Photocell Sensor Garden Light LED Street Light 240W 100W 50W Pole IP66 Ik08 Waterproof Road Sidewalks Parking Light
Contact Person : Claire Li
Phone Number : 86-15999718117
WhatsApp : +8615999718117
Minimum Order Quantity : | 100PCS | Price : | Negotiable |
---|---|---|---|
Packaging Details : | 16.5*15*22cm/1pcs, G.W: 1.2Kg | Delivery Time : | Depends on orders |
Payment Terms : | T/T, Western Union, L/C, Paypal | Supply Ability : | 5,000pcs/Month |
Place of Origin: | China | Brand Name: | MF |
---|---|---|---|
Certification: | CE, RoHS,SAA | Model Number: | MF flood street parking light L |
Detail Information |
|||
CCT: | 3000K/4000K/5000K/5700K | Material: | Alloy Aluminum+Optical PC+Tempered Glass+Stainless |
---|---|---|---|
Power: | 60/120/180/240/300W | IP Rate: | IP67 |
Ik Rate: | IK 09 | Warranty: | 5years |
Material: | Aluminum+PC+Metal+Stainless Steel | Luminous Flux: | 120-160lm/W |
Lumen Efficiency: | 135lm/W | LED: | Luxeon 5050 |
Lens: | T1m1 And T5u1 Optic Lens Are Not Available | Colour: | Black/Bronze/Green/White |
Accessory: | 10ka SPD/Photocell/Motion Sensor/1-10V | Modular: | 60W Per Module |
Driver: | Inventronics | Operating Temperature: | -40ºC ~ +50ºC |
Optic (Iesna): | Type I, Type II, Type III, Type IV, Type V | ||
High Light: | IP67 Waterproof Outdoor LED Flood Light,300W Waterproof LED Roadway Light,LED Roadway Light With SPD Photocell |
Product Description
IP67 Waterproof Outdoor LED Flood Light 60-300W With SPD Photocell Motion Sensor For Street Plaza Sports Filed
HOUSING
1.Die cast aluminum housing.
2.Modular design allows for easy installation, replacement and maintenance. This design also creates a chimney effect which provides exceptional thermal management.
3.Meets 3G vibration per ANSI C136.31-2010.
4.IK10 rated.
FINISH
1.Corrosion resistant polyester powder painted 100μm thickness.
2.Meets a 1000-hour salt spray certification per ASTM B117/ ISO 9227:2012.
3.Standard colors: Grey, Black, Bronze and White.
4.Customized colors are available.
LED & OPTICAL ASSEMBLY
1.Each PCB are mounted with a TVS (Transient Voltage Suppressors) to protect the LEDs from voltage transients induced by lightning and other transient voltage events.
2.High-uniformity LED optics are constructed of durable optical polycarbonate that is impact and UV resistant.
3.The metal plate provides double protection for the LED light engine and prolongs LED optics life.
4.Over 15 optical lenses are available for virtually any application.
5.Each LED module are 100% tested prior to assembly which is IP67 rated.
MOUNTING
1.Extremely flexible with 360 degree rotation.
2.Interchangeable with the other GAMA Series with a bracket change.
3.Brackets are available for different installations.
Electrical/ Key Components/ Controls
1.220-240VAC and 120-277VAC available.
2.Surge protection to 20kV/10kA per ANSI/IEEE C62.41.2-2002 available.
3.High quality LEDs, driver and components, e.g. MOLEX, WAGO connectors.
4.Multiple smart lighting control options are available, e.g. photocell, motion sensor, 1-10V.
Power: 60/120/180/240/300W
Efficacy: 120-160lm/W
Control: Photocell/Motion Sensor/1-10V dimming
Application: Architecture/Factory Warehouse/Billboard/Auto dealership/Area lighting
Power | 60/120/180/240/300W | IP Rating | IP67 |
Input | 220-240V AC or 120-277V AC | SPD | Optional |
PF | >0.95 | Certification | U-L/ CUL/ DLC/LM79/SAA/ ENEC/ CB/ CE/ ErP/ ROHS/ IK10 |
THD | <20% | DALI | Optional |
L70/L90 | >200,000H/>60,000H | 1-10V | Optional |
Operating temperature | -40°C~+50°C | Photocell | Optional |
Typical Efficacy | 120-160lm/W | Smart Control | Optional |
ANSI CCT | 3000K/4000K/5000K5700K | Optic (IESNA) | Type l, Type Il, Type lll, Type Iv Type V |
Min CRI | 70 or 80 or 90 | Color Options | Grey/Black/Bronze/White |
ModelNo. | pyrster Power |
Mtpml Modules |
LEDs | EPA (sq.ft) |
Drive current |
luminous Flusx | Efficacy (lm/W) |
5000K | |||||||
MFA :220-240V& or 120-277v Ac | |||||||
MFA60 | 60w | 1 | 18 | 0.347 | 1050mA | 8100lm | 135 |
MFA120 | 120w | 2 | 36 | 0.347 | 16200Im | 135 | |
MFA180 | 180w | 3 | 54 | 0.372 | 24300Im | 135 | |
MFA240 | 240w | 4 | 72 | 0.404 | 32400Im | 135 | |
MFA300 | 300w | 5 | 90 | 0.437 | 40500lm | 135 |
MFA60-C | 4.45kg | 5.14kg | 5.91" *13.58" *4.41" | 14.37"*16.34"×6.3" |
MFA120-C | 5.56kg | 6.26kg | 8.27" * 13.58" *4.41" | 14.37" *16.34" *6.3" |
MFA180-C | 6.38kg | 7.21kg | 10.63" * 13.58"*4.41" | 16.73"*16.34" *6.3" |
MFA240-C | 7.1kg | 8.22kg | 12.99" * 13.58" * 4.41" | 16.73" * 16.34" *6.3" |
MFA300-C | 8.62kg | 9.59kg | 17.72"*13.58" *4.41" | 21.46" *16.34" *6.3" |
MFA60-T | 4.69kg | 5.45kg | 11.81"* 12.99"* 2.76" | 14.37"* 16.34" *6.3" |
MFA120-T | 5.58kg | 6.49kg | 14.17"* 12.99"*2.76" | 16.73" * 16.34" *6.3" |
MFA180-T | 6.52kg | 7.56kg | 16.54" *12.99"*2.76" | 19.09"*16.34" *6.3" |
MFA240-T | 7.45kg | 8.47kg | 18.9"*12.99"* 2.76" | 21.46"*16.34" *6.3" |
MFA300-T | 9.14kg | 10.45kg | 23.62"* 12.99"* 2.76" | 26.18"*16.34"*6.3" |
MFA60-L | 4.98kg | 5.97kg | 15.94"* 12.99" * 2.76" | 14.37"* 16.34"*6.3" |
MFA120-L | 5.79kg | 6.67kg | 18.31"* 12.99"*2.76" | 16.73"* 16.34"*6.3" |
MFA180-L | 6.9kg | 8.03kg | 20.67" *12.99"*2.76" | 19.09" * 16.34"*6.3" |
MFA240-L | 7.79kg | 8.72kg | 23.03"*12.99" * 2.76" | 21.46"* 16.34" *6.3" |
MFA300-L | 9.42kg | 10.73kg | 27.76" * 12.99"*2.76" | 26.18"* 16.34"*6.3" |
MFA60-D | 3.86kg | 4.51kg | 5.91" * 12.99" * 5.04" | 12.01"* 16.34" * 6.3" |
MFA120-D | 4.93kg | 5.61kg | 8.27" * 12.99"* 5.04" | 12.01"* 16.34"*6.3" |
MFA180-D | 5.96kg | 6.66kg | 10.63"* 12.99"*5.04" | 14.37"* 16.34"*6.3" |
MFA240-D | 6.45kg | 7.24kg | 12.99"*12.99" *5.04" | 16.73"* 16.34"* 6.3" |
MFA300-D | 8.22kg | 9.19kg | 17.72" * 12.99" *5.04" | 21.46"* 16.34"*6.3" |
MFA60-U | 5.04kg | 5.61kg | 8.27"* 12.99"*4.33" | 12.01"*16.34"*6.3" |
MFA120-U | 5.19kg | 5.81kg | 8.27"* 12.99"*4.33" | 12.01"*16.34"*6.3" |
MFA180-U | 5.92kg | 6.64kg | 10.63"*12.99"*4.33" | 14.37"*16.34"*6.3" |
MFA240-U | 7.16kg | 7.99kg | 12.99"*12.99"*4.33" | 16.73"*16.34"*6.3" |
MFA300-U | 9.06kg | 9.92kg | 17.72"*12.99"*4.33" | 21.46"*16.34"*6.3" |
Outdoor Sports Fields: LED flood lights are commonly used to illuminate football fields, soccer fields, tennis courts, and basketball courts.
Parking Lots: LED flood lights provide bright and uniform lighting for large parking lots, ensuring safety and visibility.
Billboard and Signage Lighting: LED flood lights are used to illuminate billboards, signs, and advertising displays, attracting attention and enhancing visibility.
Landscapes and Gardens: LED flood lights are utilized to accentuate landscapes, gardens, and outdoor spaces, creating a beautiful ambiance and highlighting architectural elements.
Industrial and Warehouse Lighting: LED flood lights offer bright and even illumination for industrial and warehouse environments, improving visibility and safety.
Security Lighting: LED flood lights are used for outdoor security lighting, illuminating building perimeters, entrances, and parking garages.
Event Lighting: LED flood lights are commonly employed for temporary event lighting, providing vibrant lighting effects for concerts, festivals, and outdoor gatherings
.
Residential Areas: LED street lights are commonly used to illuminate residential streets, providing safe and well-lit environments for pedestrians and drivers.
Urban Roads: LED street lights are widely employed for lighting urban roads, including main thoroughfares and secondary streets, ensuring visibility and safety for motorists.
Highways and Expressways: LED street lights are used to illuminate highways and expressways, providing clear visibility and enhancing road safety during nighttime driving.
Commercial Areas: LED street lights are utilized in commercial areas, such as shopping districts and business centers, to ensure well-lit spaces for pedestrians and vehicles.
Parking Lots: LED street lights can be used to illuminate parking lots, ensuring visibility and security for vehicles and pedestrians.
Industrial Zones: LED street lights are suitable for lighting industrial zones and complexes, providing bright and efficient illumination for large areas. Public Spaces: LED street lights are employed in public spaces, such as plazas, squares, and promenades, enhancing safety and creating visually appealing environments.
LIGHTING CONTROL | 00 Not required 01 Photocell 02 Motion Sensor 03 Photocell Motion Sensor 04 DALI 05 1-10V dimming |
ACCESSORY INFO | Bird Spike 10KA/20KA Surge ProtectionDevice Back LightShield Safety Cable |
Optic LENS | 00 Not required 01 Photocell 02 Motion Sensor 03 Photocell Motion Sensor 04 DALI 05 1-10V dimming |
Packing:
