IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light

Minimum Order Quantity : 100PCS Price : Negotiable
Packaging Details : 16.5*15*22cm/1pcs, G.W: 1.2Kg Delivery Time : Depends on orders
Payment Terms : T/T, Western Union, L/C, Paypal Supply Ability : 5,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS,SAA Model Number: MF-Heliso-3

Detail Information

Power Supply: Solar CCT: 4000K-5700K
Material: ADC12 Aluminum+Al6063+PC Power: 20W/30W/40W/50W/60W/70W/80W/90W/100W/110W/120W
IP Rate: IP66 Warranty: 3years
Control System: PWM/MPPT/AC Input Beam Angle: 160°/85°, 160°/95°
Storage Temperature: -20°C~+40ºC Working Temperature: -10°C~+50ºC
Lumen Efficiency: 100 Lm/W ( Bespoke≥175lm/W) Battery: Li(Nicomn)O2 /LiFePO4 Battery
Certification: CE/CB/ROHS/TUV Recommended Installing Height: 4~8m
Control Ways: PIR / Microwave / Time / Remote

Product Description

Product Description

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 0
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 1
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light

Product Description


IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 2

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 3IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 4
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 5
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 6
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 7

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 8

Color Warm white(WW) Nature white(NW) Cool white (CW)
Color temperature 4000±300K 5000±300K 5700±300K
CRI ≥70
Beam Angle 155°/70°(20-120W,TM3),155°/75°(60-120W,TM2)
Material ADC12 , AL6063,PC
Discharge time 12 hours /day, 3 days +4 days low brightness
Control system PWM/MPPT/ AC input
Storage temperature -20°C~40°C
Working temperature -10°C~20°C
Battery type 32-LiFePO4
Power 20~120W
Luminous flux 2000~12000 lm
Luminous efficiency 100 lm/W ( Bespoke≥175lm/W)
Recommended installing height 4~8m
Control ways PIR / Microwave / Time / Remote
LED brand Lu-mileds/CREE Power 0.3 W
LED size 3.0X3.0X0.52 mm CRI ≥70
Beam Angle 120° LED efficiency 180-190 lm/W






Product dimension:

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 9
Photometry

LIGHT DISTRIBUTION CURVE

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 10


IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 11
ALL-IN -TWO TYPE Model No. Power Lumen output PV panel Battery(32-LIFePO4) LED qty
MFSL-S5H-XXX020 20W 2000 Im 35W 154 Wh 60 pcs
MFSL-S5H-XXX030 30W 3000 Im 35W 230 Wh 60 pcs
MFSL-S5H-XXX040 40W 4000 Im 43W 230 Wh 60 pcs
MFSL-S5H-XXX050 50W 5000 Im 58W 307 Wh 60 pcs
MFSL-S5H-XXX060 60W 6000 lm 62W 384 Wh 144 pcs
MFSL-S5H-XXX070 70W 7000 lm 86W 461 Wh 144 pcs
MFSL-S5H-XXX080 80W 8000 Im 94W 538 Wh 144 pcs

Installation Instructions

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 12IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 13
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 14

Packaging & Shipping

Diagram of Pallet loadingIP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 15IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 16

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 17




IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 18



Application

Street lights are commonly used to illuminate roads, streets, highways, parks, squares, parking lots and other public places. They can provide nighttime lighting, improve visibility for pedestrians and vehicles, reduce the risk of traffic accidents, and increase public safety. In addition, street lights can also be used for:
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 19


Enhance the urban landscape: The use of street lights in cities and communities can improve the beauty of the urban landscape and night environment, and promote urban tourism and economic development.
IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 20


Wildlife protection: The use of street lights in protected areas and nature reserves can improve the safety of visitors at night and reduce disturbance to wildlife.

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 21

Increase the sense of security of residents: The use of street lights in the community can increase the sense of security of residents, improve the environmental quality of the community, and reduce the crime rate.

IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 22

In conclusion, street lights can be used in many different venues and applications to increase public safety and visibility, improve urban environments and landscapes, and protect wildlife and the natural environment.


About Us:

We are a factory specializing in the production of LED lights for a wide range of indoor and outdoor applications. Our product portfolio includes LED downlights, LED panel lights, LED wall lights, LED tube lights, LED spotlights, LED track lights, LED ceiling lights, LED high bay lights, LED tri-proof lights, LED flood lights, LED high mast lights, LED stadium lights, LED street lights, LED garden lights, and LED explosion-proof lights. These products are widely installed in various large-scale lighting applications, such as farms, factories, schools, bridges, tunnels, ports, subways, airports, mines, hospitals, and more.

With a focus on LED lighting, we have gained expertise in producing and exporting high-quality LED light fixtures to over 132 countries in Asia, Europe, North America, Latin America, and the Pacific Ocean islands. Our LED lights are manufactured under the ISO9001 system, and our professional team ensures efficient management throughout the production process. We hold certifications such as CE, CB, ENEC, RoHS, CSA, UL, SAA, and REACH, which are accredited by reputable organizations like SGS or TUV, depending on the LED light family.

At MF, our dedicated R&D team is driven by passion, persistence, and technological expertise. Our engineers meticulously develop our LED lights, paying attention to even the smallest details. Our goal is to provide high-quality LED lighting solutions by combining our visionary approach with in-depth knowledge. We firmly believe in the power of lighting to enhance the quality of life and work for users worldwide. As a team, we understand that "LIGHTS THE WORLD" is not just a slogan but a commitment that we strive to fulfill through our hard work, day by day.


IP66 Outdoor LED Solar Street Light COB SMD Integrated Outdoor Parking light Sloar Light 23
