IP67 Alloy Aluminum Waterproof 5Years Warranty LED Tunnel Light For Railway Tunnel High Way Tunnel

Minimum Order Quantity : 1PCS Delivery Time : depends on order
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Place of Origin: China Brand Name: MF
Certification: TUV,CB,CE,SAA,RoHs,ETL Model Number: MFTL-T9

Detail Information

CCT: 4000 5000 5700 6500K CRI: ≥70
Lifespan: >80000h IP: IP67
Driver: Inventronics Warranty: 5 Years
Voltage: 100 ~ 240V AC LED Chips Brand: Lu-mileds 5050
Highlight:

IP67 LED Tunnel Light

,

Alloy Aluminum LED Tunnel Light

,

High Way LED Tunnel Light

Product Description

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 0

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 1



Features



IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 2

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 3
Main Parameters
IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 4
LED Parameters
LED Brand
Lumileds
LED Package size
5.0x5.0x0.70 mm
Lamp bead light angle
120°
Driving power 2W
Color rendering index
ÿ70
Lamp bead light effect
180-190lm/W

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 9



IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 10

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 11

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 12

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 13

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 14

Installation Steps:
1. Use 4 M10 bolts to install the lamp on the bridge as shown in the picture;
2. Connect the waterproof connectors of the lamps, correctly connect the power cord to the puncture clamp, and then connect it to the AC power supply
cord (see wiring steps for details);
3. Adjust the lamp to the position according to the actual lighting needs of the site, and then tighten the bolts;
4. Adjust the dimming line settings according to on-site needs (not required for non-dimming);
Note: The power supply cable must ensure even distribution of the three-phase load.
If the product does not contain dimming cable: Please adapt the cable outer diameter φ7-9mm by yourself, strip the wire 15mm, and expose 5mm copper;
IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 15
IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 16



IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 17

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 18

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 19

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 20

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 21

LED tunnel lights find wide application in tunnel lighting due to their numerous advantages over traditional lighting sources

Tunnel Illumination:

LED tunnel lights provide efficient and uniform illumination inside tunnels, ensuring clear visibility for drivers and pedestrians. They offer better light distribution, reducing shadows and dark spots, which enhances safety and reduces the risk of accidents.
Energy Efficiency:

LED tunnel lights are highly energy-efficient compared to conventional lighting options such as high-pressure sodium lamps or metal halide lamps. LEDs consume significantly less energy while producing the same or even higher levels of brightness, resulting in reduced energy consumption and lower operating costs.
Long Lifespan:

LED tunnel lights have a longer lifespan compared to traditional lighting sources. They can operate for tens of thousands of hours, reducing the frequency of maintenance and replacement. This characteristic is especially beneficial in tunnels, where accessibility for maintenance is often challenging and time-consuming.
Durability and Reliability:

LED tunnel lights are designed to withstand harsh environmental conditions, including vibration, temperature variations, and humidity. They are resistant to shock and impact, ensuring their reliability and longevity in tunnel environments.
Instant On/Off:

LED tunnel lights offer instant illumination without any warm-up time. This feature is crucial in tunnels, where immediate and consistent lighting is necessary during power outages or emergency situations.
Controllability and Dimming:

LED tunnel lights can be easily integrated with intelligent lighting control systems. This allows for dynamic lighting scenarios, including dimming during low traffic periods to further reduce energy consumption. It also enables remote monitor







IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 22

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 23

IP67 Alloy Aluminum Waterproof  5Years Warranty  LED Tunnel Light For Railway Tunnel High Way Tunnel 24
