ +80ºC |
| Storage Humidity |
10% ~ 90% |
| Warranty |
5 Years |
Strictly built for explosive gas and combustible dust classified locations. Complete ATEX and IECEx marking compliance. Safe deployment within oil refinery, chemical processing plant, mining and offshore working sites.
EXPLOSION PROTECTION
•Working Temperature:-40°C ~+55°C.
•High quality SMT LED and Brand Driver
•Heavy-duty and high impact resistance .
•Integrated junction box for driver .
•Zinc-rich powder coated finish treatment .
•Up to 5 years warranty .
•Various installation ways for different applications.
•Glass lens or polycarbonate lens to make different beam angles.
Main housing is high-strength die cast aluminum alloy.
Zinc-rich powder coating delivers anti-rust, anti-corrosion capability for coastal offshore and chemical plant corrosive atmosphere.
IP66 structure fully blocks dust particle and high-pressure water jet; IK08 rating stands mechanical strike and site accidental collision.
Independent integrated junction box design, driver placed inside sealed chamber, simplify field wiring while keep explosion-proof integrity.
Wide working temperature window -40ºC to +55ºC, can run normally under severe cold or high-temperature workshop environment.
Storage temperature supports -40ºC ~ +80ºC.
Multiple beam angles from 30 degree up to 120 degree are available with tempered glass or polycarbonate lens solutions.
Built specifically for high‑risk hazardous industrial environments, MF EX02 A Goat Family explosion proof flood light is heavy‑duty lighting hardware engineered for petrochemical, mining and offshore facilities.
Unlike ordinary commercial floodlights, this unit complies with strict ATEX and IECEx explosion‑protection standards to operate safely within explosive‑gas and combustible‑dust classified zones.
Three size frameworks cover power tier from 50W up to 400W, satisfying small‑area local lighting and large‑site wide‑range flood illumination requirements. Robust die cast aluminum main body with zinc‑rich anti‑corrosion surface treatment resists dust, moisture and mechanical collision.
Multiple beam angle choices and flexible mounting structures allow engineers to configure lighting layout freely for different field conditions. Long service cycle plus 5‑year warranty effectively cut recurring replacement expense for long‑run industrial projects.
Different from ordinary commercial highbay lamps, optical solution of MF EX02‑B is balanced for safety and illumination efficiency, not pursuing ultra‑narrow beam at the cost of site practicality.
Multiple beam‑angle options respond to varied site layout. Narrow 30‑45‑60‑degree beams for tall‑bay targeted working‑surface lighting; wide 90‑120‑degree beams for large‑area workshop general flood illumination. ‑ Tempered glass lens provides high mechanical strength. Resist thermal shock from big temperature swing common in outdoor petrochemical and mine‑site surroundings.
Sea transportation / Air transportation / Rail transportation / International express
Oil & gas industry: petroleum refinery, oil storage terminal, LNG facility, petroleum loading-unloading station
Chemical industry: chemical production workshop, chemical raw-material storage warehouse, paint processing site
Mining operations: underground auxiliary area, surface mining site and mine service facility
Offshore & marine field: offshore platform working area, vessel related operation location
Metal processing plant: steel mill, aluminum smelting workshop, pumping station in corrosive environment
Food & alcohol processing: grain powder production warehouse, distillery and ferment production site
Other harsh sites: high-dust, high-humidity, high-temperature hazardous industrial zones
