Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light

Minimum Order Quantity : 100PCS Price : Negotiable
Delivery Time : Depends on orders Payment Terms : T/T, Western Union, L/C, Paypal
Supply Ability : 5,000pcs/Month
Place of Origin: China Brand Name: MF
Certification: CE, RoHS Model Number: MFSL-S5A-BX

Detail Information

Cell Type: 32-LiFePO4 Control Ways: PIR / Microwave / Time / Remote
Charging Time (H): 6 Solar Panel: 45W/60W
With Light Source: With Light Source IP Rating: IP66
LED Chip: Philips Lumen Output: 4000lm/5000lm
CRI: >70 Discharge Time: 3 Days

Product Description

IP66 Heliso Family LED Solar Street Light for Highway/Street/Roadside

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 0



Specifications:



Color
Warm white (WW)
Nature white (NW)
Cool white (CW)
Color Temperature
4000±300K
5000±300K
5700±300K
CRI
≥70
Beam Angle
155°/70°(20-120W,TM3),155°/75°(60-120W,TM2)
Material
ADC12 , AL6063,PC
Discharge Time
12 hours /day, 3 days +4 days low brightness
Control System
PWM/MPPT/ AC input
Storage Temperature
-20ºC~+40ºC
Working Temperature
-10ºC~+50ºC
Battery Type
32-LiFePO4
Power
20~120W
Luminous Flux
2000~12000 lm
Luminous Efficiency
100 lm/W ( Bespoke≥175lm/W)
Recommended Installing Height
4~8m
Control Ways
PIR / Microwave / Time / Remote



LED Parameter:



LED Brand
Lu-miled/CREE
Power
0.3 W
LED Size
3.0X3.0X0.52 mm
CRI
≥70
Beam Angle
120°
LED Efficiency
180-190 lm/W



Description:



Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 1

Key Features:



Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 2



Installation:

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 3



Light Distribution Curve:



Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 4



Dimension:



Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 5

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 6

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 7



Production Line:



Ming Feng Lighting manufactures LED street lights with precision and expertise. The production process begins with the careful selection of high-quality materials. Advanced manufacturing techniques are employed to ensure the efficiency and durability of the lights.

First, the LED chips, known for their energy-saving properties, are meticulously placed on circuit boards. These boards undergo thorough testing to ensure optimal performance.

Next, the assembled components are housed in rugged and weather-resistant casings, designed to withstand the harshest outdoor conditions.

Quality control measures are implemented at every stage of production. Rigorous testing procedures guarantee that each LED street light meets the highest industry standards.

Ming Feng Lighting's commitment to innovation and reliability has positioned them as a leading provider of LED street lights. Their dedication to producing top-quality products ensures long-lasting performance, energy efficiency, and customer satisfaction.



Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 8

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 9



Applications:



Ideal for highways, squares, schools and other outdoor lighting place.



Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 10



Viaducts, urban streets

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 11



Overpasses, sidewalks

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 12



Packing:



Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 13

Garden Lawn Lamp IP66 Waterproof Outdoor Lighting Fixture LED Solar Street Light 14





Type
Power
Wooden case inner size(mm)
Lamps/wooden case
Qty of one 20ft CTN
Qty of one 40ft CTN
MFSL-S5A-XXX020~050
20~50W
1910x1100x1700
44pcs 220pcs 528pcs
MFSL-S5A-XXX060
60W
1745x1050x1700
30pcs 180pcs 390pcs
MFSL-S5A-XXX070
70W

1200x1050x1700
18pcs 144pcs 324pcs
MFSL-S5A-XXX080
80W
MFSL-S5A-XXX090
90W 1420x1050x1700 18pcs 120pcs 288pcs
MFSL-S5A-XXX100
100W
MFSL-S5A-XXX110
110W
1745x1050x1700
18pcs 108pcs 234pcs
MFSL-S5A-XXX120
120W







FAQ:



Q1: What do you sell?
A1: We provide good quality of floodlight, high bay light, explosion proof light, tri-proof light, downlight, and other lighting products, as well as responsible services and reliable after-sales warranty.

Q2: Is it OK to print my logo on led light product?
A2: Yes. We provide ODM and OEM services. Please inform us formally before our production and confirm the design firstly based on our sample.

Q3: How to deal with the faulty?
A3: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

Q4: Can I have a sample order for led light?
A4: Yes, we welcome sample order to test and check quality. One sample or mixed samples are acceptable.

Q5: How long time to ship the goods if place an order?
A5: Usually 7 days for sample or small order,15 working days for bulk order, but sometimes depend on the order quantity.
