190lm/W 30W LED Outdoor Street Garden Light 3 Years Warranty IP66 70ra Aluminum Waterproof For Parking Lot

• Power range: from 10W to 30W;
• Municipal electricity supply optional;
• Using LiFePO4 batteries, with the capability to charge and discharge for over 2000 cycles, oters a safer and relatively smaller size and longer lifespan;
• Continuously work 2-3 rainy days under intelligent mode;
• Die-cast aluminum fixture housing ;
• UV stabilized polyester powder paint finish for durability and corrosion resistance, C5-grade painting;
• Mounting options: Post Top installation;
• Streamlined design to reduce wind resistance;
• Optical systems maintain an IP65 rating;
• ULOR=0%, no up light pollution;
• MPPT intelligent controller, features an intelligent energy-saving mode with selectable levels, extending the lighting duration and automatically adjusting brightness

• The light engine utilizes cutting-edge energy-efficient LEDs and specialized optics tailored for professional use.
• Featuring 5050 LED chips, our lighting solutions range from high-level specialized lights to cost-effective luminaires of exceptional quality. Custom LED chip options are also available.

Application Reference:
• Road & street lighting
• Residential area ligthing
• Garden, parks & perimeter lighting
• Parking lot lighting
• Industrial and commercial park lighting
• Railway & station side lighting
• Riverside & jogging track lighting

1) Moving Track MPPT maximum power tracking technology is adopted to improve the tracking eiciency and speed by more than 20%;
2) UltraGreen power control technology with extremely low static power consumption and sleep current;
3) 10 time-periods programmable load power/time control;
4) Multiple intelligent power modes can be selected, and the load power can be automatically adjusted according to the battery power; 5) Multiple protection functions such as battery /PV reverse connection protection, LED short circuit/open circuit/power limit protection;
6) Aluminum metal housing, IP67 waterproof rating, can be used in a variety of harsh environments
7) Extensible IoT remote communication monitoring function;

Parameter Table

Electrical Data
Model	MF-SP3-P10W	MF-SP3-P20W	MF-SP3-P30W
Control Function	MPPT intelligent controller
Standard working mode	2H: Detected-100%, None-30%; 3H: Detected-70%, None-10%; 7H: Detected-40%, None-10%
Photometric Data
LED Model	5050, custom on request
Efficacy	190lm/w
Luminous Flux	1900lm	3800lm	5700lm
Lens	Polycarbonate
CCT	3000K, 4000K, 5000K, 5700K, 6500K
CRI	70Ra
Mechanical Data
IP Rating	IP65
Housing	Aluminum
Mounting	Round pole (Ø60mm)
Painting	Black, custom color on request, C5-grade painting, resistance to extreme climates
Configuration Data
Solar Panel	18V, 35W
Battery Voltage	12.8V 6AH	12.8V 12AH	12.8V 18AH
Li-ion Battery	76.8WH	153.6WH	230.4WH
Charging Time	2-3Hrs	4-5Hrs	7-8Hrs
Run time	6.9Hrs
Battery Lifespan	>2000 time cycle
Ambient & Storage	-10°C to 50°C (14°F to 122°F) / -20°C~45°C (-4°F to 113°F)
Maximum Autonomy	Operate 2~3 rainy days under intelligent model.
Others
SCx	Top View - 0.249m2 (2.68ft2 ); Front View- 0.045m2 (0.48ft2 ); Side View - 0.042m (0.45ft2 )
Certification	FCC / CE / RoHS (The company is ISO 9001 and ISO 14001 certified.)
Product size	570*370*180 mm / 22.5*14.6*7.1 inches
Carton Size	645*445*230 mm / 25.4*17.5*9.1 inches
Net weight	6.2kg/13.7lbs	6.9kg/15.2lbs	7.5kg/16.5lbs
Warranty	8.3kg/18.3lbs	9.0kg/19.8lbs	9.6kg/21.2lbs
Recommend Installation Height	3-4m	3-6m	5-7m
Application Field	Road & street, residential area, garden, parks, parking lot, industrial and commercial parks, railway & station side, riverside & jogging track
Storage Instruction	For long-term storage, it is advisable to first fully charge the battery, then discharge it for 2 to 3 hours. This should be done every 3 months to prevent battery damage.
