Product Description

ALUMINUM ATEX IECES EX 50/75/100/150/200/240/300/400W HIGHBAY IP66 IK08 TEMPERED GLASS OIL GAS MINING EXPLOSION PROOF EXPLOSIONPROOF WATER LED HIGH BAY LIGHT

Feature

- Multiple beam angle options: 30°/45°/60°/90°/120°
- Wide operating temperature range: -40°C ~ +55°C
- Adopt high-quality SMT LED and brand-name driver
- Heavy-duty structure with high impact resistance
- Integrated junction box for driver
- Zinc-rich powder coated surface finish
- Up to 5-year warranty
- Multiple installation methods for diverse site applications
- Optional tempered glass or polycarbonate lens to achieve different beam angles
- Power range covers 50W-400W

Characteristic

- CCT optional: 3000K,4000K,5000K,5700K,6500K
- LED quantity:
50-150W:168PCS
200-240W:336PCS
300-400W:504PCS
- Dimension:
50-150W: Φ250×194mm
200-240W: Φ320×205mm
300-400W: Φ400×202mm
- Installation: Ceiling mounting, wall mounting, hook pendant, pole-mount & balance chain installation
- Warranty: 5 years

Mechanical Structure

1. Three overall size form factors:
- 50-150W: 329*217*166mm
- 200-240W: 389*268*191mm
- 300-400W: 462*312*205mm
2. Die-cast ADC12 aluminum housing with zinc-rich powder coating for anti-corrosion
3. Integrated internal driver junction box, separate lens options to achieve varied beam angles
4. Tempered glass front cover, high mechanical strength (IK08)
5. Adjustable lamp body angle via adjustment screw

Product description

Product Size

Installation:

Mounting methods

- Ceiling mounting
- Wall mounting
- Hook / pendant chain mounting
- Pole mounting (adjustable pole length)

Application:

- Oil & gas industry: petroleum production, refining, loading, transportation, storage, retail; LNG industry
- Mining operations
- Chemical industry: chemical production & storage, paint manufacturing facilities
- Ocean & marine field: offshore platforms, ocean vessel operations
- Aerospace field: aerospace clean-room & production workshop
- Metal processing: steel & aluminum factories, metal smelting & foundry, pumping stations
- Food & alcohol industry: fine-particle flour production, food distilling, alcohol manufacturing
- Other hazardous locations: sites with high humidity, heavy dust, high temperature and vapor where explosion-proof lighting is required
